Network Appliance
Platform
NCA-5710
User Manual
Version: 1.2
Date of Release:2019-06-11
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NCA-5710 and is the answer not in the manual?

Questions and answers

Related Manuals for Lanner NCA-5710

Summary of Contents for Lanner NCA-5710

  • Page 1 Network Appliance Platform NCA-5710 User Manual Version: 1.2 Date of Release:2019-06-11...
  • Page 2 - assumed to be qualified in the servicing of computer equipment, such as professional system integrators, or service personnel and technicians. The latest version of this document can be found on Lanner’s official website, available either through the product page or through the Lanner Download Center page with a login account and password.
  • Page 3 For troubleshooting the issues with your system, please visit the Lanner Q&A page for diagnostic procedures and troubleshooting steps. In addition to contacting your distributor or sales representative, you could submit a request to our Lanner Technical Support at http://www.lannerinc.com/technical-support where you can fill in a support ticket to our technical support department.
  • Page 4 Taiwan Corporate Headquarters China Lanner Electronics Inc. Beijing L&S Lancom Platform Tech. Co., Ltd. 7F, No.173, Sec.2, Datong Rd. Xizhi District, Guodong LOFT 9 Layer No. 9 Huinan Road, New Taipei City 22184, Taiwan Huilongguan Town, Changping District, Beijing 102208 China...
  • Page 5 NCA-5710 User Manual This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communications.
  • Page 6 Follow these guidelines to ensure general safety: Keep the chassis area clear and dust-free during and after installation. Do not wear loose clothing or jewelry that could get caught in the chassis. Fasten your tie or scarf and roll up your sleeves. Wear safety glasses if you are working under any conditions that might be hazardous to your eyes.
  • Page 7 NCA-5710 User Manual Leaving a battery in an extremely high temperature environment can result in an explosion or the leakage of flammable liquid or gas. A battery subjected to extremely low air pressure may result in an explosion or the leakage of flammable liquid or gas.
  • Page 8 The installation of this product must be performed by trained specialists; otherwise, a non-specialist might create the risk of the system’s falling to the ground or other damages. Lanner Electronics Inc. shall not be held liable for any losses resulting from insufficient strength for supporting the system or use of inappropriate installation components.
  • Page 9 NCA-5710 User Manual Before turning on the device, ground the grounding cable of the equipment. Proper grounding (grounding) is very important to protect the equipment against the harmful effects of external noise and to reduce the risk of electrocution in the event of a lightning strike. To uninstall the equipment, disconnect the ground wire after turning off the power.
  • Page 10 This equipment must be grounded. The power cord for product should be connected to a socket-outlet with earthing connection. Cet équipement doit être mis à la terre. La fiche d'alimentation doit être connectée à une prise de terre correctement câblée Suitable for installation in Information Technology Rooms in accordance with Article 645 of the National Electrical Code and NFPA 75.
  • Page 11 NCA-5710 User Manual Package Content ......................... 13 Ordering Information ......................... 13 System Specifications ......................... 14 Front Panel ..........................15 Rear Panel ........................... 16 Motherboard Information ......................17 Installing the CPU ........................24 Installing the Disk Drive(s) ......................30 Installing the NIC Modules ......................32 Replacing the Cooling Fans ......................
  • Page 12 Why Dual BIOS? ........................121 Addressing BIOS Start-up Failure with Dual BIOS ..............122 Introduction ..........................125 Pre-requisites ........................... 125 Warranty Policy ........................131 RMA Service ..........................131 RMA Service Request Form ...................... 132...
  • Page 13 NCA-5710 User Manual Thank you for choosing NCA-5710. The NCA-5710, powered by Intel® Xeon® Processor Scalable Family and Intel® C627/C621 chipset, features optimized computing power and virtualization capacity in a compact 1U form factor with dual CPU sockets, 4x NIC module slots and up to 384GB DDR4 system memory.

