- Page 1 SMC Series Ultra HD Hybrid Matrix Operation manual Kensence(shenzhen)Technology Development CO.,LTD version：V1.01.01 2018-3...
-
Page 2: Table Of Contents
SMC100/200/400/800 Contents 1. Introduction............................. 1 2. Product Features..........................1 3. Connection and Operation.......................2 4. Standard Packing list........................3 5. Specification............................4 6. Equipment operation and function description................5 6.1Panel introduction (SMC200 as an example) ..............5 6.2Touch screen control instructions..................6 6.3 PC Control Software Operation Instructions..............11 6.3-1 Switch operation...................... - Page 3 SMC100/200/400/800 Safety Reminder To protect the device and operating personnel from electrostatic discharge, you need to check and ensure that the device is grounding good before the device is powered on. Please observe the following when you install, use, maintain this equipment.
-
Page 4: Introduction
SMC100/200/400/800 1. Introduction SMC series is a kind of professional enhanced HD modular matrix. The plug-in design can realize the flexible configuration of various signal. Supports common video signal input, such as Fiber HDMI, DVI, VGA, YPBPR, DP, CVBS, 3G/HD/SD-SDI, IP streaming media, etc., supports powerful audio embedding and de-embedding function. -
Page 5: Connection And Operation
SMC100/200/400/800 3. Connection and Operation 1. Connect signal source such as blu-ray player,game controller,A/V receiver,cables,satellite receiver etc. to the HDMI input port of the matrix. 2.Connect the output port of the matrix to HD display or HD projector with HDMI input port.Notice:It’s better to... -
Page 6: Standard Packing List
SMC100/200/400/800 4. Standard Packing list Please check the outer package before using this product. Please contact us if the product is faulted or not intact. We will sincerely serve you according to relevant provisions. Name Quantity Unit Matrix enclosure AC power adapter... -
Page 7: Specification
SMC100/200/400/800 5. Specification Model SMC100 SMC200 SMC400 SMC800 10 ways enhanced 20 ways enhanced 40 ways enhanced 80 ways enhanced Name modular matrix modular matrix modular matrix modular matrix input/slot 10/5 20/10 40/20 80/40 Output/slot 10/5 20/10 40/20 80/40 Input/output... -
Page 8: Equipment Operation And Function Description
SMC100/200/400/800 6. Equipment operation and function description 6.1Panel introduction (SMC200 as an example) Figure 6.1.3 SCM200 product picture Explanation: 1. Signal input card area 2. Signal output card area; 3. In order of power supply 1, control interface 1 (network port and serial port), screen preview card, control interface 2, power supply 2;... -
Page 9: Touch Screen Control Instructions
SMC100/200/400/800 Network: network connection status indicator; 5.7-inch touch screen, through the screen control matrix; 6.2 Touch screen control instructions The matrix can be controlled by the front panel high-definition touch screen. The touch interface contains six operating options: “Display, Switch, Scene, Settings, Tools, About Us”. As shown in Figure 6.2.1, click any option to enter The operation interface of this option, after... - Page 10 SMC100/200/400/800 Figure 6.2.2 Signal input output port selection interface In the input port selection interface, click "previous page" "next page" to page, select the input signal, click "preview" to preview the screen of the currently selected signal, double-click the screen to exit the preview, click "return" to return The previous interface Figure 6.2.3 output port selection interface...
- Page 11 SMC100/200/400/800 the scene first. Select the scene number, and then click "save" or "call" button to complete the operation, such as save "scene 8" please select the scene number, and then click "save" button can be, such as calling "scene 11" please select The scene number, and then click the "call" button.
- Page 12 SMC100/200/400/800 following options can be set: Figure 6.2.6 Matrix setting interface Screen saver time: Click this option to pop up the numeric keypad and customize the screen saver time. The matrix default screen saver time is 3 minutes. Buzzer switch: Click this option and enter ON or OFF to turn the buzzer off or on.
- Page 13 SMC100/200/400/800 4,The use of shortcut tools: In the main interface, select "Tools" option, the pop-up tool interface, as shown in Figure 6.2.7: Figure 6.2.7 shortcut tools operation interface Shortcut method of operation instructions: 1 switch to more ,switch one of the input signals to the output of multiple outputs: Command: 1X1,2,3,4.
