iotega Wireless Security and Automation System
WARNING: This manual contains information on limitations regarding product use and function and information on the lim-
itations as to liability of the manufacturer. The entire manual should be carefully read.
V1.0 Reference Manual
Models:
UL
WS900
/WS901

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iotega WS900UL and is the answer not in the manual?

Questions and answers

Related Manuals for DSC iotega WS900UL

Summary of Contents for DSC iotega WS900UL

  • Page 1 iotega Wireless Security and Automation System V1.0 Reference Manual Models: WS900 /WS901 WARNING: This manual contains information on limitations regarding product use and function and information on the lim- itations as to liability of the manufacturer. The entire manual should be carefully read.

  • Page 2: Table Of Contents

    Table of Contents Section 1: Introduction 1.1 About the System 1.2 Compatible Devices List 1.3 Specifications Section 2: Installation 2.1 Alarm Controller Installation 2.2 Controls and Indicators 2.3 Enrolling Wireless PowerG Security Devices Section 3: Operation 3.1 Using the Integrated Keypad 3.1.1 Key Functions 3.1.2 Emergency Keys 3.1.3 Phone Test ([*][7])
  • Page 3 Appendix 8: Reporting Codes Appendix 1: Guidelines for Locating Smoke Detectors and CO Detectors Appendix 2: Regulatory Information Appendix 3: EULA Appendix 4: Limited Warranty - 3 -...
  • Page 4 iotega Wireless Security and Automation System Safety Instructions for Skilled Persons Warning: When using equipment connected to the telephone network, always follow the basic safety instructions provided with this product. Save these instructions for future reference. Inform the end-user of the safety precautions that must be observed when operating this equipment.

  • Page 5: Section 1: Introduction

    Section 1: Introduction Section 1: Introduction Product Type Model UL** Wireless temperature detector (indoor PGx905 use) 1.1 About the System Wireless 4-button key PGx939 PGx929 The iotega is an easy to use, wireless security and home Wireless panic key PGx938 automation panel.
  • Page 6 Low battery threshold: 7.3V Low battery restore: 7.4V Battery Critical Shutdown: 6.5V Battery lifespan: 3-5 years Extended Battery Model: DSC model 17000179, 7.4V, 4.5Ah, lithium- Ion, rechargeable Backup time: 24 hours Recharging time to 85%: 24 hours Low battery threshold: 7.3V Low battery restore: 7.4V...

  • Page 7: Section 2: Installation

    Section 2: Installation Section 2: Installation 2.1 Alarm Controller Installation Installing the iotega consists of connecting and powering up the hardware, as well as configuring the device using the installer portal. A typical installation includes the following steps: 1. Create a customer account 2.
  • Page 8 Section 2: Installation Figure 2-2 Panel Bottom Figure 2-3 Battery Compartment 1. Power cable Strain Relief 4. Battery 2. Access Cover for Battery, SIM Card and Reset Button 5. Reset button 3. Speaker 6. SIM card 7. Tamper switch Removing the Battery 1.

  • Page 9: Controls And Indicators

    Section 2: Installation 2.2 Controls and Indicators The iotega provides a series of LED indicators to notify users of system status. Figure 2-5 LED Indicators 1. Power LED 2. Ready to Arm LED 3. Armed LED 4. Trouble LED 5. WiFi Signal Strength LED 6.
  • Page 10 Section 2: Installation Indicator Description Armed ON Steady Partition is armed [Red] Flashing System in Alarm. [Note: this LED does not flash for silent alarms or panic alarms] [Red] Flashing Installer Walk Test ( Ready, Trouble and Arm LED’s flashing at same time) or sys- tem test in progress ( Ready, Trouble and Arm LED’s flashing at same time) [Red] Partition is disarmed or audible alarm annunciation is deactivated...

