CUTTING SERIES EQUIPMENT
Troubleshooting
3.1 Troubleshooting
◆Before arc welding machines are dispatched from the factory, they have already been
debugged accurately. So forbid anyone who is not authorized by us to do any change to
the equipment!
◆Maintenance course must be operated carefully. If any wire becomes flexible or is
misplaced, it maybe potential danger to user!
◆Only professional maintenance personal who is authorized by us could overhaul the
machine!
◆Guarantee to shut off the arc welding machine's power before turn on the outline of
the equipment!
◆If there is any problem and has no the authorized professional maintenance personal,
please contact local agent or the branch company!
If there are some simple troubles of WSME-series welding machine, you can consult
the following overhauling chart:
Nr. Troubles Reasons
Fan is broken and the control board
Turn on the
broken
power source,
There is something in the fan and
power indicator
the control board broken
1
is lit, fan and air
The start capacitor of fan damaged
control valve are
and the control board broken
not working
The input lines not corretly connected
The power light damaged or
Turn on the
power source, connection is not good
2 fan is working,
The power board is broken
power indicator
Display panel is broken
is not lit
The power cable connected not
good
Turn on the
The power cable is broken
power source,
Power on switch is damaged
3 fan is not working,
The light of the power indicator is
power indicator is
broken and the problems mentioned
not lit
in Nr. 2
The power board is broken
The shield cup is unfitted installation
The tip or electrode is unfitted
installation
Turn on the power
4 source, Torch/Gas
Gas pressure too low
indicator is on
Cutting torch is broken or mistake
The input or output of the air flow
around the machine is blocked
Fan blocked
The over-heat
alarm is on after
Over-heat appear
5
a few minutes
cutting
Input voltage is not correct
Faulty components in the machine
64
Solution
Change fan and control board
Clean it and change the control
board
Change capacitor and control
board
Connect correctly
Change the power light
Change it
Change it
Connect correctly
Repair or change it
Change it
Change the light of the power
indicator or refer to the solution
in Nr. 2
Change it
Install and screw properly
Install and screw properly
Adjust the gas pressure to 65psi/
4.5 bar,the barometer indicate up
to 0.4Mpa or 60psi.
Check and change
Correct the condition
Check and correct it
let meachine cool down 5 minutes
and make sure the duty cycle is
not exceeded
Choose the proper voltage
Consult the dealer or manufacturer
to repair
CUTTING SERIES EQUIPMENT
Nr. Troubles Reasons
Torch parts broken
When torch is
Gas pressure too low or too high
pressed the torch
6
failed to ignite the
Faulty components in the machine
arc
Input voltage is not correct
The gas distributor is uninstalled
Torch parts are worn
When torch is
pressed the torch
7 Machine is in trouble
is difficult to ignite
Gas pressure too low or too high
Input voltage is not correct
The connection between cutting
torch and machine is not correct o
After triggering r the connection is poor
the torch ,the pilot
8
arc cannot change Earth clamp not correctly connect to
the work piece
to the cutting pilot
The cutting torch is broken
Power supply is overheated
Arc shuts off during
Gas pressure too low , the torch/gas
operation and it will
indicator is on when torch switch is
9
not restart when
pressed
torch is triggered
Torch consumbles are worn
Faulty components in the machine
Gas pipe not connected or pressure
The power indicator is too low
is on ,fan is working
10
Faulty components in the machine
but no gas flow , gas
indicator is on
Air regulator is broken
Incorrect setting of cutting current
low cutting output
11
Faulty components in the machine
Cutting current is too low
Torch can cut but
12
The movement of torch is too fast
the quality is poor
Excessive oil or moisture in torch
lack of air pressure
Troubleshooting
Solution
Inspect torch parts and replace
if necessary
Adjust it to proper rate
Consult the dealer or manufacturer
to repair
Choose the proper voltage
Install it
Check and change the torch parts
Consult the dealer or manufacturer
to repair
Adjust it to proper rate
Choose the proper voltage
Check the torch leads are properly
connect to the machine
Make sure the earth clamp has a
proper connection to a clean and
dry area of the workpiece
Change or repair it
let meachine cool down 5 minutes
and make sure the duty cycle is
not exceeded
Check and adjust the gas setting
at least 65psi/4.5 bar
Check and replace
Consult the dealer or manufacturer
to repair
Check the gas connection, adjust the
proper setting
Consult the dealer or manufacturer
to repair
Change it
Check and adjust the cutting current
Consult the dealer or manufacturer
to repair
Increase the cutting current
Reduce cutting speed
Do not directly start to cut before
cleaning the torch
Check the air pressure and air flow
65
