CoaXPress FMC Quickstart Card
Kit Contents - VIDEO-DC-CXP
Quantity
Description
1
CoaXPress device board with PolarFire FPGA with 100K LE MPF100T-1FCSG325I
1
CoaXPress host board
1
USB 2.0 A to Mini-B cable
1
FlashPro4
1
Coaxial HD-BNC to HD-BNC male-to-male cable
1
Quickstart card
1
Advertisement
Table of Contents
Related Manuals for Microchip Technology Microsemi CoaXPress VIDEO-DC-CXP
Summary of Contents for Microchip Technology Microsemi CoaXPress VIDEO-DC-CXP
- Page 1 CoaXPress FMC Quickstart Card Kit Contents - VIDEO-DC-CXP Quantity Description CoaXPress device board with PolarFire FPGA with 100K LE MPF100T-1FCSG325I CoaXPress host board USB 2.0 A to Mini-B cable FlashPro4 Coaxial HD-BNC to HD-BNC male-to-male cable Quickstart card...
- Page 2 CoaXPress FMC Daughter Quickstart Card Overview Microchip’s CoaXPress offering is a three-board solution that demonstrates high-speed transmission of high-resolution image data from a device to the host. It supports a 12.5G CoaXPress PHY and includes ready to use reference designs for quick prototyping. Microchip’s CoaXPress FMC daughter card is a hardware evaluation platform for evaluating and testing the CoaXPress protocol.
- Page 3 CoaXPress FMC Daughter Quickstart Card transmitted over the Micro BNC connector. To run the demo, set up the board as outlined in the following steps. For detailed instructions, refer to DG0884: PolarFire FPGA 12.5G video over CoaXPress Demo Guide. 1. Connect the FMC connector J11 on CXP host board to the FMC connector J14 on the PolarFire video kit.