  • Page 11: Enrolling Wireless Powerg Security Devices

    Section 2: Installation Indicator Description Remote Con- ON Steady [Green] Link to remote server is active ON Flash Link to remote server is active but has failed to communicate nection Status [Red] Link to remote server is not active or the panel has not been activated with Alarm.com Flashing System Test ( AC, Ready, Trouble, Arm LED’s, WiFi Trouble, Cellular Trouble &...
  • Page 12 Section 2: Installation PGx901 Indoor siren PGx924 Curtain motion detector PGx904 PIR/Pet Immune motion detector PGx926 Smoke detector PGx914 PIR/Pet Immune motion detector PGx935 Shock detector and magnetic contact PGx905 Temperature detector PGx944 Tower Cam motion detector PGx911 Outdoor siren PGx945 Magnetic contact with Aux.

  • Page 13: Section 3: Operation

    Section 3: Operation Section 3: Operation This section describes how to use the iotega‘s integrated keypad. 3.1 Using the Integrated Keypad The iotega includes a built-in, touch sensitive keypad that activates by proximity. From the keypad, users can arm and dis- arm the system, view system troubles, and activate the Fire (F), Auxiliary (A) and Panic (P) keys.

  • Page 14: Phone Test ([*][7])

    Section 3: Operation Panic Keypad beeps three times and a signal is sent to the monitoring station. Panic alarm Can be configured as audible or silent To use the Emergency keys: 1. Press the Shift key (↑). The Emergency keys are illuminated (if enabled ). If an Emergency key is not pressed within 10 seconds, the keypad returns to normal operating mode.

  • Page 15: Stay Arming

    Section 3: Operation the Ready indicator turns off. the Armed indicator stays on. the panel is silent. Note: In Away Arming mode, bypassed zones are logged and communicated to the central monitoring station. 3.2.2 Stay Arming Note: Requires at least one zone defined as Interior Stay/Away or Delay Stay/Away for this function to work. Stay Arming is intended to arm the perimeter of the premises while permitting movement within.

  • Page 16: Section 4: Programming Options

    Section 4: Programming Options Section 4: Programming Options 4.2 System Configuration This section provides descriptions of all alarm controller Options options, both programmable and read-only. Programming options are accessed through the Installer portal. This section describes programmable options for the alarm controller.
  • Page 17 Section 4: Programming Options Bell Squawk on Arming Fire Bell Time-out takes priority over Burglary Bell Time-out. With this option enabled, the iotega chirps the sirens briefly Default: 5 Minutes at full volume when the system is successfully armed. The Valid range: 0 to 255 Minutes following options are provided to customize this option:...
  • Page 18 Section 4: Programming Options Lockout Attempts informing them that the previous event should be dis- regarded. This option is used to program the number of invalid access code entries allowed before the keypad is locked. When The communications cancel window begins after the trans- keypad lockout occurs, the system is inaccessible by keypad mission delay expires and a zone alarm is transmitted.

  • Page 19: Adc Events To Forward

    Section 4: Programming Options expires, the condition is transmitted and logged to the event 4.3 ADC Events to Forward buffer. The Low Battery Restore transmission is not delayed. This section is used to configure monitoring station and Default: 007 days receiver settings for the panel.

  • Page 20: Central Monitoring Station Programming Options

    Section 4: Programming Options Time Zone Default: 000.000.000.000 This option defines the time zone that the alarm system will Valid range: 000.000.000.000 to 255.255.255.255 operate in. Default: US Eastern Panel's Preferred DNS Server Valid US-Alaska, US-Aleutian, US-Arizona, US-Central, US-Eastern, US- This section is used to program the name of the preferred range: Hawaii, US-Indiana-East, US-Indiana-Starke, US-Michigan, US-Moun-...

  • Page 21: Partition Configuration Options

    Section 4: Programming Options Note: Programming an interval of less than 5 minutes or a Closing Delinquency Delay value greater than 999999 disables the test transmission. This value determines the time the alarm system delays before transmitting a close delinquency event to the central monitoring station.

