Summary of Contents for Beyerdynamic MCS-D 200

  • Page 1: Operating Instructions

    OPERATING INSTRUCTIONS MCS-D 200 Digital multimedia-based Conference System...
  • Page 2 This manual does not include each possible case of installation, operation or maintenance. For more information please contact your beyerdynamic dealer or beyerdynamic GmbH & Co. KG. beyerdynamic assumes no liability for errors in this documentation and for damages resulting from using this documentation and the products described in it.

  • Page 3: Table Of Contents

    How to operate the menu of the MCS-D 200 control unit ......
  • Page 5 MCS-D 3171 / 3173 ............. . . Page 7.3.1 Controls and indicators .
  • Page 6 This manual describes the installation and operation of the MCS-D 200 system without the control and configuration via PC. MCS-D 200 is a fully digital multimedia-based conference system in single-cable design. It can be used for small and large events in permanent installations or for mobile use.

  • Page 7: Important Safety Instructions

    Important Safety Instructions Control Unit and Power Supply Units • READ these instructions. • KEEP these instructions. • HEED all warnings. • Follow all instructions. • Do not use this apparatus near water. • Clean only with a dry cloth. •...

  • Page 8: Set-Up

    The MCS-D 200 control unit is the heart of the system. It controls the delegate, chairman and interpreter microphone stations. The MCS-D 200 control unit has a modular power supply unit to power a maximum of 15 microphone stations (optional 30). If more than 30 microphone stations are to be used, additional power supply units are necessary to meet the power requirement.

  • Page 9: Putting Into Operation

    Mains connection with fuse (6.3 A short-circuit protection) NetRateBus conference sockets, MCS-D 200 with 1 Push-Pull socket to connect other power supply units for example. Fan outlet (number of fan outlets depends on the number of power supply units integrated into the control unit) RS 232 C (1).

  • Page 10: Mains Connection

    How to switch the control unit on/off • Before switching the MCS-D 200 control unit on, please check all connections. If there are additional power supply units connected to the control unit, we recommend switching on the devices as described in the following: 1.

  • Page 11: How To Connect A Pc Or Media Control System

    Example of a system set-up: 1 MCS-D 200 control unit with 2 power packs ... . 10 MCS-D 202 interpreter stations 1 Power supply unit with 2 power packs ....for 30 microphone stations 1 Power supply unit with 3 power packs .

  • Page 12: How To Operate The Menu Of The Mcs-D 200 Control Unit

    MCS-D 200 Control Unit 3.3 How to operate the menu of the MCS-D 200 control unit • You can scroll through the menu by using the navigator buttons 3.3.1 Menu overview of the MCS-D 200 control unit MAIN MENU MAIN MENU*...

  • Page 13: Main Menu

    MultiSession: How to change to the next meeting In the MultiSession operation, i.e. when the same MCS-D 200 control unit is used for several meetings, the right and left hand navigator buttons can be used for selecting the individual meetings.

  • Page 14: System Set-Up Menus

    The SYSTEM SETUP menus are used for the settings of the system level = GLOBAL SYSTEM SETTINGS : Define Channels, Message(s), Options, Delegate IDs, Interpreter IDs, Technician IDs and DAI/DDI Management. All devices, channels, messages and options of the whole MCS-D 200 system are defined via these menus. In the SESSION menus you can prepare settings for individual meetings.
  • Page 15 Warning: In systems using PC and iCNS software the settings are operated via the iCNS software. The set-up menus of the MCS-D 200 control unit cannot be operated to avoid conflicts. NO SESSION: iCNS is in the offline mode (conference closed), not in the online mode (conference started).

  • Page 16: Session Menus

    MCS-D 200 Control Unit 3.3.4 Session menus In the SESSION menus settings for the meeting such as Mode/Limit, Channel List, Presidents, Interpreters are selected for the meeting selected in the main menu. press the ENTER button Use the up or down navigator...

  • Page 17: Modes / Limit Menus

    Determine the maximum number of open microphones. The maximum number is 16. Note: If the rights of a chairman station are assigned to a microphone station via the MCS-D 200 control unit, the chairman can control the meeting actively by using the following function buttons: CANCEL button to cancel turned on microphones and/or requests to speak.
  • Page 18 MCS-D 200 Control Unit How to set Modes To select the mode press the SET button. A star in brackets indicates the selected operating mode. Session number Use the up or down navigator button for scrolling.
  • Page 19 MODE menu. Press MODE button to return to the MODE menu. Change LIMIT: Press the left or right hand navigator button. Cursor is flashing Session number MCS-D 200 Control Unit Use the up or down navigator button for scrolling.

