UM2407
Table 22. ST morpho connector pin assignment (continued)
CN11 odd pins
Pin nbr Pin name
53 PF0
55 PD1
57 PD0
59 PG0
61 PE1
63 PG9
65 PG12
67 NC
69 PD9
1. Default state of BOOT0 is 0. It can be set to 1 when a jumper is plugged on the pins 5-7 of CN11.
2. 5V_USB_STLK is the 5 V power coming from the ST-LINKV3 USB connector that rises before and it rises before the +5 V
rising on the board.
3. PA13 and PA14 are shared with SWD signals connected to STLINK-V3. It is not recommended to use them as I/O pins.
CN11 even pins
Pin nbr Pin name
54 PF8
56 PF9
58 PG1
60 GND
62 PE6
64 PG15
66 PG10
68 PG13
70 PG11
UM2407 Rev 1
CN12 odd pins
Pin nbr Pin name
53 PE15
55 PE13
57 PF13
59 PF12
61 PG14
63 GND
65 PD10
67 PG7
69 PG4
Extension connectors
CN12 even pins
Pin nbr Pin name
54 GND
56 PE11
58 PF3
60 PF15
62 PF11
64 PE0
66 PG8
68 PG5
70 PG6
