chipKIT™ Pro MX7 Board Reference Manual
USB Serial converter reset disconnect
This is used to connect/disconnect the USB serial converter reset circuit from the PIC32 MCLR pin. The
JP11
shorting block must be in place on this jumper when using the MPIDE development tools. Remove the
shorting block if the USB serial converter is interfering with proper operation of the licensed debugger circuit.
Do Not Use.
JP17
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
Page 25 of 35
