chipKIT™ Pro MX7 Board Reference Manual
Arranged by MCU Port and Bit Number
PIC32 Connector chipKIT
Pin # Pin # Pin #
17 BTN3 50
38 JF-08 45
58 J7-1, J7-2 55
59 J7-3, J7-4 56
60 JF-09 46
61 JF-10 48
91 N/A 47
92 JE-08 37
28 JE-09 38
29 JE-10 39
66 J8-1, J8-2 57
67 J8-3, J8-4 58
25 N/A N/A
24 N/A N/A
23 JA-01 0
22 JA-02 1
21 JA-03 2
20 N/A 59
26 JA-04 3
27 JA-07 4
32 JA-08 5
33 JA-09 6
34 JA-10 7
35 N/A N/A
41 N/A N/A
42 N/A N/A
43 JC-10 23
44 JC-07 20
6 JC-01 16
7 N/A N/A
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
MCU
PIC32 Signal Name
Port Bit
RA00 TMS/RA0
RA01 TCK/RA1
RA02 SCL2/RA2
RA03 SDA2/RA3
RA04 TDI/RA4
RA05 TDO/RA5
RA06 TRCLK/RA6
RA07 TRD3/RA7
RA09 Vref-/CVref-/AERXD2/PMA7/RA9
RA10 Vref+/CVref+/AERXD3/PMA6/RA10
RA14 AETXCLK/SCL1/INT3/RA14
RA15 AETXEN/SDA1/INT4/RA15
RB00 PGED1/AN0/CN2/RB0
RB01 PGEC1/AN1/CN3/RB1
RB02 AN2/C2IN-/CN4/RB2
RB03 AN3/C2IN+/CN5/RB3
RB04 AN4/C1IN-/CN6/RB4
RB05 AN5/C1IN+/VBUSON/CN7/RB5
RB06 PGEC2/AN6/OCFA/RB6
RB07 PGED2/AN7/RB7
RB08 AN8/C1OUT/RB8
RB09 AN9/C2OUT/RB9
RB10 CVrefout/PMA13/AN10/RB10
RB11 AN11/ERXERR/AETXERR/PMA12/RB11
RB12 AN12/ERXD0/AECRS/PMA11/RB12
RB13 AN13/ERXD1/AECOL/PMA10/RB13
RB14 AN14/ERXD2/AETXD3/PMALH/PMA1/RB14
RB15 AN15/.../OCFB/PMALL/PMA0/CN12/RB15
RC01 T2CK/RC1
RC02 T3CK/AC2TX/RC2
Notes
BTN3
I2C2
I2C2
Ethernet PHY Reset
I2C1
I2C1
debug PGC
debug PGD
USB VBUSON
Ethernet PHY
Ethernet PHY
Ethernet PHY
CAN2