  • Page 14: Chapter 1: Product Overview

    Chapter 1: Product Overview Form Factor 1U 19“ Rackmount Intel® Xeon® Processor Scalable Family Processor Options (Skylake-SP) CPU Socket Platform 2x LGA3647 Chipset Intel® C621/627 Security Acceleration Intel® QuickAssist Technology (By SKU) BIOS AMI SPI Flash BIOS Technology DDR4 2666 MHz REG DIMM System Memory Max.
  • Page 15 NCA-5710 User Manual Description For hardware /software reset, default is software reset. The setting is Reset Button configurable by changing the JRST1 jumper on motherboard. System Power LED Indicators System Status HDD Activity Console Port 1x RJ45 console port USB Ports 2x USB 3.0 port...
  • Page 16 Chapter 1: Product Overview Description Grounding Stud 1x grounding stud for connecting the grounding wire ESD Jack 1x ESD Jack Fans 6 x hot-swappable cooling fans with smart fan Power Switch 1x Power Button Alarm Off Button 1x Alarm Off Button to disable the system alarm Power Supply 2x 850W 1+1 ATX Redundant PSUs...
  • Page 17 NCA-5710 User Manual The block diagram indicates how data flows among components on the motherboard. Please refer to the following figure for your motherboard’s layout design. 6 Channel DDR4 RDIMM 2400 Mhz up to 384GB NCA-5710 Block Diagram Dual BIOS M.2B Key...
  • Page 18 Chapter 1: Product Overview This layout shows the connectors and jumpers on the board, as a reference of the pin assignments and the internal connectors.
  • Page 19 NCA-5710 User Manual JUSB1: USB2.0 Pin No. Description Pin No. Description +P5V_USB1 +P5V_USB1 USB20_L_N3 USB20_L_N4 USB20_L_P3 USB20_L_P4 USBGND1 USBGND1 USBGND1 USBGND1 JTPM1 Pin No. Description Pin No. Description IRQ_SERIAL LPC_LFRAME# LPC_LAD0 CLK_24M_LPC LPC_LAD1 +P3V3_AUX LPC_LAD2 LPC_LAD3 +P3V3 TPM_RST# JVGA1 Pin No.
  • Page 20 Chapter 1: Product Overview JNMI1 Pin No. Description Pin No. Description NMIBTN# JATX2 & JATX4: 8 pin Power Connector Pin No. Description +12V +12V +12V +12V JSATA1~JSATA4: SATA Pin No. Description TX_P TX_N RX_N RX_P JFAN1~6: FAN Connector Pin No. Description PWM Status RPM Sense...
  • Page 21 NCA-5710 User Manual JRST1: Controls the software reset method of the Reset button on front panel. Description Description SW reset HW reset (Default) NGFF1: M.2 Connector B Key...
  • Page 22 Chapter 1: Product Overview JCOMA2: COM PORT Pin No. Description Pin No. Description BMC_COM2_DCD# BMC_COM2_DSR# BMC_COM2_RX BMC_COM2_RTS BMC_COM2_TX BMC_COM2_CTS# BMC_COM2_DTR COM2_GND2 JPMB1: PMBUS Pin No. Description Pin No. Description PSU_TTL1 PSU_TTL2 ATX_PSON# ATXPWGD PMBUS_CLK PMBUS_DAT PMBUS_ALERT# JOPEN1: Case open Pin No. Description Pin No.
  • Page 23 NCA-5710 User Manual JGP1: EXT GPIO header Pin No. Description Pin No. Description GPO_B_1 GPI_B_1 GPO_B_2 GPI_B_2 GPO_B_3 GPI_B_3 GPO_B_4 GPI_B_4 JPWR1: Power on Pin No. Description Pin No. Description ATX_PSON#...