  • Page 20: Channel List

    MCS-D 200 Control Unit 3.3.4.2 Channel List In the menu CHANNEL LIST you can prepare and edit a list of all required channels. All channels have to be defined in the menu DEFINE CHANNELS (refer also to the chapter 3.3.5 “Define Channels”), because the channel list is basing on the predefined channels.
  • Page 21 Then use the right or left hand navigator button to move the cursor to the next choice etc. press the ENTER button MCS-D 200 Control Unit Use the right or left hand navigator button to scroll through the international language list.

  • Page 22: President(S)

    MCS-D 200 Control Unit 3.3.4.3 President(s) In the PRESIDENTS menu you can assign the functions of a chairman station such as CANCEL, PRIORITY, PREVIOUS or NEXT to any microphone station in the selected session (here: session 01). press the ENTER button The following items refer to chairman stations: •...
  • Page 23 PRIORITY button of the microphone station 0001, the microphone of the chairman station 0002 is muted along with the delegate stations. session number Device ID MCS-D 200 Control Unit Use the right or left hand navigator button to change the level...

  • Page 24: Interpreter

    MCS-D 200 Control Unit 3.3.4.4 Interpreter In the INTERPRETER menu you can prepare a list of all required interpreter’s channels from the list of session channels for the selected session (here: session 01) (refer also to chapter 3.3.4.2 “Channel List”). The list includes only channels required for interpreters, i.e.
  • Page 25 To remove a selected booth from the session press the RESET button. The star is removed. Repeat these steps if you want to remove more booths from the session. Press the EXIT button to leave the menu. Session number Booth number MCS-D 200 Control Unit Use the up or down navigator button to scroll through the menu...

  • Page 26: Define Channels

    MCS-D 200 Control Unit 3.3.5 Define Channels In the DEFINE CHANNELS menu all channels required for the whole system are defined, added or removed. By using these defined channels the lists of the session channels are prepared for the individual sessions (refer to chapter 3.3.4.2 “Channel List”).
  • Page 27 Use the right or left hand navigator button to go with the cursor to the next character position MCS-D 200 Control Unit Use the up or down navigator button to scroll through the list to find the desired character...

  • Page 28: Options

    3.3.6.1 Time In the TIME menu the system time for the MCS-D 200 control unit, MCS-D 202 and MCS-D 2073 microphone stations can be set manually (refer to chapter 7.1.6 “Menu settings”) in the format HOURS – MINUTES – SECONDS.

  • Page 29: Ports

    PC with the iCNS software or to a media control Press the up or down navigator button to select a COM port Use the right or left hand navigator button to scroll through a configuration list MCS-D 200 Control Unit...

  • Page 30: Delegate Ids

    MCS-D 200 Control Unit 3.3.7 Delegate IDs For identifying a device identification number (ID) should be assigned to each delegate station. Basically, the system can be operated without the organisation of ID numbers. But for special functions such as functions of a chairman station, phoning and some data bank manangement functions the organisation of the IDs of the microphone stations is absolutely necessary for a smooth meeting.

  • Page 31: Id List

    2 have the IDs 0001 to 0150. Select the next microphone station, and so on. Use the up or down navigator button for scrolling Group number Device Identification number (ID) MCS-D 200 Control Unit Use the right or left hand navigator button to edit the number...

  • Page 32: Set Ids

    MCS-D 200 Control Unit 3.3.7.2 Set IDs This function allows you to set identification numbers for all microphone stations by pressing the MIC button of all microphone stations one after the other. The arrow indicates the active line press the ENTER button Go to the “Group”...

  • Page 33: Interpreter Ids

    Booth 1: MCS-D 202 (1) = 01-0001, MCS-D 202 (2) = 01-0002 Booth 2: MCS-D 202 (1) = 02-0001, MCS-D 202 (2) = 02-0002 press the ENTER button MCS-D 200 Control Unit Use the up or down navigator button for scrolling...

  • Page 34: Interpreter Id List

    MCS-D 200 Control Unit 3.3.8.1 Interpreter ID List You may select an individual device and assign a booth in combination with a device dentification number (DEVICE ID). Also refer to chapter 3.3.8.2 “Set Interpreter IDs” to find out how you can assign identification numbers to all interpreter stations.

