Board connectors
1. Green LED: Ethernet traffic
2. Amber LED: Ethernet connection
The related pinout for the Ethernet connector is listed in
Connector
CN14
36/48

Figure 17. Ethernet RJ45 connector CN14 (front view)

Table 17. Ethernet connector pinout

Pin
Description
number
1
TX+
2
TX-
3
RX+
4
NC
5
NC
6
RX-
UM2407 Rev 1
Table
Pin
MCU pin
number
-
7
-
8
-
9
-
10
-
11
-
12
17.
Description
MCU pin
NC
-
NC
-
K, yellow LED
-
A, yellow LED
-
K, green LED
-
A, green LED
-
UM2407