  • Page 24: Chapter 2: Hardware Installation

    Chapter 2: Hardware Installation To reduce the risk of personal injury, electric shock, or damage to the system, please remove all power connections to completely shut down the device. Also, please wear ESD protection gloves when conducting the steps narrated in this chapter. Please note that the system delivered to you is already installed with the processor and that this processor, LGA3647, comes with rather sophisticated design;...
  • Page 25 NCA-5710 User Manual Item Description Please avoid touching the gold fingers or Processor package lands of the processor even if you are wearing ESD gloves. If a TIM (Thermal Interface Material) protective film is already attached to the base of the heat...
  • Page 26 Chapter 2: Hardware Installation 1. Align the PIN1 indicator on the processor with that on the carrier. Gently insert one side of the processor into the carrier and make sure the alignment feature is aligned with the latch of the carrier. Latch Align Note...
  • Page 27 NCA-5710 User Manual 4. Align PIN1 of the processor with the corner cutout of the heat sink (if Cutout there are two corner cutouts on one heat sink, either will do). 5. With a little pressure, push the four corners of the carrier down to...
  • Page 28 Chapter 2: Hardware Installation 2. Flip the PHM over to align PIN1 the carrier with the Cutout of the Cutout bolster plate. 3. Flip the PHM over, so the package Alignment Pin land of the processor will face the socket. Lower the PHM vertically to engage it to the alignment pins of the bolster plate.
  • Page 29 NCA-5710 User Manual Note When fastening #3 and #4 nuts, the gap between the metal spring leaf of the bolster plate and the PHM will gradually diminish as you drive the nuts.
  • Page 30 Chapter 2: Hardware Installation NCA-5710 is built with two 2.5” HDD/SSD slot (HDD preferred) drive bay. The following will discuss disk drive installation procedures based on their HDD/SSD designs. 1. Power off the system. 2. Loosen the screw that fixes the tray onto the motherboard.
  • Page 31 NCA-5710 User Manual 4. Install the tray back to the original position with the screw. Make sure the notch of the tray’s side engages properly into the pin as shown in the picture. 5. Connect the SATA cable and SATA...
  • Page 32 Chapter 2: Hardware Installation NCA-5710 comes with 4 NIC Ethernet module slots for network bandwidth expansion. Please follow the steps for installation. 1. On the front panel, select a NIC Ethernet module slot. 2. Loosen the two lock-screws. 3. Remove the door and locate the socket for module insertion.
  • Page 33 NCA-5710 User Manual 4. Insert your NIC module. (The module shown in the image below is for reference only). Align the golden fingers to the socket on the motherboard carefully while inserting this module. 5. Once the module is firmly seated,...
  • Page 34 Chapter 2: Hardware Installation Cooling fans may wear down eventually. Please refer to the steps below for replacing cooling fans. When using a new cooling fan, simply reverse the steps to install the fan back onto the enclosure and the system. 1.
  • Page 35 NCA-5710 User Manual The motherboard supports 12 memory slots for DDR4 registered DIMM. JCPU0 requires at least 1 memory module to boot and run from. Total Slots 12 (6 slots per processor) Number of Channels 6 (Channel 0~5, 1 DIMM per channel) per processor...
  • Page 36 Chapter 2: Hardware Installation Please do follow the memory module installation instructions to install the DIMMs, and make sure At least one CPU is installed  If two CPUs are installed, install at least 1 DIMM for JCPU0.  Try to split the DIMMs evenly across the CPUs. ...
  • Page 37 NCA-5710 User Manual Please follow the steps below to install the DIMM memory modules. 1. Power off the system. 2. Pull open the DIMM slot latches. 3. Align the notch of the module with the socket key in the slot and carefully insert the card into the slot.
  • Page 38 Chapter 2: Hardware Installation With Slide Rail Kit + Short Ear Brackets The Ear Brackets fix the system onto the front rack posts. The Slide Rails can secure the system while making the equipment more easily accessible.

  • Page 39: Package Content

    NCA-5710 User Manual 1. Check the package contents of the Slide Rail Kit. The kit shall include the following items: 1x pack of M4X4L screws (for securing the sliding rail on the system) 2 x Slide Rails The rail consists of the following parts:...
  • Page 40 Chapter 2: Hardware Installation 5. Align the Rail Bracket to the side of the chassis and make sure the screw-holes on it match and properly engage the four buttons on the side panel as shown in the picture. Rear Front Buttons Aligning 6.
  • Page 41 NCA-5710 User Manual Assembling the Ear Brackets 1. Check the package contents, which shall include the items below: 1x pack of screws For securing the Ear Brackets on the unit 2x Ear Brackets 2. Install the Ear Brackets on both sides of the system using the provided screws.
  • Page 42 Chapter 2: Hardware Installation Installing the System into the Rack 1. Stretch both of the Inner Channels out to their fullest extent. You will hear a click sound when they are fully stretched and stop. Click The inner rail will click when it is fully stretched.

  • Page 43: Rear Panel

    NCA-5710 User Manual Before connecting any other cable to this system, you should first attach the grounding cable to the system’s grounding stud. 1. Obtain a proper grounding cable. 2. Position the grounding cable against the grounding stud on the system’s rear panel, and then tighten the nut to secure the cable.
  • Page 44 Chapter 2: Hardware Installation Power supply units may wear down eventually. Please be noted that NCA-5710 series supports 850W PSU. Please prepare the power supply units matching this capacity. 1. On the rear panel, locate the power supply units and disconnect the power cords.

  • Page 45: Power Source

    Tma = 40 degrees C, and the altitude of operation = 5000m. The cable should be 12AWG (21A minimum, 60V minimum). If you need further assistance with purchasing the power source, please contact to Lanner Electronics Inc. for further information.

