ALGE-Timing TdC 8000 Manual page 11

Attention: Please take care that the paper goes through the paper slotted hole of the cover when
you put the cover back on.
Clearing Jammed Paper:
- Press the black lever forward and pull back the remaining paper.
- Remove the serrated cutter by holding the black lever forward and sliding the cutter towards
the lever and lifting upwards.
- Pull the print head back with your fingernail and remove any stuck paper with tweezers or
small needlenose pliers.
- If the paper has jammed under the roller it will be necessary to remove it by sliding a piece
of 35 mm film through the paper path and rocking it to and fro until the stuck paper is ex-
pelled. Use a piece of film about 20 cm long to have something to hold onto.
The printer is a very rugged device but needs regular maintenance for a long service life. Call
your ALGE agent if you have further questions.
Printer-Paper:
Electrosensitive paper 60 mm width, 40 mm diameter with about 25 m paper length (about 6000
lines). The electrosensitive paper is available at your ALGE representative.
A black strip will become visible on the edge of paper, when a paper roll is about to run out.
Attention: Do not pull on the paper when printing. Press the black lever forward and pull the paper
carefully out, if the paper is repressed.
The printer-paper has to stay dry!
Version: E-19-03-07
TdC 8000
- Insert the beginning of the paper into the paper feed of the
printer. Make sure it is cleanly out.
- If necessary correct the paper path through pressing the black
lever forward and adjusting the paper manually.
- Put the cover back and press the button until they stay in the
lower position.
