STICK SERIES EQUIPMENT
Summary
1.9 Specifications E301/E401
Description
VECTOR DIGITAL E301 STICK
Weight
Power Source Dimensions H515mmxW224mmxD375mm
Cooling
Welder Type
Inverter Power Source
European Standards
EN 60974-1 / IEC 60974-1
Number of Phases
Nominal Supply Voltage
Nominal Supply Frequency
Welding Current Range
( STICK Mode)
Effective Input Current
Maximum Input Current
Single Phase Generator
Requirement
STICK (MMA) 300A @ 60%, 32V
Welding Output, 40ºC, 10 min.
232A @ 100%, 29.3V
Open circuit voltage
Protection Class
NOTE
Due to variations that can occur in manufactured products, claimed performance,voltages,
ratings, all capacities, measurements, dimensions and weights quoted are approximate
only. Achievable capacities and ratings in use and operation will depend upon correct
installation, use, applications, maintenance and service.
1.10 Packaged Items
E301/ E401
◆300 A electrode holder with 3M cable
◆300 A earth clamp with 3M cable
◆3M Power cable
◆Operating Manual
38
VECTOR DIGITAL E401 STICK
19.2 kg 26.3 kg
H540mmxW235mmxD445mm
Fan Cooled Fan Cooled
Inverter Power Source
EN 60974-1 / IEC 60974-1
3 3
400V +/- 15% 400V +/- 15%
50/60Hz 50/60Hz
30 - 300A 30 - 400A
13.6A
20.4A
17.5 A
26.3A
27.3kVA
18.2KVA
400A @ 60%, 36V
310A @ 100%, 32.4V
66V DC 66V DC
IP23 IP23
STICK SERIES EQUIPMENT
1.11 Duty Cycle
The rated duty cycle of a Welding Power Source is a statement of the time it may be
operated at its rated welding current output without exceeding the temperature limits of the
insulation of the component parts. To explain the 10 minute duty cycle period the following
example is used. Suppose a Welding Power Source is designed to operate at a 60% duty
cycle, 400 amperes at 36 volts. This means that it has been designed and built to provide
the rated amperage (400A) for 6 minutes, i.e. arc welding time, out of every 10 minute
period (60% of 10 minutes is 6 minutes).During the other 4 minutes of the 10 minute period
the Welding Power Source must idle and be allowed to cool.
1 0 0
9 0
8 0
E301 STICK
7 0
6 0
5 0
4 0
3 0
Safe Operating Region
(STICK)
2 0
1 0
0
1 60 190 220
0 1 0 0 130
Welding Current(AMPS)
2.1 Layout For The Panel E161 /E201
3 3
6 6
4 4
5 5
7 7
Summary
E401 STICK
250 280 310 330 360 390
1 1
2 2
8 8
420