  • Page 46: Chapter 3: Software Setup

    Chapter 3: Software Setup This chapter will introduce the features of Lanner’s BMC firmware and how to perform server remote management through it. For detailed instructions on using each function, please refer to the full version of NCA-5710 BMC manuals available on http://www.lannerinc.com/support/download-center/user-manuals.
  • Page 47 NCA-5710 User Manual System Power Management The BMC implements chassis power and resets functions for system administrators to control and manage the system power behavior. These functions can be activated by sending the IPMI 2.0 compatible chassis commands to the BMC over messaging interfaces. The following list summaries the supported functions.
  • Page 48 Chapter 3: Software Setup IPMI Commands Support List COMMANDS NETFN IPM Device “Global” Commands Get Device ID APP (06h) Cold Reset APP (06h) Warm Reset APP (06h) Get Device GUID APP (06h) BMC Watchdog Timer Commands Reset Watchdog Timer APP (06h) Set Watchdog Timer APP (06h) Get Watchdog Timer...
  • Page 49 NCA-5710 User Manual In the address bar of your Internet browser, input the IP address of the remote server to access the BMC interface of that server. Initial access of BMC prompts you to enter username and password. A screenshot of the login screen is...

  • Page 50: Default Username And Password

    Chapter 3: Software Setup Default User Name and Password Username: admin Password: admin The default username and password are in lower-case characters. When you log in using the default username and password, you will get full administrative rights, and it will ask you to change the default password once you log in.
  • Page 51 NCA-5710 User Manual Menu Bar The menu bar displays the following: Dashboard Configuration Remote Control Maintenance A screenshot of the menu bar is shown below: Menu Bar Quick Button and Logged-in User The user information and quick buttons are located at the top right of the Web UI.

  • Page 52: Lanner Sdk

    To meet today's security requirements, Lanner SDK derives unique platform identity design and integrates TPM software stack 2.0 on optional base. By leveraging Lanner SDK, the application development can be shortened and time-to-market can be easily met, download the SDK package and instruction guide from...
  • Page 53 NCA-5710 User Manual If your system is shipped without an operating system, install the supported operating system using the following resources. 1. Download the ISO image and make a bootable DVD from it. 2. Connect a DVD player or other type of readers (floppy disk, or a drive) to a computer.
  • Page 54 Chapter 3: Software Setup 5. After a JViewer screen pops up, select “Media” and then “Virtual Media Wizard” from the toolbar. 6. On Virtual Media screen, select your media type to load the image. For example, click on “Browse” of CD/DVD Media 1 and then “Connect CD/DVD.”...
  • Page 55 NCA-5710 User Manual 7. The Status window will display the connection status. 8. The installation process will automatically start. Please follow the onscreen instruction to complete the rest of the steps and restart the target system manually.

  • Page 56: Bios Setup

    Chapter 3: Software Setup BIOS is a firmware embedded on an exclusive chip on the system’s motherboard. Lanner's BIOS firmware offering including market-proven technologies such as Secure Boot and Intel Boot Guard technology deliver solid commitments for the shield protection against malware, uncertified sequences and other named cyber threats.
  • Page 57 NCA-5710 User Manual Setup page contains BIOS information and project version information. Feature Description BIOS Vendor: American Megatrends Core Version: AMI Kernel version, CRB code base, X64 Compliancy: UEFI version, PI version BIOS Information Project Version: BIOS release version Build Date and Time: MM/DD/YYYY Access Level: Administrator / User To set the Date, use <Tab>...
  • Page 58 Chapter 3: Software Setup...

  • Page 59: Trusted Computing

    NCA-5710 User Manual Trusted Computing Feature Options Description Enables or disables BIOS support for security device. Security Device Enabled By disabling this function, OS will not show Security Support Disabled Device. TCG EFI protocol and INT1A interface will not be available.
  • Page 60 Chapter 3: Software Setup Trusted Computing (TPM1.2) Feature Options Description Enables or disables BIOS support for security device. Security Device Enabled By disabling this function, OS will not show Security Support Disabled Device. TCG EFI protocol and INT1A interface will not be available.
  • Page 61 NCA-5710 User Manual Trusted Computing (TPM2.0)
  • Page 62 Chapter 3: Software Setup Feature Options Description Enables or disables BIOS support for security device. Security Device Enabled By disabling this function, OS will not show Security Support Disabled Device. TCG EFI protocol and INT1A interface will not be available. Enabled SHA-1 PCR Bank Enables or disables SHA-1 PCR Bank.
  • Page 63 NCA-5710 User Manual Trusted Computing (PTT Enable)
  • Page 64 Chapter 3: Software Setup Feature Options Description Enables or disables BIOS support for security device. Security Device Enabled By disabling this function, OS will not show Security Support Disabled Device. TCG EFI protocol and INT1A interface will not be available. Enabled SHA-1 PCR Bank Enables or disables SHA-1 PCR Bank.

