    1. Introduction Preface The WP Panel is a highly advanced wireless alarm control system produced by DSC. Note: Make sure that you have the name and telephone number of the monitoring station your system will report to. When calling the monitoring station to ask questions, you should have access to your "ACCOUNT NUMBER"...

  • Page 4: Wp Panel Panel Indicator And Controls

    Arm (Red): Lights when the system is in the armed state. Chime (Green): Chime zones will chime when disturbed (see Chapter 2). Trouble (Orange): Lights when the system is in a state of trouble (see Chapter 5). Control Keys Indication Function D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 5: Arming Keys

    Press both buttons simultaneously for panic alarm WP Panel Panel Indicator and Controls Figure 1b. WP Panel Controls and Indicators LED Indicators Indication Function Power (Green): Indicates that your system is properly connected to the power outlet. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 6: Control Keys

    * May not be functional on all versions of WP Panel. ** The Mute Speaker button is active only if the "Set Voice Option" function is enabled (see Chapter 6, section B.14). Refers to WP8030 with voice option only D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 7: Built-In Alarm Sounder

    The normal display alternates with the time and the system status, for example: READY HH:MM (alternating) READY MEMORY Refers to WP8030 with voice option only D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 8: Screen Saver Mode

    (see Chapters 2 and 6, B.7 Add / Delete Keyfob Transmitters). The Duress Code enables you to disarm the system using a special code that sends a silent alarm to the monitoring station (See chapter 2). D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 9: Operating The Wp Panel System

    Disarming and Stopping Alarm Enter the protected premises via a delayed zone. Upon detecting your entrance, the system will start sounding the entry delay beeps alerting you to disarm the system before the entry delay ends. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 10: Disarming Under Duress

    ENTER CODE _ _ _ _ [Enter code] / Code / Present tag [Present tag] ARMING HOME  (Exit delay)  Move to interior zone ARM HOME HH:MM ARM indicator flashes during the armed state. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 11: Arming Away Or Home „Instant

    Code / Present tag [Present tag] ARMING AWAY PLEASE EXIT NOW   (Exit delay) (to mute the buzzer) AWAY Vacate the premises ARM indicator lights during the armed state. Remember: Forced arming compromises security!! D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 12: Arming In The Latchkey Mode

    You can generate a panic alarm manually in the disarmed and armed states. The sequence will be as shown: PRESS RESULTING DISPLAY PANIC ALARM simultaneously READY HH:MM To stop the alarm, press the button and then key in your valid user code. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 13: Initiating Fire Alarm Or Emergency Alarm

    (assuming that the volume was at minimum/maximum to begin with). PRESS RESULTING DISPLAY PRESS RESULTING DISPLAY VOLUME+ (max) VOLUME– VOLUME+ VOLUME– VOLUME+ VOLUME– (max) VOLUME+ VOLUME– This function is disabled in ACPO compliant version Refers to WP8030 with voice option only D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 14: Speech And Sound Control

    ACTION RESULTING DISPLAY RECORD A MESSAGE (constant) Talk  TALK NOW Talk  TALK NOW Talk  TALK NOW Talk  TALK NOW Talk  TALK NOW Refers to WP8030 with voice option only D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 15: Message Playback

    PLAY will be displayed and the message will be played back over the built-in loudspeaker. When the playback ends, the display will revert to the normal status-displaying mode. If more than 1 minute elapsed after recording, the MSG indication will disappear. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 16: Electrical Appliance Control

    If not satisfied - press BY TIMER OFF If satisfied - press BY TIMER OFF BY SENSOR ON BY SENSOR OFF If not satisfied - Press BY SENSOR OFF If satisfied - BY SENSOR OFF READY HH:MM D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 17: Reviewing Troubles And Alarm Memory

    TRBL message is displayed, as follows. READY HH:MM NOT READY HH:MM (alternating) (alternating) READY TRBL NOT READY TRBL or, if the system is not ready for arming D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 18: General Indications

    If a PIR camera is enrolled in the system, the control panel will read "GPRS initialize" to indicate that the modem is undergoing initialization. This message appears at the end of all trouble messages and immediately following the GSM signal strength indication (if a SIM card is installed). D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 19: Correcting Trouble Situations

