ALGE-Timing TdC 8000 Manual page 105

Menu 5: DISPLAY Time 2 = 03 s
(15)
Save with: ENTER
Pre adjusted value: Display Time 2 = 3 seconds
Display Board Channel 2:
You can adjust the channel 2 of the display board interface (24). If you have channel two on it
outputs no running time (only run times). It outputs the classement always on channel 2. You can
select between channel 1 and channel 2 by turning the plug of the display board cable 180°.
Menu 18: D-BOARD CHANNEL 2
Save with: ENTER
ON = <F1> .............. run time and classement
OFF = <F2> .............. running time and classement
Pre adjusted value:
Version: E-19-03-07
TdC 8000
Menu 18:
ON F1
OFF< F2
D-Board Channel 2 is off (running time)
input seconds with finish keyboard
Confirm input with <ENTER>
D-BOARD CHANNEL 2 = OFF
output of run times
output of running time
Confirm selection with <ENTER>
