Assembly Instructions

optoCONTROL
Functions
•
Edge measurement with the shadow principle (Edge low-high; edge high-low)
•
Measurement of diameter-, width-, gap incl. center axis
•
Counting of edges or segments, any segment situations or widths; calculation of the center
axes between edges
•
Trigger, synchronization and further functions
•
RS422, Ethernet or EtherCAT interface, transfer of sveral measuring values to the PC
•
Measuring rate 2.5 kHz
Warnings
Connect the power supply according to the safety regulations for electrical operating equipment.
Supply voltage must not exceed specified limits.
> Danger of injury, damage to or destruction of the sensor
Protect cables against damage.
> Failure of the measuring device
Avoid shock and vibration to the light source and the receiver.
> Danger of injury, damage to or destruction of the sensor
Notes on CE Identification
The following applies to the optoCONTROL 2520: EMC
regulation 2004/108/EC
The sensor satisfies the requirements according to the
standards
EN 61000-6-3 / EN 61326-1 (class B) emitted interference
EN 61000-6-2 / EN 61326-1 interference immunity
Proper Environment
Protection class:
Operating temperature: +5 ... +50 °C
Storage temperature:
optoCONTROL 2520
2520
IP 64 applies only with connected cable (with protective cap on Ethernet
connector)
-20 ... +70 °C