  • Page 35: Conflicts

    The LED ring will illuminate and the next ID number is shown on the display of the interpreter station and on the MCS-D 200 control unit. Proceed with the next interpreter station as described above and so on. Assign the ID numbers to all interpreter stations in the same booth.

  • Page 36: Dai/Ddi Management

    MCS-D 200 Control Unit 3.3.10 DAI/DDI Management The MCS-D 200 control unit features an integrated D/A interface (=INTERNAL DAI) with the connexions CH1 IN, CH2 IN, CH1 OUT and CH2 OUT. To provide more analogue inputs and outpus, additional Digital / Analog Interfaces (DAI) are connected via the conference bus for the connection of external audio devices such as wireless microphones or tape recorders providing the sound of a video film in different languages.

  • Page 37: Ext. Dai Id List

    ENTER button The DAI SETUP menu includes a list of the internal D/A interfaces of the MCS-D 200 control unit [=00] and all external DAI units; each with its ID number that has been set in the EXT. DAI ID LIST menu.
  • Page 38 MCS-D 200 Control Unit press the ENTER button, to assign channels to DAI no. 01 Each DAI unit features CH1 IN, CH 2 IN; CH 1 OUT, CH 2 OUT press the ENTER button for CH 1 OUT Scroll through the list of channels which has been defined in the DEFINE CHANNELS menu before.

  • Page 39: Dai Control

    DAI ID LIST (refer also to chapter 3.3.10.1 “Ext. DAI ID List”. The identification number [=00] of the internal DAI of the MCS-D 200 control unit is fixed and cannot be changed. Use the up or down navigator button to scroll through the list. Use the ENTER button to select the DAI. The LED of the selected D/A unit will illuminate on the front panel of the DAI.
  • Page 40 MCS-D 200 Control Unit press the ENTER button for CH 1 OUT How to switch off a channel: Warning: Unused DAI inputs must be OFF, to avoid noise! press the OFF button How to switch on a channel: press the ON button...

  • Page 41: Ca 4115/30/45 Power Supply Unit

    Controls and indicators Front view Power switch Power LED illuminates when the MCS-D 200 control unit is switched on and ready to pass signals, no matter if the power switch is on or off. Power converter LED 1-3. These LEDs will only illuminate when the MCS-D 200 control unit and the power supply unit are switched on.

  • Page 42: Connection

    • Each unit which is connected to a NetRateBus socket is powered by the MCS-D 200 when it is switched on. It is not important if the power supply unit is switched on or off. A Digital/Analog interface or adapter connected to the NetRateBus sockets would be powered by the power converter of the MCS-D 200.

  • Page 43: Ca 4522/44/66 Digital / Analogue Interface (Dai)

    CA 4522/44/66 Digital / Analogue Interface (DAI) You may connect additional Digital / Analogue Interfaces (DAI) via the conference bus for the connection of external audio devices such as wireless microphones or tape recorders providing the sound of a video film in different languages. The 19" housing of a Digital / Analogue Interfaces (DAI) may be equipped with up to 3 interface units (=EXTERNAL DAI), each with 2 analogue audio inputs and outputs.
  • Page 44 CH1 IN: XLR LINE IN input (female), ±0 dBm, balanced. The signal fed in will be transmitted to the loudspeakers of the microphone stations or to any other output which can be selected via the MCS-D 200 control unit. CH2 IN: XLR LINE IN input (female), ±0 dBm, balanced. The signal fed in will be transmitted to the loudspeakers of the microphone stations or to any other output which can be selected via the MCS-D 200 control unit.

  • Page 45: Ca 4577 Digital / Digital Interface (Ddi)

    CA 4577 Digital / Digital Interface (DDI) To provide digital AES/EBU outputs you may connect additional CA 4577 Digital / Digital Interfaces via the conference bus. The CA 4577 is powered via the system and will be recognised when the system is started. Use the DAI/DDI MANAGEMENT menus to adjust the following: •...

  • Page 46: Microphone Stations

    MCS-D 2073 Microphone Station Microphone Stations For the MCS-D 200 system there is a variety of microphone stations available. Make sure that the microphone and all cables are tightly and properly connected. If a cable is not properly connected, interferences can occur.
  • Page 47 Microphone socket. Make sure that the microphone is connected properly and tightly. Loudspeaker. The original sound of the conference is transmitted via the two loudspeakers. When the microphone is activated, the loudspeaker of the microphone station is turned off automatically. Headphone socket (3.5 mm TRS jack) on the right and left hand side (optional with a 2nd language selector).

