chipKIT™ Pro MX7 Board Reference Manual
44 JC-07 20
47 JE-01 32
48 JE-04 35
49 JF-03 42
50 JF-02 41
51 N/A N/A
52 JE-03 34
53 JE-02 33
56 N/A N/A
57 N/A N/A
58 J7-1,J7-2 55
59 J7-3,J7-4 56
60 JF-09 46
61 JF-10 48
63 N/A N/A
64 N/A N/A
66 J8-1,J8-2 57
67 J8-3.J8-4 58
68 N/A N/A
69 JD-01 24
70 JD-04 27
71 N/A N/A
72 JD-02 25
73 N/A N/A
74 N/A N/A
76 JD-07 28
77 JD-08 29
78 JD-09 30
79 JD-10 31
80 N/A 60
81 JC-09 22
82 JC-08 21
83 N/A N/A
84 JC-04 19
87 N/A N/A
88 N/A N/A
89 JC-03 18
90 JC-02 17
91 N/A N/A
92 JE-08 37
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
RB15 AN15/.../OCFB/PMALL/PMA0/CN12/RB15
RD14 AETXD0/SS1A/U1BRX/U1ACTS/CN20/RD14
RD15 AETXD1/SCK1A/U1BTX/U1ARTS/CN21/RD15
RF04 SDA3A/SDI3A/U3ARX/PMA9/CN17/RF4
RF05 SCL3A/SDO3A/U3ATX/PMA8/CN18/RF5
RF03 USBID/RF3
RF02 SDA1A/SDI1A/U1ARX/RF2
RF08 SCL1A/SDO1A/U1ATX/RF8
RG03 D-/RG3
RG02 D+/RG2
RA02 SCL2/RA2
RA03 SDA2/RA3
RA04 TDI/RA4
RA05 TDO/RA5
RC12 OSC1/CLKI/RC12
RC15 OSC2/CLKO/RC15
RA14 AETXCLK/SCL1/INT3/RA14
RA15 AETXEN/SDA1/INT4/RA15
RD08 RTCC/EMDIO/AEMDIO/IC1/RD8
RD09 SS1/IC2/RD9
RD10 SCK1/IC3/PMCS2/PMA15/RD10
RD11 EMDC/AEMDC/IC4/PMCS1/PMA14/RD11
RD00 SDO1/OC1/INT0/RD0
RC13 SOSCI/CN1/RC13
RC14 SOSCO/T1CK/CN0/RC14
RD01 OC2/RD1
RD02 OC3/RD2
RD03 OC4/RD3
RD12 ETXD2/IC5/PMD12/RD12
RD13 ETXD3/PMD13/CN19/RD13
RD04 OC5/PMWR/CN13/RD4
RD05 PMRD/CN14/RD5
RD06 ETXEN/PMD14/CN15/RD6
RD07 ETXCLK/PMD15/CN16/RD7
RF00 C1RX/ETXD1/PMD11/RF0
RF01 C1TX/ETXD0/PMD10/RF1
RG01 C2TX/ETXERR/PMD9/RG1
RG00 C2RX/PMD8/RG0
RA06 TRCLK/RA6
RA07 TRD3/RA7
USBID (USB-4)
D- (USB-2)
D+ (USB-3)
I2C2
I2C2
Primary Oscillator
Primary Oscillator
I2C1
I2C1
Ethernet PHY
Ethernet PHY
Secondary Oscillator
Secondary Oscillator
USB Overcurrent
Ethernet PHY
Ethernet PHY
Ethernet PHY
Ethernet PHY Reset
Page 28 of 35
