Classement "PROTOCOL" and "SINGLE":
After the instruction for "PROTOCOL" and "SINGLE" input the start number blocks. You can use
more than one start number block. Each start number block has the first and last start number
(each four digits) of a continuous sequence. Both start numbers are separated by a hyphen. Each
number block is separated by a carriage return. Input after the last number block 0000-0000 and
carriage return.
PSIST(CR) ...... Protocol of selected start times
PSIFT(CR) ...... Protocol of selected finish times
PSIRT(CR) ...... Protocol of selected run times
PSISQ(CR) ...... Protocol of selected sequential times (lap times)
PSIMT(CR) ...... Protocol of selected memory times
PSITT(CR) ...... Protocol of selected total times
PSIITC2(CR) .... Protocol of selected intermediate times of channel C2
PSIITC3(CR) .... Protocol of selected intermediate times of channel C3
PSIITC4(CR) .... Protocol of selected intermediate times of channel C4
PSIITC5(CR) .... Protocol of selected intermediate times of channel C5
PSIITC6(CR) .... Protocol of selected intermediate times of channel C6
PSIITC7(CR) .... Protocol of selected intermediate times of channel C7
PSIITC8(CR) .... Protocol of selected intermediate times of channel C8
PSIITC9(CR) .... Protocol of selected intermediate times of channel C9
PSIBRT(CR) ..... Protocol of selected run times of the blue course for Dual Timer
PSIRRT(CR) ..... Protocol of selected run times of the red (right) course for Dual Timer
PSILRT(CR) ..... Protocol of selected run times of the left course for Dual Timer
0001-0024(CR) .. Start number block, e.g. form StNo. 1 to StNo. 24
0065-0073(CR) .. Start number block, e.g. form StNo. 65 to StNo. 73
0105-0124(CR) .. Start number block, e.g. form StNo. 105 to StNo. 124
0000-0000(CR) .. Finish with this input

8.3. RS 485 Interface (16, 23, 28):

Transfer Speed:
Pin Arrangement:
8.4. Display Board Interface (24):
Transfer Format:
Transfer Speed:
Transfer Protocol:
The display board interface has two different channels:
Channel 1: running time
Channel 2: running time and classement or run time and classement
Attention: Switch between channel 1 and channel 2 by turning the plug of socket (24) 180°.
Channel 1 has always the same output as shown in display 7 and 8. The adjusted display time
(see menu 4 on page 52) is always valid for display 7 and 8 and channel 1 of the display board
interface (24). Channel 1 does not output a classement.
You can switch channel 2 in the main menu (menu 19 on page 56) between running and
standing time (run time). On channel 2 you have always an output of the classement.
NNN.xxxxxxxxM:SSxxxx(CR)
Version: E-19-03-07
TdC 8000
60 kBaud
see page 95
1 start bit, 8 data bit, no parity bit, 1 stop bit
2.400 Baud
ASCII
running time (without 1/10 seconds)
no function
Page 103