    There is no power to the siren TAMPER OPEN The sensor has an open tamper TROUBLE The sensor reports trouble SOAK TEST FAIL Detector alarms when in Soak Test mode Soak Test is not applicable for UL installations D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 20: Menus And Functions

    The bypass options will be displayed in the User Settings menu only if enabled by the installer. Otherwise, the USER CODES first User Settings option displayed will be [ C. User Settings Options Menu D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 21 SERIAL NUMBER Use to exit from the “USER SETTINGS” menu back to Main Menu. For further <OK> TO EXIT details see section A.2. Returns to first option Duress Code is not applicable for UL installations D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 22: Returning To The Previous Step Or Exiting The User Settings Menu

    To repeat (recall) the last used zone bypassing scheme – refer to section B.3. Note: For UL Listed Product, zone bypassing must be conducted on an individual basis each time the system is armed. D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 23 To clear the bypassed zone, press the button. A "Happy Tune" ☺ sounds and the updated zone status is now displayed,  Z04: READY Z04: READY Z04: NOT READY i.e. [ ] or [ D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 24: Reviewing The Zone Bypass Scheme

    You can now repeat steps 2 - 5 to bypass or clear another zone. To end this session and to select other menu options or to quit programming - follow the instructions in section A.2. You can now select another option in the User Settings menu (see section A.1), or quit programming (see section A.2). D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 25: Programming User Codes

    Any attempt to program it will be rejected by the system. 4. Carefully read the section titled "Additional Information" according to the indicated references etc – see table at end of this section. D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 26 This setting can be performed only after completing steps 1 - 5 of section B.4A.  symbol now appears next to the newly selected Partitions. You can now repeat steps 3 - 7 to program or edit another user code. When PARTITIONING is enabled. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 27: Programming The Duress Code

    ENTR ID:xxx-xxxx Present the proximity tag to the control panel within the timeout period. If enrollment was successfully completed, a "Happy Tune" ☺ sounds and DEVICE ENROLLED Duress Code is not applicable for UL installations D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 28 To delete the tag press the button. DELETE TAG A "Happy Tune" ☺ sounds and the display reads [ ] and DELETE TAG returns to step 3. ☺ Go to step 3   When PARTITIONING is enabled. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 29: Add / Delete Keyfob Transmitters

    B: ENROLLMENT BY DEVICE ID: Enter the 7-digit number that appears on ID No. 300-5786 the keyfob sticker and then press to confirm. To complete the enrollment procedure, see Note 9 in the Additional Information table below. D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 30 When the keyfob you wish to delete appears on the display, press ID No. 300-6108 The display now reads [<OFF> TO DELETE]. <OFF> to delete To delete the keyfob press the button. ☺ Go to step 3   When PARTITIONING is enabled. D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 31 You can now repeat steps 2 - 7 to program or edit another keyfob. To abort the procedure, press the button. You can now add or delete another keyfob, select another option in the User Settings menu or quit programming (see sections A.1 A.2). D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 32: Setting The Time & Time Format

    The time saved is displayed without the cursor, for example, " " followed by the selected time format. You can now select another option in the User Settings menu (see section A.1 and section A.2), or quit programming (see section A.3). D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 33: Setting The Date & Date Format

    You can now select another option in the User Settings menu (see section A.1 and section A.2), or quit programming (see section A.3). This setting can be performed only after completing steps 1 – 3 of section B.9A. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 34: Enabling / Disabling Auto-Arming

    The saved auto arm time is displayed without the cursor, for example, " ". You can now select another option in the User Settings menu (see section A.1 and section A.2), or quit programming (see section A.3). D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 35: Programming Private Phone, Email, Mms And Sms Reporting

