SPX FLOW Power Team PB102-1 Parts List And Operating Instructions page 29

Parts List continued
ITEM PART NO.
1001029
1001030
1001031
32
1001054
1001055
1001143
33 1001053
1001058
1001036
1001037
34
1001057
1001038
1001144
35 2001397
36 2001467
37 2001486
38 2007914
39 2008866
40 2009627
41 2009628
42 2009629
43 2009630
44 2009631
45 2009632
46 2009633
47 2009634
48 2009635
49 2009636
50 2009637
51 2009638
52 2009640
53 2009649
54 2009650
55 2009652
56 2009656
57 2010059
58 3000989
2009646
59
2009647
© SPX FLOW, Inc.
DESCRIPTION
DECAL, PLAS CERT CE US RECT 4.25IN
DECAL, PLAS CERT CE US RECT 4.25IN
DECAL, PLAS CERT CE US RECT 4.25IN
DECAL, PLAS CERT CE US RECT 4.25IN
DECAL, PLAS CERT CE US RECT 4.25IN
DECAL, PLAS CERT CE US RECT 4.25IN
DECAL, PLAS LOGO PTEM US RECT 10.7IN
DECAL, PLAS CERT CE US RECT 1.73IN
DECAL, PLAS CERT CE US RECT 1.73IN
DECAL, PLAS CERT CE US RECT 1.73IN
DECAL, PLAS CERT CE US RECT 1.73IN
DECAL, PLAS CERT CE US RECT 1.73IN
DECAL, PLAS CERT CE US RECT 1.73IN
SPACER, BLADDER
TERMINAL,QUICK DISCONNECT FEMALE
TERMINAL, QUICK DISCONNECT, FEMALE
TERMINAL,QUICK DISCONNECT - FEM 18-22AWG
TERMINAL, ADAPTOR, SLOT TO .25 SPADE
M18 ODM ADAPTOR - HD V1030
BATTERY, 9.0 AMP, Li-ION TYPE
SCREW, #8-32UNC 0.75 IN PNH 2 ST BOX
GASKET, 3.80INx2.60x0.06xPU 70
SWITCH, ROCKER OFF - (ON) MOMENTARY
HANDLE - RUBBER, RETAINER PLUG, THIN BODY
PLUG, CAP 0.625IN D-FLATS NYLON6-6
HOUSING, HYD. PUMP RND MTR, MACH
FUSE, AUTO RESET 30AMP DUAL 1/4" FASTON
RELAY, SSR OPR 1-60VDC, CTRL4-32VDC, 40A
PLATE, RECT ADPTx0.1INx2.0x3.5 AL
SCREW, #6-32UNC 0.5 IN CSK 4 ST ZN
NUT, 8-32UNFx0.75IN LCK ST ZN
ASSY, HARNESS, STRAP, CLIP, MOUNT
CLAMP, HOSE 3.70-4.13 SCREW DRIVE
CONNECTOR, 4 PIN 18GA FEM NIBR
DIODE, SUPPRESSION 600V, 1N4005
CAPACITOR, 0.068 MICRO FARAD CLASS X2
REMOTE PUMP HAND SWITCH ASSEMBLY
CHARGER, LI-ION BATTERY 120VAC
CHARGER, LI-ION BATTERY 240VAC
(USED ON PB102P)
(USED ON PB102R)
(USED ON PB102A)
(USED ON PB102)
(USED ON PB104)
(USED ON PB102-CP)
(USED ON PB102P)
(USED ON PB102R)
(USED ON PB102A)
(USED ON PB102)
(USED ON PB104)
(USED ON PB102-CP)
(INCLUDED WITH PB102P)
(USED WITH PB10XX-1 MODELS)
(USED WITH PB10XX-2 MODELS)
29
QTY.
1
1
1
1
1
1
2
1
1
1
1
1
1
1
7
2
1
6
1
1
4
1
1
1
1
1
1
1
1
2
4
1
1
1
1
1
1
1
1
Form No. 1001044
Rev. 2 Jan. 25, 2019
