Course Identification:
It identifies the courses with b (= blue) and r (= red), or l (= left) and r (= right). You can select in
the main menu if you want the identification b or L (Menu 26: ID CHANNEL 4).
Photocells for the Finish:
-
the red (right) course must be connected with channel 1 (cable 001-10 at socket 20)
-
the blue (left) course must be connected with channel 4 (cable 001-10 at socket 21)
Photocells for the First Intermediate Time:
-
the red (right) course must be connected with channel 2.
-
the blue (left) course must be connected with channel 5.
Photocells for the Second Intermediate Time:
-
the red (right) course must be connected with channel 6.
-
the blue (left) course must be connected with channel 7.
Photocells for the Third Intermediate Time:
-
the red (right) course must be connected with channel 8.
-
the blue (left) course must be connected with channel 9.
Timing Channels
c0 = Start (= C3)
c2 = Intermed. 1 red
c1 = Finish, red
c3 = Start (= C0)
ALGE adjustments for the main menu:
Menü 1:
Delay Time Start = 1.0 s
Menü 2:
Delay Time Finish = 0.3 s
Menü 3:
Seconds Mode = off
Menü 4:
Display Time1 = 3 s
Menü 5:
Display Time 2 = 3 s
Menü 8:
Running Time = run
Menü 9:
Running Tenth = off
Menü 13:
Print Start Time = off
Menü 14:
Print Menues = on
Menü 15:
Print Linefeed = 0
Display (2):
Shows the start number of the blue (left) course. Additional it shows the position of switch (1) and
the condition of the competitor (no identification = not started, "u" = used or started, r = run time,
t = total time (only in the 2nd heat)).
Display (8):
Shows the start number of the red (right) course. Additional it shows the position of switch (1) and
the condition of the competitor (no identification = not started, "u" = used or started, r = run time,
t = total time (only in the 2nd heat)).
Info-Display (6):
The info-display shows the actual start numbers and the times. After the racer finish their race it
shows as well the difference time.
0001 b
0:00.000
0002 r
0:00.000
0001 b
0:03
0002 r
0:03
Version: E-19-03-07
TdC 8000
c4 = Finish, blue
c6 = Intermed. 2 red
c5 = Intermed. 1 blue
c7 = Intermed. 2 blue
Menü 16:
Menü 17:
Menü 18:
Menü 19:
Menü 20:
Menü 24:
Menü 24:
Menü 25:
Menü 26:
Menü 27:
before the start:
StNo, course (b = blue, r= red), time
after the start:
StNo, course (b = blue, r= red),running time
Page 77
c8 = Intermed. 3 red
c9 = Intermed. 3 blue
RS-232 Baudrate = 9600 Baud
RS-232 Run time = off
D-Board Baudrate = 2400 Baud
D-Board Kanal 2 = running
Beep = on
Change Heat
Change Race
D-Board-Test = off
ID Channel 4 = b (blue)
Penalty Time = 1.500 Sek.
Page 77