  • Page 22: Primary Temperature Zone

    Section 4: Programming Options Panic Button Options Default: Disabled This feature is used to enable and disable the Fire, Medical, Valid range: Enabled/Disabled and Panic keys on the wirefree keypad. Programming is done through the installer portal under Command Cata- Duress Access Code (Pin) log>Keypad/Screen Settings>Panic Button Options.

  • Page 23: User Configuration Options

    Section 4: Programming Options Auto Alarm Scroll Option Has permission to enable WPS mode (to enable local pro- gramming access to the panel via the installer app) and also When this option is enabled, the keypad scrolls auto- initiate phone test. matically and displays all alarms when the bell is active or when an alarm is in memory while armed.

  • Page 24: Wireless Key Configuration Options

    Section 4: Programming Options Siren Label Volume Control This option is used to program a label for the device. This option is used to control the volume of the wireless siren. Default: Siren 1 Default: Medium. Valid range: 32 character ASCI Valid range: Low, Medium, High Siren Enable/Disable...

  • Page 25: Wireless Smoke And Co Configuration Options

    Section 4: Programming Options Zone Type Default: Button 1 = Away Arm* Button 2 = Stay Arm* This programming option is used to program a zone type for Button 3 = Disarm* the device. Button 4 = Panic** Default: 24-hour standard fire Button 5 = Quick Exit Valid range: 24-hour standard fire, Auto-verified fire...

  • Page 26: Wireless Temperature Configuration Options

    Section 4: Programming Options Device Enable/Disable Default: This option is used to enable and disable the wireless Valid range: device. Default: Enabled Chime Tone Valid range: Enabled/Disabled This option is used to select the tone emitted by the device when the zone is tripped. Device Partition Assignment Default: Beeps...

  • Page 27: Wireless Flood Configurations

    Section 4: Programming Options Device Partition Assignment Default: Enabled This option is used to assign the wireless device to an avail- Valid range: Enabled/Disabled able partition. Default: Temperature Format Valid range: This section is used to select the scale temperature is dis- played in.
  • Page 28 Section 4: Programming Options Device Enable/Disable Default: Enabled This option is used to enable and disable the wireless Valid range: Enabled/Disabled device. Default: Enabled Alarm LED Valid range: Enabled/Disabled This option is used to enable/disable the device’s onboard LED. When enabled, the LED activates when an alarm occurs.

  • Page 29: Wireless Pir (No Cam) Configurations

    Section 4: Programming Options Zone Attribute Default: Enabled This section is used to customize zone behavior for the Valid range: Enabled/Disabled device. The table below specifies the status of each attribute for this device. Normal Quality See "Available Zone Attributes" on page 32 for attribute When this option is enabled, the camera captures lower res- definitions.

  • Page 30: Wireless Door Window Configurations

    Section 4: Programming Options Detection Range Door Chime Disabled This option is used to select the sensitivity of the detector. Alarm Report Enabled The higher the sensitivity, the further the range of the Burglary Verified Enabled detector. Transmission Delay Enabled Default: High Bell Audible...

  • Page 31: Repeater Configuration Options

    Section 4: Programming Options Device Enable/Disable Default: Enabled This option is used to enable and disable the wireless Valid range: Enabled/Disabled device. Default: Enabled Alarm LED Valid range: Enabled/Disabled This option is used to enable/disable the device’s onboard LED. When enabled, the LED activates when an alarm occurs.
  • Page 32 Section 4: Programming Options Device Label This section is used to program a custom label for the device. Default: Repeater X Valid range: 32 character ASCII Device Enable/Disable This option is used to enable and disable the wireless device. Default: Enabled Valid range: Enabled/Disabled...

  • Page 33: Available Zone Types

    4.8 Available Zone Types Delay 1 Commonly assigned to primary points of entry. Follows entry delay 1 and exit delay timers. Arming the alarm system starts the exit delay timer. After the exit delay has expired, opening the door starts the entry delay timer. During entry delay, the keypad buzzer prompts the user to disarm the system.
  • Page 34 Digital Security Controls n’approuve aucune modification apportée à l’appareil par l’utilisateur, quelle qu’en soit la nature. Tout changement ou modification peuvent annuler le droit d’utilisation de l’appareil par l’utilisateur. ISED CANADA INTERFERENCE STATEMENT This device complies with Part 15 of the FCC Rules and ISED Canada licence-exempt RSS standard(s). Operation is sub- ject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any inter- ference, including interference that may cause undesired operation of the device.

