4.2.2

Use of DRIVE CLiQ interface

Use of DRIVE-CLiQ
The DRIVE CLiQ interfaces are used to connect the components assigned to the control unit
in the drive assembly (e.g., active line module, motor modules, terminal modules, and sensor
modules from the SINAMICS family).
DRIVE CLiQ has the following properties:
• Independent expansion of components possible
• Automatic detection of components by the control unit
• Standardized interfaces to all components
• Uniform diagnostics down to the components
• Complete service down to the components
D4xx
Manual, 12.2004, 6AU1900-1AJ32-0BA0
Signal name
NC
RXN
NC
NC
+ (24 V)
M (0 V)
B
8
1
A
DRIVE CLiQ interface
4.2 DRIVE CLiQ interfaces
Signal type
I
VO
VO
Interfaces
Meaning
Reserved, do not use
Receive data -
Reserved, do not use
Reserved, do not use
Voltage supply for
DRIVE CLiQ, 450 mA
maximum
Ground to 24 V
4-3