  • Page 65: Super Io Configuration

    NCA-5710 User Manual Super IO Configuration...
  • Page 66 Chapter 3: Software Setup Serial port 1 Configuration Feature Options Description Enabled Serial Port Enables or disables Serial Port 1 Disabled Device Settings IO=3F8h; IRQ = 4 Serial Port 1...
  • Page 67 NCA-5710 User Manual Serial port 2 Configuration Feature Options Description Enabled Serial Port Enables or disables Serial Port 2 Disabled Device Settings IO=2F8h; IRQ = 3 Serial Port 2...
  • Page 68 Chapter 3: Software Setup Case Open Configuration Feature Options Description Enabled Case Open Enables or disables Case Open function Disabled...
  • Page 69 NCA-5710 User Manual Control Legacy PXE Boot Feature Options Description Control Legacy Disabled Select On Board LAN# Boot PXE Boot MGT LAN1 MGT LAN Port...

  • Page 70: Status Led Configuration

    NCA-5710 User Manual Status LED Configuration Feature Options Description Status LED GREEN Configures Status LED color...

  • Page 71: Digital I/O Configuration

    Chapter 3: Software Setup Digital I/O Configuration Feature Options Description Output High Digital I/O Output 1 Configure Digital I/O Pin5 Output Low Output High Digital I/O Output 2 Configure Digital I/O Pin6 Output Low Output High Digital I/O Output 3 Configure Digital I/O Pin7 Output Low Output High...

  • Page 72: Watchdog Timer Configuration

    NCA-5710 User Manual Watch Dog Timer Configuration Feature Options Description Watch Dog Enabled Enables or disables Watch Dog Timer function Timer Disabled...

  • Page 73: Serial Port Console Redirection

    Chapter 3: Software Setup Serial Port Console Redirection Feature Options Description COM0 Enabled Console Enables or disables Console Redirection Disabled Redirection...
  • Page 74 NCA-5710 User Manual Console Redirection Settings Feature Options Description VT100: ASCII char set VT100 VT100+:Extends VT100 to support color, function VT100+ keys, etc. Terminal Type VT-UTF8 VT-UTF8:Uses UTF8 encoding to map Unicode ANSI chars onto 1 or more bytes ANSI: Extended ASCII char set...
  • Page 75 Chapter 3: Software Setup Hardware overflow. RTS/CTS VT-UTF8 Combo Key Disabled Enables VT-UTF8 Combination Key Support for Support Enabled ANSI/VT100 terminals Disabled With this mode enabled, only text will be sent. This Recorder Mode Enabled is to capture Terminal data. Disabled Resolution 100x31 Enables or disables extended terminal resolution...
  • Page 76 NCA-5710 User Manual Legacy Console Redirection Settings Feature Options Description Legacy Serial Select a COM port to display redirection of Legacy OS COM0 Redirection Port and Legacy OPROM Messages Legacy Serial Redirection Port...
  • Page 77 Chapter 3: Software Setup PCI Subsystem Settings Feature Options Description Enables or disables 64bit capable Devices to be Above 4G Disabled Decoded in Above 4G Address Space (Only if Decoding Enabled System Supports 64 bit PCI Decoding) If the system has SR-IOV capable PCIe Devices, this Disabled SR-IOV Support option enables or disables Single Root IO...

  • Page 78: Network Stack Configuration

    NCA-5710 User Manual Network Stack Configuration Feature Options Description Disabled Network Stack Enables or disables UEFI Network Stack Enabled Disabled Enables Ipv4 PXE Boot Support. If IPV4 is Ipv4 PXE Support Enabled disabled, PXE boot option will not be created.

  • Page 79: Csm Configuration

    Chapter 3: Software Setup CSM Configuration Feature Options Description Disabled CSM Support Enables or disables CSM Support Enabled Do Not Launch Controls the execution of UEFI and Network UEFI Legacy PXE OpROM Legacy Do Not Launch Controls the execution of UEFI and Storage UEFI Legacy Storage OpROM...
  • Page 80 NCA-5710 User Manual NVMe Configuration USB Configuration...
  • Page 81 Chapter 3: Software Setup Feature Options Description Enables Legacy USB support. Enabled Auto option disables legacy support if Legacy USB Support Disabled no USB devices are connected; Auto Disabled option will keep USB devices available only for EFI applications. This is a workaround for OSes without Enabled XHCI hand-off support.
  • Page 82 NCA-5710 User Manual Select the Platform menu item from the BIOS setup screen to enter the Platform Setup screen. Users can select any of the items in the left frame of the screen. Feature Options Description Displays and provides option to change...

