4

SYSTEM DATA

4.1

Physical data

4.1.1

Dimensions

The figures shown in Table 2
motor. This is the only dimension that deviates from the standard product.
Note: Customers should be aware that there might be differences in dimensions, terminal box size and position
when sourcing replacement motors.
RV3/5 RV8
510 mm 550 mm 570 mm
4.1.2

Mass

Pump type
E1M175
E1M275
4.2

Mechanical data

Degree of protection
Maximum tilt angle
Motor rotational speed (50 Hz supply)
Motor rotational speed (60 Hz supply)
© Edwards Limited 2008. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
are typical values of the overall length of the pump when fitted with a flameproof
Table 2 - Overall length
RV12 E1M18 E2M18
526 mm 576 mm
Table 3 - Pump mass
RV3
RV5
RV8
RV12
E1M18
E2M18
E2M28
E1M40
E1M80
E1M/ E1M/
E2M28
E2M40 E2M80
606 mm 775 mm 840 mm
Mass with no oil (kg)
28.0
28.0
31.0
32.0
37.0
39.0
42.0
85.0
101.8
231.4
262.4
IP55 (1 ph and 3 ph pumps)
10°
1430 rpm
1710 rpm
A652-18-880 Issue C
E1M/ E1M/
E2M175 E2M275
1010 mm 1110 mm
