Table 4-1: Connector Analog

Signal name Commo
n point
X<1...16> AGND
Y<1...16> AGND
4
The common wire circuit for the specified signal input or output
Y16
20
Y15
21
Y14
22
Y13
23
Y12
24
Y11
25
Y10
26
Y9
27
Y8
28
Y7
29
Y6
30
Y5
31
Y4
32
Y3
33
Y2
34
Y1
35
GND32
36
DI_SYN1
37

Fig. 4-3: Connector Analog

Direction
4
• Non-inverting channel voltage input 1 ... 16 for differential and
Input
"common ground" mode:
• Operation voltage range: ±10 V (see the details in section
• Unused inputs X <1 ... 16> are recommended to be connected to
AGND or the corresponding physical channel not to be interrogated
programmatically.
• Inverting channel voltage input 1 ... 16 for differential mode.
Input
• Input channels 17 ... 32 for the mode "with common ground".
• Operation voltage range: ±10 V (see the details in section
• Unused inputs X <1 ... 16> are recommended to be connected to
AGND or the corresponding physical channel not to be interrogated
programmatically.
GND
X16
1
X15
2
X14
3
X13
4
X12
5
X11
6
X10
7
X9
8
X8
9
X7
10
X6
11
X5
12
X4
13
X3
14
X2
15
X1
16
AGND
17
DAC1 / +15V / AGND / NC
18
DAC2 / -15V / DGND / NC
19
Description
4.6 p. 41).
4.6 p. 41).
