Programming the Device Using FlashPro Express

4 Programming the Device Using FlashPro
Express
This chapter describes how to program the PolarFire device with the job file using Flashpro Express. The
job file is available at the following design files folder location:
mpf_dg0799_eval_liberosocv12p1_df\Programming_Job
Follow these steps:
1. Connect the jumpers and set up the PolarFire Evaluation Kit Board as described in steps 1 to 5 of
Run PROGRAM Action,
2. On the host PC, start the FlashPro Express software from
<$Installation Directory>\Microsemi\Libero_SoC_v12.1\Designer\binfp.
3. Select New or New Job Project from FlashPro Express Job from Project menu to create a new
job project, as shown in
Figure 21 • FlashPro Express Job Project
4. Enter the following in the New Job Project from FlashPro Express Job dialog box:
• Programming job file: Click Browse, and navigate to the location where the job file is located
and select the file. The default location is:
mpf_dg0799_eval_liberosocv12p1_df\Programming_Job
• FlashPro Express job project location: Select Browse and navigate to the location where
you want to save the project.
Figure 22 • New Job Project from FlashPro Express Job
5. Click OK. The required programming file is selected and ready to be programmed in the device.
page 21.
Figure 21, page 23.
