5.6. Characteristics of standard interfaces.

Parameter, characteristics
Standards for interfaces with PC
Bit depth of program data word
Data transmission speed
•
via USB on input and output
•
via Ethernet on input
•
via Ethernet on output
Interface with a computer
Main interface of input-output for ADC, DAC, digital I/O
Main control interface
A number of auxiliary I/O ports for connection with FPGA
SDRAM interface
Debugging interface
Compatibility with JTAG emulators Analog Devices
Interface with a computer
Interfaces of ADSP-BF523 (E-502-P) signal processor
Value, description
USB 2.0
100BASE-TX
32 bits
5 Mwords/s
2.5 Mwords/s
To be confirmed
HOST DMA 16 bits
SPORT0, >120 Mbit/s, duplex
SPI
32 MB; 16 bit; 132.5 MHz
JTAG
ADZS-ICE-100B,
ADZS-USB-ICE,
ADZS-HPUSB-ICE.
