Vector Welding C-Series Operating Instructions Manual page 31

CUTTING SERIES EQUIPMENT
Summary
NOTE
Due to variations that can occur in manufactured products, claimed performance, voltages,
ratings, all capacities, measurements, dimensions and weights quoted are approximate
only. Achievable capacities and ratings in use and operation will depend upon correct
installation, use, applications,maintenance and service
1.3 Packaged Items
C41
◆Plasma Torch 6m S45
◆200 A earth clamp with 3M cable
◆3M Power cable
◆3M Gas Hose 8x13.5
◆Operating Manual
1.4 Duty Cycle
The rated duty cycle of a Welding Power Source is a statement of the time it may be
operated at its rated welding current output without exceeding the temperature limits of the
insulation of the component parts. To explain the 10 minute duty cycle period the following
example is used. Suppose a Welding Power Source is designed to operate at a 40% duty
cycle, 40 amperes at 96 volts. This means that it has been designed and built to provide
the rated amperage (40A) for 4 minutes, i.e. arc welding time, out of every 10 minute
period (40% of 10 minutes is 4 minutes). During the other 6 minutes of the 10 minute period
the Welding Power Source must idle and be allowed to cool.
1 0 0
90
C41 CUT
8 0
70
6 0
5 0
40
3 0
Safe
Operating
20
Region
10
0
100
25 75
0 50
Welding Current(AMPS)
52
150 175 2 0 0 2 25 2 5 0
125
CUTTING SERIES EQUIPMENT
1.5 Specifications C71
Power Source Dimensions
European Standards
Number of Phases
Nominal Supply Voltage
Nominal Supply Frequency
Welding Current Range (CUT)
Effective Input Current
Maximum Input Current
Single Phase Generator
Welding Output, 40ºC, 10 min.
Open circuit voltage
NOTE
Due to variations that can occur in manufactured products, claimed performance, voltages,
ratings, all capacities, measurements, dimensions and weights quoted are approximate
only. Achievable capacities and ratings in use and operation will depend upon correct
installation, use, applications,maintenance and service
1.6 Packaged Items
C71
◆Plasma Torch 6m PT80
◆200 A earth clamp with 3M cable
◆3M Power cable
◆3M Gas Hose 8x13.5
◆Air Regulator
◆Operating Manual
275 3 00
1.7 Duty Cycle
Description
VECTOR DIGITAL C71 CUT
Weight
H515mmxW224mmxD375mm
Cooling Fan Cooled
Welder Type
Inverter Power Source
EN 60974-1 / IEC 60974-1
400V +/- 15%
Requirement
70A @ 60%, 108V 54A @ 100%, 101.6V
Protection Class
Summary
18.8 kg
3
50/60Hz
20 - 70A
10.7A
13.8A
14.3kVA
300V DC
IP23
53
