chipKIT™ Pro MX7 Board Reference Manual
53 JE-02 33
52 JE-03 34
48 JE-04 35
18 JE-07 36
92 JE-08 37
28 JE-09 38
29 JE-10 39
40 JF-01 40
50 JF-02 41
49 JF-03 42
39 JF-04 43
19 JF-07 44
38 JF-08 45
60 JF-09 46
10 BTN1 47
61 JF-10 48
11 BTN2 49
17 BTN3 50
96 LD1 51
97 LD2 52
95 LD3 53
1 LD4 54
58 J7-1,J7-2 55
59 J7-3,J7-4 56
66 J8-1,J8-2 57
67 J8-3, J8-4 58
20 N/A 59
80 N/A 60
7 N/A N/A
8 N/A N/A
12 N/A N/A
14 N/A N/A
24 N/A N/A
25 N/A N/A
35 N/A N/A
41 N/A N/A
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
RF08 SCL1A/SDO1A/U1ATX/RF8
RF02 SDA1A/SDI1A/U1ARX/RF2
RD15 AETXD1/SCK1A/U1BTX/U1ARTS/CN21/RD15
RE08 AERXD0/INT1/RE8
RA07 TRD3/RA7
RA09 Vref-/CVref-/AERXD2/PMA7/RA9
RA10 Vref+/CVref+/AERXD3/PMA6/RA10
RF12 AC1RX/SS3A/U3BRX/U3ACTS/RF12
RF05 SCL3A/SDO3A/U3ATX/PMA8/CN18/RF5
RF04 SDA3A/SDI3A/U3ARX/PMA9/CN17/RF4
RF13 AC1TX/SCK3A/U3BTX/U3ARTS/RF13
RE09 AERXD1/INT2/RE9
RA01 TCK/RA1
RA04 TDI/RA4
RG06 .../SCK2A/U2BTX/U2ARTS/PMA5/CN8/RG6
RA05 TDO/RA5
RG07 .../SDA2A/SDI2A/U2ARX/PMA4/CN9/RG7
RA00 TMS/RA0
RG12 TRD1/RG12
RG13 TRD0/RG13
RG14 TRD2/RG14
RG15 AERXERR/RG15
RA02 SCL2/RA2
RA03 SDA2/RA3
RA14 AETXCLK/SCL1/INT3/RA14
RA15 AETXEN/SDA1/INT4/RA15
RB05 AN5/C1IN+/VBUSON/CN7/RB5
RD13 ETXD3/PMD13/CN19/RD13
RC02 T3CK/AC2TX/RC2
RC03 T4CK/AC2RX/RC3
RG08 .../SCL2A/SDO2A/U2ATX/PMA3/CN10/RG8
RG09 .../SS2A/U2BRX/U2ACTS/PMA2/CN11/RG9
RB01 PGEC1/AN1/CN3/RB1
RB00 PGED1/AN0/CN2/RB0
RB11 AN11/ERXERR/AETXERR/PMA12/RB11
RB12 AN12/ERXD0/AECRS/PMA11/RB12
also CAN1 (JP-1)
also CAN1 (JP-2)
BTN1
BTN2
BTN3
LED1
LED2
LED3
LED4
I2C2
I2C2
I2C1
I2C1
USB VBUSON
USB Overcurrent detect
CAN2
CAN2
Ethernet PHY
Ethernet PHY
debug PGD
debug PGC
Ethernet PHY
Ethernet PHY
