Operating manual

3.6 STARTING THE KEY-CUTTING MACHINE

1) Connect the power lead.

2) Turn on the key-cutting machine with the master switch (P). A beep sounds and for a second all the warning

lights (leds) on the key pad/control board (K) light up simultaneously on the machine front (blue vertical bar –

green vertical bar -2 red arrows) (Fig. 3).

3) When the beep stops only the blue warning light stays on to indicate that the machine is live.

Nota: if the conditions described above do not occur, see chap.6.7.

3.6.1

With the machine connected and on:

1) press the luminous switch (Q) to power the motor (Fig. 11).

2) Press the push button (D1) on the vertical axis lever (D) and lower the lever.

ATTENTION: if the motor does not start and the lever (D) will not move, check that the lever is

fully tightened.

A ﬂ ashing warning light (W) signals that the motor is on (chap.3.6.2). Attention: cutter in motion!

3) To turn off the motor release the lever (D) or turn off one of the 2 switches (P) or (Q).

3.6.2

There is a warning light (W) on the right-hand part of the machine

front (behind the clamps unit (Fig. 13).

When the cutter motor is on the warning light ﬂ ashes.

3.6.3

When the key-cutting machine is turned on the lamp is off.

Lightly touch the button (J1) to turn the lamp on or off.

Matrix ONE

Fig. 13

Fig. 14