  • Page 35: Available Zone Attributes

    The modular transmitter 3G7090 or LT7090 is labeled with its own FCC ID and IC number. When the module is installed inside the host device WS900-19 or WS900- 29 and the FCC ID/IC of the module is not visible, the host device displays the provided label referring to the FCC ID and IC of the enclosed module.

  • Page 36: Diagnostics - Read Only

    4.10 Diagnostics - Read Only Radio Version# This section displays the software version of the cellular radio. Primary Telephone Number This section displays the cellular telephone number of the SIM. IMEI number This section displays the unique 15-digit International Mobile Equipment Identity (IMEI) of the radio. The format of the IMEI is: Reporting Body Identifier (2 digits), Allocation Number (4 digits);...

  • Page 37: Network

    Placement Test This test is used to determine the RF signal status for wireless devices and can be performed on the installer portal or at the individual device. For instructions on placement testing at the device, refer to the installation sheet included with the wire- less equipment.

  • Page 38: Section 5: Troubleshooting

    Section 5: Troubleshooting Section 5: Troubleshooting 5.1 Testing Power up the system Program options as required (see programming section) Trip then restore zones Verify correct reporting codes are sent to the central monitoring station 5.2 Viewing Troubles from the Integrated Keypad 1.
  • Page 39 Section 5: Troubleshooting Not Networked 1-128 Fire/CO Trouble 1-128 Siren Future Use 1-16 Battery Trouble 1-16 Tamper 1-16 Fault (Supervision) 1-16 Not Networked 1-16 Keypad Battery Trouble Tamper Fault (Supervision) Not Networked Repeater Battery Trouble Tamper Fault (Supervision) Not Networked RF Jam Wireless Key Future Use...

  • Page 40: Appendix 8: Reporting Codes

    Appendix 8: Reporting Codes Appendix 8: Reporting Codes The following tables contain Contact ID and Automatic SIA format reporting codes. Contact ID Each of the digits indicate specific information about the signal. For example, if zone 1 is an entry/exit point, the event code contains [34].
  • Page 41 Appendix 8: Reporting Codes Section # Definition Dialer Dir- Automatic Contact ID SIA Auto Rep Codes** ection* Codes Sensor trouble/restore MA/R E(3)8A-ZZZ UT-ZZZZ / UJ-ZZZZ R(3)8A-ZZZ Sensor bypass/restore MA/R E(5)7A-ZZZ UB-ZZZZ / UU-ZZZZ R(5)7A-ZZZ Heat or probe trouble/restore MA/R E(3)8A-ZZZ KT-ZZZZ / KJ-ZZZZ R(3)8A-ZZZ Freeze ESM module/restore...
  • Page 42 Appendix 8: Reporting Codes Zone Definition SIA Auto Rep Codes Contact ID Auto Rep Codes Delay 1 BA-ZZZZ / BH-ZZZZ E(1) 3A - ZZZ / R(1)3A- ZZZ Delay 2 BA-ZZZZ / BH-ZZZZ E(1) 3A - ZZZ / R(1)3A- ZZZ Instant BA-ZZZZ / BH-ZZZZ E(1) 3A - ZZZ / R(1)3A- ZZZ Interior...