  • Page 83: Pch Configuration

    Chapter 3: Software Setup PCH Configuration Feature Options Description PCI Express None PCI Express Configuration settings Configuration PCH SATA None SATA devices and settings Configuration PCH sSATA None sSATA devices and settings Configuration Security Configuration None Security Configuration settings Power ON Restore AC Power Loss Power Off Select S0/S5 for ACPI state after a G3...
  • Page 84 NCA-5710 User Manual PCI Express Configuration Feature Options Description Enable PCIe root port function swapping PCIe Root Port Disabled feature to dynamically assign function 0 Function Swapping Enabled to enabled root port. MRRS 128B PCIE Max Read Request Size Selection.
  • Page 85 Chapter 3: Software Setup PCH SATA Configuration Feature Options Description Disabled SATA Controller Enables or disables SATA Controller Enabled AHCI Configure SATA as This will configure SATA as RAID or AHCI. RAID Support Aggressive Disabled Link Power Enables or disables SALP Enabled Management Disabled...
  • Page 86 NCA-5710 User Manual have this option enabled will spin up at boot. Otherwise all drives spin up at boot. Hard Disk Drive Identify the SATA port is connected to Solid SATA Device Type Solid State Drive State Drive or Hard Disk Drive...
  • Page 87 Chapter 3: Software Setup PCH SATA Configuration Feature Options Description Disabled sSATA Controller Enables or disables SATA Controller Enabled AHCI This will configure SATA as RAID or Configure SATA as RAID AHCI. Support Aggressive Disabled Link Power Enables or disables SALP Enabled Management Disabled...

  • Page 88: Security Configuration

    NCA-5710 User Manual drives which have this option enabled will spin up at boot. Otherwise, all drives spin up at boot. Hard Disk Drive Identify the SATA port is connected to SATA Device Type Solid State Drive Solid State Drive or Hard Disk Drive...

  • Page 89: Server Me Configuration

    Chapter 3: Software Setup Server ME Configuration...

  • Page 90: Runtime Error Logging

    NCA-5710 User Manual Runtime Error Logging Feature Options Description Disabled System Errors System Error Enable/Disable setup options. Enabled...
  • Page 91 Chapter 3: Software Setup Select the Socket menu item from the BIOS setup screen to enter the Socket Setup screen. Users can select any of the items in the left frame of the screen. Feature Options Description Processor Displays and provides option to change the None Configuration Processor Settings...
  • Page 92 NCA-5710 User Manual Processor Configuration...
  • Page 93 Chapter 3: Software Setup Feature Options Description Hyper-Threading Disabled Enables Hyper-Threading (Software Method to [ALL] Enabled Enable/Disable Logical Processor threads. Disabled Machine Check Enable or Disable the Machine Check Enabled Execute Disable Disabled When disabled, it forces the XD feature flag to Enabled always return 0.
  • Page 94 NCA-5710 User Manual Per-Socket Configuration Feature Options Description CPU Socket0 None None Configuration CPU Socket1 None None Configuration CPU Socket 0 CPU Socket 1...
  • Page 95 Chapter 3: Software Setup CPU Socket0 Configuration Feature Options Description Core Disable 0: Enable all cores. Bitmap(Hex) 3fff: Disable all cores Disabled IOT Cfg None Enabled...
  • Page 96 NCA-5710 User Manual CPU Socket1 Configuration Feature Options Description Core Disable 0: Enable all cores. Bitmap(Hex) 3fff: Disable all cores Disabled IOT Cfg None Enabled...

  • Page 97: Memory Configuration

    Chapter 3: Software Setup Memory Configuration Feature Options Description Auto 1000 1066 1200 1333 1400 1600 1800 1866 Memory Maximum Memory Frequency Selections in Mhz. 2000 Frequency Do not select Reserved 2133 2200 2400 2600 2666 2800-OvrClk 2933-OvrClk 3000-OvrClk 3200-OvrClk 3400-OvrClk...
  • Page 98 NCA-5710 User Manual 3600-OvrClk 3733-OvrClk 3800-OvrClk 4000-OvrClk 4200-OvrClk 4266-OvrClk 4400-OvrClk Displays memory topology with DIMM population Memory Topology None information...

  • Page 99: Iio Configuration

    Chapter 3: Software Setup IIO Configuration Feature Options Description Socket0 Configuration None None Socket1 Configuration None None IOAT Configuration None All IOAT configuration options Intel® VT for Directed Press <Enter> to bring up the Intel? VT for None I/O (VT-d) Directed I/O (VT-d) Configuration menu.