  • Page 48: How To Turn The Microphone On

    If the limit is exceeded, the request-to-speak is registered by the MCS-D 200 control unit and the microphone is activated automatically as soon as another speaker turns off his microphone.

  • Page 49: How To Set The Volume Of The Headphone

    When pressing the buttons the channel list is displayed. The language channels are encoded according to the international MARC language codes. In the following you will find some examples for channel descriptions. The list has been created via the menu of the MCS-D 200 control unit before.

  • Page 50: Menu Settings

    The default display is only shown, when the display is not needed to show any other function. Format: HOUR – MINUTES – SECONDS. In the TIME menu of the MCS-D 200 control unit, the system time can be set manually. The system time is automatically updated when the system is started.
  • Page 51 Telephone Note: If chip cards are used for the activation of the microphone stations, the participant himself can only dial when the chip card is inserted. When microphone stations are locked, the participants cannot dial, but accept phone calls. DEFAULT DISPLAY (e.g.

  • Page 52: How To Switch On A Microphone While Phoning

    MCS-D 2073 Microphone Station 7.1.7 How to switch on a microphone while phoning While phoning, the microphone of a microphone station can also be switched on or registered by pressing the microphone button. 1. If the microphone of a phoning participant is turned on, the phone call is interrupted immediately. The LED ring of the microphone is illuminated.

  • Page 53: Mcs-D 2073 As Chairman Station

    7.1.10 MCS-D 2073 as chairman station Each MCS-D 2073 microphone station can be configured as a chairman station via the MCS-D 200 control unit. Refer also to chapter 3.3.4.3 “President(s)“. Note: Whenever the MENU button is activated, the PRIOR and CANCEL buttons cannot be enabled. When the MENU button is deactivated, the PRIOR and CANCEL buttons can be enabled once again.

  • Page 54: Mcs-D 3121 / 3123

    MCS-D 3121 / 3123 Microphone Stations 7.2 MCS-D 3121 / 3123 The MCS-D 3121 delegate station provides one microphone button and a two-way loudspeaker with two tweeters. The MCS-D 3123 chairman station features one microphone button, a two-way loudspeaker with two tweeters as well as “Clear”...
  • Page 55 Lateral view MCS-D 3121 and MCS-D 3123 left hand side Microphone LED strip illuminates when the microphone is activated. Loudspeaker. The original signal of the conference is transmitted via the loudspeakers. As soon as the microphone is activated the loudspeaker will be deactivated. The volume is set via the control unit. Microphone button to activate the microphone.

  • Page 56: How To Turn On The Mcs-D 3121

    If the limit is exceeded, the request-to-speak is registered by the MCS-D 200 control unit and the microphone is activated automatically as soon as another speaker turns off his microphone.

  • Page 57: How To Operate The Mcs-D 3123 Chairman Station

    The “Prior” button operates only, if the microphone station has been programmed as a chairman station via the MCS-D 200. For a brief interruption or announcement the “Prior” button must be held down. If the microphone was turned off, it will be turned on by pressing the “Prior”...

  • Page 58: Mcs-D 3171 / 3173

    MCS-D 3171 / 3173 Microphone Stations 7.3 MCS-D 3171 / 3173 The MCS-D 3171 delegate station provides an LC display, one microphone button, five voting buttons and a two-way loudspeaker with two tweeters. The up / down navigator buttons allow selecting the desired channel while the headphone volume is set by using the right / left navigator buttons.

  • Page 59: How To Display The Device Id

    Bottom view MCS-D 3171 H and MCS-D 3173 H Lateral view MCS-D 3171 and MCS-D 3173 left hand side Microphone LED strip illuminates when the microphone is activated. Loudspeaker. The original signal of the conference is transmitted via the loudspeakers. As soon as the microphone is activated the loudspeaker will be deactivated.

  • Page 60: How To Display Messages

    If the limit is exceeded, the request-to-speak is registered by the MCS-D 200 control unit and the microphone is activated automatically as soon as another speaker turns off his microphone.

  • Page 61: How To Adjust The Headphone Volume

    The language channels are encoded according to the international MARC language codes. In the following you will find some examples for channel descriptions. The list has been created via the menu of the MCS-D 200 control unit before.

