Error Report

Sets the error reporting capability for IGP/PGL forms.
•
On. Full error boundary checking reported. Any element which
falls off the current page is reported as an error.
•
Debug Mode. The printer is put in debug mode whenever a
form is defined in Create Form Mode. Each line of the Create
Form is printed along with an error if one occurred. This is the
same functionality as if there were a slash (/) entered before
the Create Form Name.
•
Fault. When an error occurs, the error is printed, and the
message "IGP/PGL ERROR" appears on the printer front
panel. The printer then stops printing and goes offline. The
error must be cleared before the printer can resume normal
operation.
•
Off. No form boundary checking. Graphic elements appear
clipped if they are beyond the page boundaries.
Submenu
105