  • Page 100: Socket0 Configuration

    NCA-5710 User Manual Socket0 Configuration Feature Options Description Socket 0 None Settings related to PCI Express Port 1A PcieBr1D00F0 Socket 0 None Settings related to PCI Express Port 1C PcieBr1D02F0 Socket 0 None Settings related to PCI Express Port 2A...
  • Page 101 Chapter 3: Software Setup Socket0 PcieBr1D00F0 – Port 1A/1C/2A/2C...
  • Page 102 NCA-5710 User Manual Feature Options Description In auto mode the BIOS will remove the EXP port if Auto there is no device or errors on that device and PCI-E Port Enable the device is not HP capable. Disable is used to Disable disable the port and hide its CFG space.
  • Page 103 Chapter 3: Software Setup Socket1 Configuration Feature Options Description Socket 1 None Settings related to PCI Express Port 1A PcieBr1D00F0 Socket 1 None Settings related to PCI Express Port 1C PcieBr1D02F0 Socket 1 None Settings related to PCI Express Port 2A PcieBr2D00F0 Socket 1 None...

  • Page 104: Ioat Configuration

    NCA-5710 User Manual IOAT Configuration Feature Options Description Sck0 IOAT Config None None Sck1 IOAT Config None None Disable TPH TLP Processing Hint disable Disabled Prioritize TPH Prioritize TPH Enabled Disabled Relaxed Ordering Relaxed Ordering Enable/Disable Enabled...

  • Page 105: Intel® Vt For Directed I/O (Vt-D)

    Chapter 3: Software Setup Intel® VT for Directed I/O (VT-d) Feature Options Description Intel® VT for Directed Disabled Press <Enter> to bring up the Intel? VT for Directed I/O (VT-d) Enabled I/O (VT-d) Configuration menu.

  • Page 106: Advanced Power Management Configuration

    NCA-5710 User Manual Advanced Power Management Configuration Feature Options Description P State Control Configuration Sub CPU P State Control None Menu, include Turbo, XE and etc. CPU C State Control None CPU C State setting...
  • Page 107 Chapter 3: Software Setup CPU P State Control Feature Options Description Disabled SpeedStep(Pstates) Enables or disables EIST (P-States) Enabled Max Performance Boot performance Max Efficient Select the performance state that the mode Set by Intel Node BIOS will set before OS hand off. Manager Disabled Energy Efficient Turbo Disable, MSR...

  • Page 108: Cpu C State Control

    NCA-5710 User Manual CPU C State Control Feature Options Description Autonomous Core Disabled Autonomous Core C-State Control C-State Enabled Disabled Enables or disables CPU C6(ACPI C3) CPU C6 report Enabled report to OS Enhanced Halt State Disabled Core C1E auto promotion Control. Takes...
  • Page 109 Chapter 3: Software Setup Feature Options Description Enabled Enable or disables interfaces to communicate with BMC Support Disabled BMC. Wait For BMC response for specified time out. In Enabled PILOTII, BMC starts at the same time when BIOS Wait For BMC Disabled starts during AC power ON.
  • Page 110 NCA-5710 User Manual Do Nothing Configure how the system should respond if the FRB-2 Timer Reset FRB-2 Timer expires. Not available if FRB-2 Timer is Policy Power Down disabled. Power Cycle If enabled, it starts a BIOS timer which can only be...

  • Page 111: System Event Log

    Chapter 3: Software Setup System Event Log Feature Options Description SEL Components Disabled Enables or disables all features of System Enabled Event Logging during boot. Erase SEL Yes, On next reset Choose options for erasing SEL. Yes, On every reset Do Nothing Erase When SEL is Full...

  • Page 112: Bmc Network Configuration

    NCA-5710 User Manual BMC network configuration Feature Options Description Select to configure LAN channel parameters Unspecified Configuration statically or dynamically (by BIOS or BMC). The Static Address source unspecified option will not modify any BMC DynamicBmcDhcp network parameters during BIOS phase.
  • Page 113 Chapter 3: Software Setup View System Event Log...
  • Page 114 NCA-5710 User Manual Select the Security menu item from the BIOS setup screen to enter the Security Setup screen. Users can select any of the items in the left frame of the screen. Feature Description If ONLY the Administrator's password is set, it only...

  • Page 115: Secure Boot

    Chapter 3: Software Setup Secure Boot Feature Options Description Secure Boot is activated when Platform Key(PK) is Attempt Secure Disabled enrolled, System mode is User/Deployed, and CSM Boot Enabled function is disabled. Secure Boot mode selector: Standard Secure Boot Mode In Custom mode, Secure Boot Variables can be Custom configured without authentication...