    A "Happy Tune"  sounds. The display confirms the set events to be alarms  5, 15 reported, and returns to step 3. ☺ Return to step 3   Refers to WP8030 with voice option only D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 36 The display confirms the desired two-way voice disable two-way  5, 15 communication method and returns to step 15. ☺ Return to step 15   Refers to WP8030 with voice option only D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 37 6, 7 keypad. When done, press to confirm. ☺ A "Happy Tune"  sounds, the display confirms the SMS phone number 8032759333 8, 15 and returns to step 8. ☺ Return to step 8  D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 38 When the display reads [Address], press To program or edit the email, at the blinking cursor position enter the Email, info@DSC.com 6, 7 for example, “info@DSC.com”, using the alphanumerical keypad. When done, press to confirm. ☺ A "Happy Tune" ...
  • Page 39 [2nd SMS/MMS], and press 2nd SMS/MMS The display reads [Telephone num.]. Telephone num. Click the button repeatedly until the display reads [MMS Events]. MMS Events Press the button. D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 40 All messages, except alerts alarms Alarm messages only alerts Alert messages only op/cl Arming and disarming (Open/close) only Note: “ ” means all events including the L. BAT and AC FAIL trouble messages (WP Panel only). D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 41 Trouble messages only trouble+o/c Trouble messages, including arming & disarming open/close Arming and disarming (open/close) only  The display shows the currently selected option (indicated by a symbol), for example, " disable report ". D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 42: Enabling / Disabling The Squawk Option

    Scheduler table (placed at the end of this section) before programming the Scheduler. Carefully read the section titled "Additional Information" according to the indicated references etc – see  table at end of this section. A. To Set the Scheduler D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 43 ☺ A "Happy Tune"  sounds. The display confirms the saved stop time and ☺ Return to step 5  returns to the "operation No" screen, as in step 5. Additional Information (section B.14) D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 44 _ _: _ _ _ _: _ _ _ _: _ _ _ _: _ _ OFF: _ _: _ _ OFF: _ _: _ _ OFF: _ _: _ _ OFF: _ _: _ _ D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 45: Volume Control

    When you are satisfied with the setting, press to confirm. A "Happy Tune" ☺ sounds. The display confirms the saved setting, then  4, 8 returns to step 6. ☺ Return to step 6  D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 46 When you are satisfied with the setting, press to confirm. A "Happy Tune" ☺ sounds. The display confirms the saved setting, then  4, 8 returns to step 18. ☺ Return to step 18  D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 47 (see Chapter 2 - Adjusting the Speech Volume and the Volume of the Keypad Beeps). You can now select another option in the User Settings menu (see section A.1 and section A.2), or quit programming (see section A.3). D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 48: Serial Number

    To end this session and return to previous menu options, press the button. You can now select another option in the User Settings menu (see section A.1 and section A.2), or quit programming (see section A.3). D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 49: Event Reporting And Control By Telephone And Sms

    Acknowledge and request a status report: The WP Panel will issue a verbal report of system status. For example: [Disarm - ready to arm] or [Disarm - back door open] or [Disarm - alarm in memory]. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 50: Event Notifications By Sms

    []  [4]  [#] []  [0]  [partition]  [4]  [#] Arming Away-Instant-Latchkey []  [4] [ 1]  [#] []  [0]  [partition]  [4] [ 1]  [#] D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 51 ] and then key your user code followed by the command (see “keying sequences” in Executable Commands table above). Refers to WP8030 with voice option only Operates on all permitted partition(s) Refers to WP8030 with voice option only D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 52: Remote Control By Sms

    Note: The WP Panel may react with a delay to received SMS messages if a GPRS session is in progress at the same time. Refers to WP8030 only House ID includes up to 16 characters, for example, JOHN'S HOUSE D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 53: Special Applications And Functions

    A. Press AWAY twice to arm the system. B. Press AWAY and then press disarm button. Performing either of these two actions will also store the acknowledge message in the event log. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 54: Testing The System

    C. To Display the Temperature TEMPERATURE TEST The display now reads [TEMPERATURE TEST]. To display the temperature of zones on the control panel, press The control panel reads the temperature of each zone. The display alternates Z01 24.5C D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 55 Three seconds after the device is displayed, the device LED blinks to assist you to identify ("it's me"). b. To end the session, press the button until the display reads [<OK> TO EXIT] then press D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 56: Periodic Test Per Partition

    Periodic test per partition will be interrupted (the panel returns to selected partition display) upon occurrence of one of the following: 1) Disarm event by keyfob, keypad or pendant assigned to a selected partition; 2) PANIC, FIRE or EMERGENCY event. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 57: Maintenance

    Note: Up to 250 events (WP8010) / 1000 events (WP8030) are stored in the event log that can be reviewed via the Remote Programmer PC software application or by the remote PowerManage server.