  • Page 62: Mcs-D 202

    MCS-D 202 Interpreter Station 7.4 MCS-D 202 The MCS-D 202 is an interpreter station for one interpreter. It can directly be integrated into the conference network without an additional control unit. The access to the audio channels can be configured according to the application. The interpreter station can be operated with a gooseneck microphone or headset.
  • Page 63 Socket (DIN 45326) to connect a headset or gooseneck microphone. Monitoring loudspeaker (2-way-loudspeaker system) reproduces the original signal. The loudspeaker is automatically muted as soon as the microphone is activated. Volume control for the monitoring loudspeaker Bass control to set the low frequencies for the headphones Treble control to set the high frequencies for the headphones Volume control for the headphones Change-over switch RELAY/ORIGINAL.

  • Page 64: How To Program The Relay Channel Buttons 1-3

    MCS-D 202 Interpreter Station 7.4.2 How to program the relay channel buttons 1-3 How to select the relay language channel (PRE-SELECT) Press the left or right hand PRE SELECT button to scroll through a list of all available relay channels without changing the pre-selected channels! The list is displayed in the top line.

  • Page 65: Output Channels A And B

    7.4.3 Output channels A and B Each interpreter station has two buttons for the output channels A and B. The interpreter can directly switch from output A to B, and vice versa. Both channels may be pre-selected. With the PRE SELECT buttons you can select a free output channel. “A” is the default output channel which is automatically defined when the system is started.

  • Page 66: Call Buttons

    MCS-D 202 Interpreter Station 7.4.4 Call buttons TECH button Use the TECH button to contact the technician. Hold down the button while speaking or listening to the technician. Note: Only the interpreter can contact the technician, not vice versa. During the connection the following message will be shown on the right hand side of the display of the MCS-D 202 interpreter station: The connection will be interrupted when the TECH button is released.
  • Page 67 PRESIDENT button Use the PRESIDENT button of the MCS-D 202 interpreter station to contact the chairman. Hold down the button while speaking or listening to the chairman. Note: Only the interpreter can contact the chairman, not vice versa. During the connection the following message will be shown on the right hand side of the display of the MCS-D 202 interpreter station: The connection will be interrupted when the PRESIDENT button is released.

  • Page 68: How To Assign The Interpreter Id

    Each interpreter station should be specified with an identification number (ID) in order to render an address. This may be done via the INTERPRETER IDs menu of the MCS-D 200 control unit (refer also to chapter 3.3.8 “Interpreter IDs”). Optional, the identification numbers may directly be assigned at each interpreter station one after the other. This way, you will always have an overview of the system, especially of large systems.
  • Page 69 MCS-D 202 Interpreter Station How to set the ID The “SET ID” line is displayed. Station ID= BOOTH-ID + DEVICE-ID By using the PRE-SELECT buttons you can change the BOOTH ID and the DEVICE ID as described below: 1. BOOTH ID: press left/right relay channel PRE SELECT button 2.

  • Page 70: How To Save Settings On A Chip Card

    MCS-D 202 Interpreter Station 7.4.6 How to save settings on a chip card The following settings can be saved on a chip card after the languages have been programmed (refer to “How to program the relay channel buttons 1-3” and “How to program the output channels A and B”). •...
  • Page 71 MCS-D 202 Interpreter Station...

