HYDRAULIC SCHEMATIC

SUPER CHARGE
RELIEF VALVE
150 PSI.
AUTO.
VALVE
LOW PRESSURE
UNLOADING VALVE
425 PSI.
42
MAX. PRESSURE
SAFETY RELIEF VALVE
10,400 PSI.
OPTIONAL
EXTERNAL PSI REGULATOR
9,800 PSI.
TO VALVE