  • Page 43: Appendix 1: Guidelines For Locating Smoke Detectors And Co Detectors

    Appendix 1: Guidelines for Locating Smoke Detectors and CO Detectors Appendix 1: Guidelines for Locating Smoke Detectors and CO Detectors The following information is for general guidance only and it is recommended that local fire codes and regulations be con- sulted when locating and installing smoke and CO alarms.
  • Page 44 Appendix 1: Guidelines for Locating Smoke Detectors and CO Detectors Figure 3a Figure 4 Carbon Monoxide Detectors Carbon monoxide is colorless, odorless, tasteless, and very toxic. It also moves freely in the air. CO detectors can measure the concentration and sound a loud alarm before a potentially harmful level is reached. The human body is most vulnerable to the effects of CO gas during sleeping hours;...
  • Page 45 Appendix 1: Guidelines for Locating Smoke Detectors and CO Detectors Make sure that all border doors and windows are easily opened. Ensure that they are not painted shut, and that their locking mechanisms operate smoothly. If opening or using the exit is too difficult for children, the elderly or handicapped, plans for rescue should be developed.

  • Page 46: Appendix 2: Regulatory Information

    Appendix 2: Regulatory Information Appendix 2: Regulatory Information This product has been tested and found in compliance with the following standards: UL1023 Household Burglar-Alarm System Units UL985 Household Fire Warning System Units ULC-S545-02 Residential Fire Warning System Control Units ORD-C1023-1974 Household Burglar-Alarm System Units This product has also been tested and found in compliance with the ANSI/SIA CP-01-2014 Control Panel Standard –...
  • Page 47 Appendix 2: Regulatory Information Programming The notes in the programming sections describing the system configurations for UL/ULC listed installations shall be imple- mented. Bell Location The alarm sounding device (bell) shall be located where it can be heard by the person operating the security system during the daily arming and disarming cycle.
  • Page 48 Appendix 2: Regulatory Information FCC/ISED CANADA WIRELESS NOTICE This equipment complies with FCC and ISED Canada radiation exposure limits set forth for an uncontrolled environment. The antenna should be installed and operated with minimum distance of 20 m between the radiator and your body. Antenna gain must be below: Frequency band 3G7090...
  • Page 49 SIA False Alarm Reduction Installations: Quick Reference Caution Fire Alarm Verification feature (Auto Verified Fire Zone) is supported on the DSC Wireless Smoke Detector, Model PGx916 and PGx926. The fire alarm delay is 40s. Notes: Programming at installation may be subordinate to other UL requirements for the intended application.
  • Page 50 SIA Feature Comments Range/Default Requirement Programming Section Cancel Annunciation Access to the reporting code for Alarm Annunciate that a Cancel Required Canceled was transmitted. Default: Panel Settings>Panel Con- Enabled figuration>System Configuration> > Reporting Duress Feature Do not derive code from an existing No automatic derivative of Allowed Master/User code (e.g., Master code is...

  • Page 51: Appendix 3: Eula

    You may not make any changes or modifications to the Software, without the written per- INCLUDING CUSTOMERS, AND INJURY TO PROPERTY. mission of an officer of DSC. You may not remove any proprietary notices, marks or labels from DSC recommends that the entire system be completely tested on a regular basis. However, des- the Software Product.

  • Page 52: Appendix 4: Limited Warranty

    DSC. Custom products are only warranted to the extent that they do not function upon delivery. In such cases, DSC can replace or credit at its option.
  • Page 53 24EU,WS901-18,WS901-28,WS911-18,WS911-28,and 3G7090-EU. The full textofthe EU declarations ofconformity for the models mentioned below are available atthe following internet addresses: A security system must be installed properly in order to provide adequate protection. Every install- Model WS901-14:http://dsc.com/pdf/1707001 Model WS901-24EU:http://dsc.com/pdf/1707002 Model WS901-18:http://dsc.com/pdf/1707003 ation should be evaluated by a security professional to ensure that all access points and areas are Model:WS901-28:http://dsc.com/pdf/1707004...
  • Page 54 Product offerings and specifications are subject to change without notice. Actual products may vary from photos. Not all products include all features. Availability varies by region; contact your sales representative. © 2018 Tyco Security Products All Rights Reserved. Tech Support: 1-800-387-3630 (Canada & U.S.) or 905-760-3000 www.dsc.com...
