Chapter 4. Toolchest Components

Dual Bus Mapper

Each dual bus will require a separate instance of the DBUS function block. In this case the block refers to the
first dual bus. The name DB00 relates to the first bus.

Figure 11: Edit Block for Mapping Each Dual Bus

Note the bus variable on the left side of the function block. This passes the configuration parameters (that
were set by INIT_GB00, or INIT_GBnn) into the dual bus mapping logic.
16 PACSystems* RX3i Genius Dual Bus Application Guide GFK-2928
