Pb102A-2 - SPX FLOW Power Team PB102-1 Parts List And Operating Instructions

Parts List continued
ITEM PART NO.
1 10268
2 10394
10855
3 251077
251078
4 11863
5 12313
6 12355
7 12515
8 12747
9 12747
10 12747
11 13324
12 13755
13 14456
14 15468
15 16811
16 65187-18
17 201373
18 202505
19 207405
20 211060
21 251039
22 251041
23 251043
24 251280
25 252871
26 350583
350622
420558
27 350623
350720
3001123
28 420607
29 420643
30 1000413
31 1001026
© SPX FLOW, Inc.
DESCRIPTION
O-RING (-012) 0.316 ID x 0.070 NITRILE 70
AND 350623)
NUT, JAM, 5/8-18 UNF
SCREW, SCKT HD CAP - 1/4-20 x 2.75
SCREW, SHC 1/4-20 X 4.75
SCREW, SHC 1/4-20 X 3.25
WASHER, BACKUP 0.50 x 0.375
CABLE TIE, NON-RELEASABLE
WASHER, PLAIN 0.44 X 0.19 X 0.05 STEEL
SCREW, RND 10-24 X 1.75
WIRE, 14GA XXIN RED
WIRE, 14GA XXIN RED
WIRE, 14GA XXIN RED
WASHER, PLAIN 1.330 x0.660
O-RING (-905) 0.414ID X 0.072 NITRILE 90
SCREW, HEX WSH #10-24 X 0.50 TAPPING
SCREW, #6-32UNC 0.375 IN PNH-ST ZN
SCREW, #10-32 X 0.50 BHCS
PUMP SUBASSY, ELECTRIC 18VDC
WASHER, RETAINER 1.000 x0.750
BUSHING
(INCLUDED WITH VALVE 420558 AND 350623)
LOCKNUT, HEX: #10-24 FLEXIBLE LOCKING
SCREW, HEX. WASHER HD.TAPPING - #9-15 x 1 PLASTITE
STRAP, MOTOR MOUNTING
CHANNEL, RUBBER
RING, RETAIN EXT 0.62 X .050
PLUG, O RING BOSS: 1/2-20 UNF
NUT, HEX ACORN CAP #10-32
ADAPTER, FILLER
VALVE, MANUAL, 2 POSITION, 2 -WAY
VALVE, MANUAL (3-POSITION, 4-WAY)
BODY, VALVE (PRESSURE REGULATOR)
MANIFOLD ASSEMBLY
MANIFOLD ASSEMBLY
PLATE, BASE
BLADDER
LABEL, WEEE (WHEELIE BIN)
DECAL, PLAS SAFE INST US RECT 4.90IN
(INCLUDED WITH VALVE 420558
(USED ON PB102R)
(USED ON PB102-CP)
(INCLUDED WITH VALVE 420558 AND 350623)
(USED ON PB102, PB102P, PB102R)
(USED ON PB104)
(USED ON PB102R)
(USED ON PB102A)
(USED ON PB102-CP)
28
QTY.
2
1
2
2
2
2
1
6
4
1
1
1
1
1
2
2
2
1
1
1
4
2
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
Form No. 1001044
Rev. 2 Jan. 25, 2019
