350622 (Valve, Manual, 2-Position 2-Way) - SPX FLOW Power Team PB102-1 Parts List And Operating Instructions

Parts List continued
11
4
10
ITEM NO. PART NO.
1 58351
2 213109
3 15085
4 11088
5 20771
6 10425
7 350626
8 10267
9 11418
10 11127
11 10909
12 251279
13 10556
14 251512
15 251472
© SPX FLOW, Inc.
(Valve, Manual, 2-position, 2-Way)
14
6
5
3X 12
DESCRIPTION
BODY, VALVE, 2 WAY
HANDLE, RELEASE VALVE
WASHER, BACK-UP: 0.438 x 0.312
RING, RETAINING - INTERNAL
POPPET
SPRING, COMPRESSION
SCREW, RELEASE VALVE
ORING -011 0.301X0.07X0.441IN NBR 70
PIN, SLOTTED SPRING STANDARD DUTY
FITTING, PLUG 3/8 NPTF W/SEALANT
FITTING, PLUG - 3/8 NPTF M FLUSH
FITTING, PLUG 1/8 PTF
SCREW, 1/4-20 SET LOCK
DECAL, TELEPHONE INFORMATION
DECAL, WARNING
350622
15
1
7
2
34
9
2X
8
3
Form No. 1001044
Rev. 2 Jan. 25, 2019
13
QTY.
1
1
1
1
1
1
1
1
2
1
1
3
2
1
1