-
Page 14: Pc Control Software Operation Instructions
SMC100/200/400/800 Figure 6.2.8 Calibration interface 6.3 PC Control Software Operation Instructions The SMC Cloud Media Signal Management Platform is a green software that can be used by double-clicking on the main program to connect the matrix and computer via RS232 serial cable or network cable, and control the matrix through the SMC control software. - Page 15 SMC100/200/400/800 Figure 6.3.0 Computer IP change Network connection:Network connection: Use a network cable to connect the computer and matrix, double-click to open the control software, click the "SETUP" button, if you control the matrix through the network port, you must set the computer IP and matrix IP in the same network segment, in the network port online Select the computer's IP address in the column (click the "SETUP"...
- Page 16 SMC100/200/400/800 Figure 6.3.1 Network Connection Serial connection:Use a straight serial cable to connect the computer and matrix, double-click to open the control software, click the "SETUP" button, select the serial port connected to the matrix, for example, "COM2", then select the serial device "COM2", click "serial connection", when all the buttons in the lower right corner show green, the connection...
-
Page 17: Switch Operation
SMC100/200/400/800 changed in the network address in the configuration bar. Click Save to change the IP Turn on/off the buzzer: Make sure the matrix is connected to the computer. Click the “ON” button next to the buzzer to turn off or on the buzzer. - Page 18 SMC100/200/400/800 Figure 6.3.4 Input central control, resolution, name change and other operations 2）Output card:After you double-click any output signal on the “SWITCH” interface and pop up the interface as shown in Figure 6.3.5, you can set this output signal of the channel. In the “control”...
-
Page 19: Scene Save Operation
SMC100/200/400/800 6.3-3 Scene save operation Click the "VIEW" button to pop up the interface as shown in Figure 6.3.6. On the right side of the interface, click on the scenes you want to save in numbers 1 to 12. Press the "SAVE" button to move the current matrix. -
Page 20: External Serial Port Commands
SMC100/200/400/800 Figure 6.3.7 scene recall 6.3-5 External serial port commands The external serial port command is sent in the following format (black characters are fixed, "parameter" in the red character indicates the string command to be sent, "param length" indicates the length of the string command, and "packet length"... -
Page 21: Tv Wall Splicing
SMC100/200/400/800 Synchroni Paramet Packet Packet Comma Parameter zation Method Length Count Head Length (1BYT （1BY （2BYT （2BYTE （2BYT （n TE） （2BYTE （2BYT E） E） BYTE） ） E） ） 61 62 63 55 55 00 13 00 00 07 01 00 07 64 32 33 Tip: The SMC cloud media management platform can intelligently detect the card. - Page 22 SMC100/200/400/800 Figure 6.3.9 TV wall configuration As shown in the above figure, the 4 areas represent 4 display screens. Double-click each area to set in sequence. If we select "1" for the input signal, double-click the first area and enter "1" in the input box.
-
Page 23: Upgrade Equipment
SMC100/200/400/800 Figure 6.3.10 Set the input and output relations of each area Figure 6.3.11 Use mouse drag to splice Figure 6.3.12 Successful splicing 6.3-7 Upgrade equipment Select the upgrade button, click the drop-down button to select the serial port which connected to the matrix and the device to be upgraded, then double-click the upgrade file to select the software to be upgraded, and then click to start the upgrade. -
Page 24: Add A Plugin
SMC100/200/400/800 Figure 6.3.13 Select serial port, upgrade device, upgrade file Figure 6.3.14 Successful upgrade 6.3-8 Add a plugin Users can add some common tools by themselves; first, the user needs to put the tools they want to add in the root folder of the Plugins folder, and then open the sys_config.ini file and add the path after PLUGINS_LIST=. -
Page 25: Distributed Matrix Function
SMC100/200/400/800 Figure 6.3.15 Plug-in was added successfully 6.3-9 Distributed Matrix Function Connect this unit with the encoder and decoder to the network switch. Refresh the list to see the IP of the encoder and decoder. To switch, just select the encoder and decoder IP and click to switch. - Page 26 SMC100/200/400/800 Figure 6.3.17 Screen preview Note: In the SMC cloud media signal management platform software, the "Tools", "Audio Processor", and "Large Panel Splice" functions are valid for specific models, and are not described here.
-
Page 27: Communication Protocol And Control Instruction Code
SMC100/200/400/800 7. Communication protocol and control instruction code Communication protocol: (baud rate 115200, data bit 8, stop bit 1, parity bit) Type Control Command Function Description aXb.take. switch the input of a way to the output of b way aX1-b.take. -
Page 28: Version And Production Information
SMC100/200/400/800 3)The first input signal is switched to the third, 8th, 15th port output, send the command: 1X3,8,15.take. 4) Switch the 4th, 5th, and 6th input signals to the 21st, 25th, and 33rd port outputs and send the command: 4X21.5X25.6X33.take.
