RCP 101 D Remote Control Panel • Setup Guide (Continued)
Firmware
The firmware version installed on the RCP 101 D must be compatible with the firmware installed on the SMP. To ensure this, the
RCP 101 D firmware is managed automatically by the SMP series products. The firmware version of the RCP 101 D can be found
on the SMP embedded web page under
When the remote control panel is first connected to the SMP, the SMP checks the firmware version on the RCP 101 D and, if
necessary automatically updates the panel firmware to a compatible version.
If you update the SMP firmware, the RCP 101 D firmware is automatically updated at the same time. For more information about
updating SMP firmware, see the SMP User Guide at www.extron.com.

Making a Recording

Once the SMP and RCP 101 D are installed, and configured, follow these instructions to make a recording using the RCP 101 D:
Open the SMP web page to ensure the recording will be saved to the correct drive and that the recording media is attached
1.
to the correct drive.
Use the RCP 101 D to start the recording by pressing the
2.
If required, add a chapter marking by pressing the
3.
If required, pause the recording by pressing the
4.
Restart the recording by pressing the
End the recording by pressing the
5.
For more information, see the SMP User Guide at www.extron.com.
For information on safety guidelines, regulatory compliances, EMI/EMF compatibility, accessibility, and related topics,
see the Extron Safety and Regulatory Compliance Guide
6
Configuration > System Settings > Unit Identification
Record
Mark
button (figure 1,
Pause
button (figure 1,
Pause
button a second time or by pressing the
End
button (figure 1, C
© 2016 - 2018 Extron Electronics — All rights reserved.
All trademarks mentioned are the property of their respective owners.
1, A
button (figure ).
E
).
D ).
Record
).
on the Extron website.
www.extron.com
.
button.
68-3000-50 Rev. C
10 18