  • Page 116: Key Management

    NCA-5710 User Manual Key Management Feature Options Description Provision Factory Disabled Allows User to provision factory default Secure Defaults Enabled Boot keys when System is in Setup Mode. Install Factory Forces System to User Mode - install all Factory None...
  • Page 117 Chapter 3: Software Setup Select the Boot menu item from the BIOS setup screen to enter the Boot Setup screen. Users can select any of the items in the left frame of the screen. Feature Options Description The Number of seconds to wait for setup Setup Prompt Timeout activation key.
  • Page 118 Select the Save and Exit menu item from the BIOS setup screen to enter the Save and Exit Setup screen. Users can select any of the items in the left frame of the screen. Discard Changes and Exit Select this option to quit Setup without saving any modifications to the system configuration. The following window will appear after the “Discard Changes and Exit”...
  • Page 119 Chapter 3: Software Setup Restore Defaults Restore default values for all setup options. Select “Yes” to load Optimized defaults. The items listed under Boot Override depend on devices connected to system. Note:...
  • Page 120 NCA-5710 User Manual The status explanations of LED indicators on the Front Panel are as follows: System Power System Status HDD Activity System Power Solid Green The system is powered on The system is powered off System Status This LED indicator is programmable. You could program it to display the operating status of the...

  • Page 121: Introduction

    Eventually, you are left with no choice but to ship the board back to the manufacturer. Lanner understands this pain and has empowered our products with the Dual BIOS feature. Normally, the Primary BIOS is used to boot the OS during powering up; when Primary BIOS is down, the Recovery BIOS automatically jumps in to boot up the OS for the User to take further steps such as performing data backup and BIOS upgrade.
  • Page 122 NCA-5710 User Manual Few things can shut down a computer as completely as a corrupted BIOS. With Dual BIOS feature, you will be guaranteed to enter a healthy OS to perform thorough troubleshooting before the situation is irreparable. Dual BIOS features two physical BIOS ROMs soldered onto the motherboard, carrying two separate BIOS images.
  • Page 123 Appendix B: Dual BIOS Introduction On POST screen, the Boot Bios information will display the BIOS used for this bootup. With the Recovery BIOS at work, it can be asserted that the Primary BIOS is having such severe problem that it failed to function. Before you make certain the BIOS chip is completely corrupted, it is definitely sensible to try the last resort—updating BIOS.
  • Page 124 Lanner Technical Support. Disclaimer Under no circumstances will Lanner accept responsibility or liability for damages of any kind whatsoever resulting or arising directly or indirectly from a BIOS update.
  • Page 125 “treat a PCIe end-point device as a Hot-pluggable one.” To achieve this functionality, Lanner has implemented a methodology that involves in both hardware (Hot-plug controller IC) and software implementation (both BIOS and kernel) support, not only successfully utilizing this functionality in NCA-5710’s architecture but allowing for combined operation...
  • Page 126 NCA-5710 User Manual Note It is suggested that the hot-plug capability of a PCIe port remain “Disabled” until you literally need to replace the module in it. This serves the same purpose of disabling this function by factory default—to reserve CPU resources to allocate for more critical tasks.
  • Page 127 Appendix C: PCIe Hot-Swap 4. Enter the configuration page to enable these two capabilities: “Hot Plug Capable” and “Surprise Plug Capable.” Set to “Enable” The Hot-swap Utility is a Linux application, acting as a handy tool for User to place command to directly “power-on”...
  • Page 128 NCA-5710 User Manual In the command window, execute this utility with the following command: hot_swap.sh 2. Input the power-off command to disconnect the power supply of the target PCIe slot. hot_swap.sh 1 off [Slot No.][Command] The slot names map to the physical slots as shown below:...
  • Page 129 Appendix C: PCIe Hot-Swap In a typical PCIe-based system, the enumeration and resource allocation algorithms performed by the CPU during the very first initialization will fix the PCIe topology, meaning that the configuration of the PCIe modules first installed in the slot is locked down and not allowed for alternation. Considering this limitation, for hot-swapping, it is strongly advised that you always replace a PCIe module with one of the same link width.
  • Page 130 NCA-5710 User Manual Console redirection lets you monitor and configure a system from a remote terminal computer by re-directing keyboard input and text output through the serial port. The following steps illustrate how to use this feature. The BIOS of the system allows the redirection of the console I/O to a serial port. With this configured, you can remotely access the entire boot sequence through a console port.

  • Page 131: Appendix E: Terms And Conditions

    Appendix E: Terms and Conditions 1. All products are under warranty against defects in materials and workmanship for a period of one year from the date of purchase. 2. The buyer will bear the return freight charges for goods returned for repair within the warranty period; whereas the manufacturer will bear the after service freight charges for goods returned to the user.
  • Page 132 NCA-5710 User Manual When requesting RMA service, please fill out the following form. Without this form enclosed, your RMA cannot be processed.