  • Page 58: Exiting The Event Log

    Click the button from anywhere within the event log. The WP Panel display will read [<OK> TO EXIT]. <OK> TO EXIT Click the button. READY 00:00 The system reverts to the normal operating mode. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 59: Appendix A. Functions Of Controlling Devices

    Zone Status when working with Partitions Alarms Response Notes Upon each press of the key, the next zone number For NOT READY ( assigned to the pressed Partition number appears on the BYPASSED ( D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 60: A2. Wk141 (868-3:037)

    (see Note) PG2 User's alarm PG2 User's ( 2 sec.) Guide, “Panel Guide. Response to STATUS See section Keypad indication 3.6 of KP-140 Commands” Fire alarm ( 2 sec.) PG2 User's section 3.5 Guide. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 61: A3. Pgx9939

    LATCHKEY ready", the red LED lights steadily and a "sad tune" is PGx9939 User's Guide, “Panel heard Response to Keyfob Commands” section 3.2. Panic alarm ( 2 sec.) See section 2.2 of PGx9939User's Guide. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 62: Appendix B. Partitioning

    Press repeatedly to view memory / status content. Note: After 5 seconds of no button press there will be a timeout and the display will revert to the all partition display. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 63: B4. Siren

    / disarmed directly. Common areas are created when you assign a zone or zones to 2 or 3 partitions. Table A1 summarizes the behavior of the different zone types in a common area. D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 64  Acts as a Delay type when at least one of the assigned partitions is armed HOME.  Will be ignored when at least one of the assigned partitions is disarmed. Emergency; Fire; Flood;  Always armed. Gas; Temperature; 24-hour silent; 24-hour audible; Non-alarm D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 65: Appendix C. Glossary

    Bypassed zones will not be protected throughout the arming period. Even if restored to normal (closed), bypassed zones will remain unprotected until the system is disarmed. Permission to “force arm” is given or denied by the installer while programming the system. D-306232 WP8010/WP8030 V18 DSC EN USER...
  • Page 66 Instant and delay zones are “on watch” only when the control panel is armed, and other (24-hour) zones are “on watch” regardless of whether the system is armed or not. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 67: Appendix D. Home Fire Escape Planning

    Tell guests or visitors to your home about your family‟s fire escape plan. When visiting other people‟s home, ask about their escape plan. If they don‟t have a plan in place, offer to help them make one. This is especially important when children are permitted to attend “sleepovers” at friends' homes. D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 68: Appendix E. Specifications

    - Two-way voice communication enabled in UL Listed product. Note: Tracking inactivity of elderly not to be enabled in UL Listed product. Data Retrieval Alarm memory, trouble, event log Alarm memory, trouble, event log D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 69: E2. Wireless

    GP220AAH4YMX, manufactured load 22 by GP or p/n LTT-2300AA4Y, manufactured hours by LTT. For UL Listed product, use these no backup 0 mA 10 mA batteries only. no backup no backup 0 mA D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 70: E4. Communication

    Via RS232 serial port Local Computer Report 2 Monitoring Stations, 4 private telephones 2 Monitoring Stations, 4 private telephones Destinations Reporting Format SIA, Contact ID, Scancom, SIA IP, DSC SIA, Contact ID, Scancom, SIA IP, DSC D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 71: E5. Physical Properties

    According to EN 50131-1:2006 and A1:2009, this equipment can be applied in installed systems up to and including Security Grade 2.  EN 50131-1 Environmental Class Class II USA: CFR 47 Part 22 (GSM850) and Part 24 (GSM 1900). D-306232 WP8010/WP8030 V18 DSC EN USER...

  • Page 72: Fcc Statement

    Directive 2002/96/EC Waste Electrical and Electronic Equipment. ©2016 Tyco International Ltd. and its Respective Companies. All Rights Reserved. Toronto, Canada www.dsc.com Printed in Israel WP8010/WP8030 V18 DSC EN USER D-306232 Rev 1(4/16) D-306232 WP8010/WP8030 V18 DSC EN USER...
