19-13 Initial Diameter Measurement
Option:
[0] *
Set diameter when diameter reset
[1]
Set diameter based on analog signal The frequency converter sets the diameter based on an analog signal. The diameter can only be
19-14 Diameter Measurement Input
4
Option:
[1]
Input 53 (0-10 VDC or 0-20 mA)
[2]
Input 54 (0-10 VDC or 0-20 mA)
19-15 Reading at Core
Range:
0*
[-1100 – 1100]
19-16 Reading at Full Roll
Range:
0
[-1111 – 2111]
19-19 Tension Set-Point Input
Option:
[0] *
Parameter 19-02
[1]
Input 53 (0-10 VDC or 0-20 mA)
[2]
Input 54 (0-10 VDC or 0-20 mA)
19-20 Taper Set-Point Input
Option:
[0] *
Parameter 19-03
[1]
Input 53 (0-10VDC or 0-20mA)
[2]
Input 54 (0-10VDC or 0-20mA)
19-21 Tension Feedback Input
Option:
[1] *
Input 53 (0-10 VDC or 0-20 mA)
[2]
Input 54 (0-10 VDC or 0-20 mA)
20
Function:
It is possible to connect a roll diameter sensor to one of the frequency converter's analog inputs.
This signal can be used to have the controller use a measured initial diameter, rather than a diameter
size set by parameter. This is particularly useful in applications where non-uniform roll sizes are the
norm.
Parameters 19-04 to 19-06 set the diameter when the diameter is reset.
reset when the tension is OFF.
Function:
This parameter sets the analog input used for diameter measurement.
Function:
If a signal of 1.50 V results from measuring the smallest core, set this parameter to 150.
This parameter sets the analog input signal reading at the smallest core used. The value needs to
be multiplied by 100 to allow maximum resolution.
Function:
If a signal of 9.50 V results from measuring the full roll, set this parameter to 950.
This parameter sets the analog input signal reading at the largest roll size used. The value needs
to be multiplied by 100 to allow maximum resolution.
Function:
This parameter sets the source of the tension set-point.
Function:
This parameter sets the source of the taper set-point.
Function:
Sets analog input used for tension feedback.
®
MG.33.T1.02 - VLT
