SLC500 Rack
1746-IO12DC
6 - Discrete Inputs
6 - Discrete Outputs
*T.R.
Page 8 of 77
(slot 2)
RS-232 to Host PC
SLC 5/04
Processor
(slot 0)
1770-KFD
1747-SDN
DevceNet
DeviceNet
to
Scanner
RS-232
(slot 1)
serial interface
+24V DC
P/S
Evaluation DeviceNet Network
Unidrive
# 2
UD77
UD77
TB
logical layout
Unidrive
# 1
UD77
UD77
TB
*T.R.
*T.R. - Termination
R
i t