  • Page 72: System Setup

    Single-sided powering of the microphone stations which are set up as a branch Please calculate the maximum cable length. We recommend using our standard cables. MCS-D 200 Inserting devices at any location Devices such as microphone stations, interpreter stations and digital / analogue interfaces are inserted at any location of the system.
  • Page 73 Additional power supply units for branches MCS-D 200 control unit (1 integrated power supply = 2 A) ....for approx. 15 devices MCS-D 200 control unit option A (2 intergrated power supplies = 4 A)..for approx. 30 devices To expand the system: CA 4115 power supply unit (1 integrated power supply = 2 A) .
  • Page 74 A condition for redundancy is that all cable lengths had been selected in a way that a single-sided powering could cover the power requirement. MCS-D 200 CA 4115/30/45 power supply unit Additional power supply units when the microphone units are set up in a circle With redundancy i.e.
  • Page 75 Set up the microphone stations as a branch or in a circle. The microphone stations are connected to the Extension Ports of the power supply units as a branch or in a circle. MCS-D 200 CA 4115/30/45 power supply unit...
  • Page 76 Warning: Never link branches, which are powered by different power supply units. This could lead to an overload of the cable and cause short circuits and cable fire. MCS-D 200 CA 4115/30/45 power supply unit CA 4115/30/45 power supply unit...
  • Page 77 How to connect a power supply unit to the Extension Port Note: In this setup the connected power supply unit no. 3 does only work when the power supply unit no. 2 is also turned on. MCS-D 200 1. CA 4115/30/45 power supply unit 2. CA 4115/30/45 power supply unit 3.
  • Page 78 MCS-D 200 control unit (push-pull socket) MCS-D 2073 delegate station (push-pull sockets, 2 language selectors, 1 microphone, 2 headphones) 2a MCS-D 2073 delegate station as chairman station with PRIORITY and CANCEL buttons (configuration via MCS-D 200 control unit), 1 language selector, microphone and headphone...
  • Page 79 1 x for 1,400 delegate and interpreter stations. Divison into several meetings, which are simultaneously operated by 1 MCS-D 200 (only with iCNS software) for approx. 15 microphone stations for approx. 30 microphone stations for approx. 45 microphone stations...
  • Page 80 System Setup MultiSession Management All microphone stations in Session 1 SESSION 1 OPERATOR...
  • Page 81 MCS-D 200 control unit (push-pull sockets) MCS-D 2073 delegate station (push-pull sockets, 2 language selectors, 1 microphone, 2 headphones) 2a MCS-D 2073 delegate station as chairman station with PRIORITY and CANCEL functions (configuration via the MCS-D 200 control unit), 1 language selector, microphone and headphone...
  • Page 82 System Setup MultiSession Management SESSION 1 SESSION 2 SESSION 3 OPERATOR...
  • Page 83 MultiSession Management: Several meetings can be simultaneously controlled by one MCS-D 200 control unit and the iCNS software. The individual conference rooms are combined to one large group (fig. 3b) or one large conference room (fig. 3a). For this only software settings are changed.

  • Page 84: Components

    Components MCS-D 200 Digital control unit ............Order # 483.060 MCS-D 202 Interpreter station .

  • Page 85: List Of Language Codes

    11. List of Language Codes This is a list of language codes. You will find the web version under: http://lcweb.loc.gov/marc/languages/. Refer also to: http://www.ethnologue.com/iso639/codes.asp: Afar Abkhaz Achinese Acoli Adangme Afroasiatic (Other) Afrihili (Artificial language) Afrikaans -ajm Aljamía Akan Akkadian Albanian Aleut Algonquian (Other) Amharic...
  • Page 86 Language Codes Kabyle Kachin Kalâtdlisut Kamba Kannada Karen Kashmiri Kanuri Kawi Kazakh Khasi Khoisan (Other) Khmer Khotanese Kikuyu Kinyarwanda Kyrgyz Kimbundu Konkani Komi Kongo orean Kusaie Kpelle Kurukh Kuanyama Kumyk Kurdish -kus Kusaie Kutenai Ladino Lahnda Lamba -lap Sami Latin Latvian Lezgian Lingala...

  • Page 87: Technical Specifications

    12. Technical Specifications Power supply The MCS-D system includes devices which provide power via integrated modular power supplies (MCS-D 200 control unit, CA 4115/30/45 power supply units) and devices which have to be powered (microphone stations, interfaces, adapters). Power supplies MCS-D 200 control unit (19") with integrated power supply...
  • Page 88 Technical Specifications MCS-D 200 Control Unit Max. power consumption..... . . 1 power supply: Input voltage ....... . . 100 - 250 V Supply voltage .
  • Page 89 Technical Specifications MCS-D 3121/MCS-D 3123 Microphone Station Frequency response......130 Hz - 17,000 Hz Microphone .
  • Page 90 Technical Specifications CA 4213/14 Adapter Connections CA 4213 ........3 x push-pull CA 4214 .
  • Page 91 Notes...
  • Page 92 GmbH & Co. KG Theresienstr. 8 D-74072 Heilbronn Tel. +49 (0 ) 71 31 6 17-0 Fax +49 (0 ) 71 31 617-224 E-mail: info@beyerdynamic.de Internet: www.beyerdynamic.de beyerdynamic U.K. Ltd. 17 Albert Drive Burgess Hill RH15 9TN Tel. +44 (0) 1444 258 258 Fax +44 (0) 1444 258 444 E-mail: sales@beyerdynamic.co.uk...
