chipKIT™ Pro MX7 Board Reference Manual
88 N/A N/A
52 JE-03 34
51 N/A N/A
49 JF-03 42
50 JF-02 41
53 JE-02 33
40 JF-01 40
39 JF-04 43
90 JC-02 17
89 JC-03 18
57 N/A N/A
56 N/A N/A
10 BTN1 47
11 BTN2 49
12 N/A N/A
14 N/A N/A
96 LD1 51
97 LD2 52
95 LD3 53
1 LD4 54
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
RF01 C1TX/ETXD0/PMD10/RF1
RF02 SDA1A/SDI1A/U1ARX/RF2
RF03 USBID/RF3
RF04 SDA3A/SDI3A/U3ARX/PMA9/CN17/RF4
RF05 SCL3A/SDO3A/U3ATX/PMA8/CN18/RF5
RF08 SCL1A/SDO1A/U1ATX/RF8
RF12 AC1RX/SS3A/U3BRX/U3ACTS/RF12
RF13 AC1TX/SCK3A/U3BTX/U3ARTS/RF13
RG00 C2RX/PMD8/RG0
RG01 C2TX/ETXERR/PMD9/RG1
RG02 D+/RG2
RG03 D-/RG3
RG06 .../SCK2A/U2BTX/U2ARTS/PMA5/CN8/RG6
RG07 .../SDA2A/SDI2A/U2ARX/PMA4/CN9/RG7
RG08 .../SCL2A/SDO2A/U2ATX/PMA3/CN10/RG8
RG09 .../SS2A/U2BRX/U2ACTS/PMA2/CN11/RG9
RG12 TRD1/RG12
RG13 TRD0/RG13
RG14 TRD2/RG14
RG15 AERXERR/RG15
Ethernet PHY
USBID (USB-4)
also CAN1 (JP-1)
also CAN1 (JP-2)
D+ (USB-3)
D- (USB-2)
BTN1
BTN2
Ethernet PHY
Ethernet PHY
LED1
LED2
LED3
LED4
