Page 1: Operating Instructions
BEDIENUNGSANLEITUNG OPERATING INSTRUCTIONS NOTICE D’UTILISATION MCW-D 50 Konferenzsystem Discussion System Système de conférence digital sans fil... -
Page 2: Table Of Contents
5. Programmable Functions of the Microphone Units with the MCW-D 50 Conference Software ......Page 44... -
Page 3: Important Safety Instructions
MCW-D 50 – Important Safety Instructions Thank you for selecting the MCW-D 50 Digital wireless conference system. Please take some time to read carefully through this manual before setting up the equipment. This manual describes the installation and operation of the system without control and configuration via PC. -
Page 4: Microphone Units
Volume • If the participants of a meeting use a headphone with the MCW-D 50 microphone stations, please make sure that the volume is not set too high via the MCW-D 50 Conference Software. Otherwise, the hearing of the participants could permanently be damaged. - Page 5 MCW-D 50 – Important Safety Instructions Special Note about Power Cables for Canada and the USA Canada Only use a power cable according to CSA C22.2 No.21 and CSA C22.2 No. 42. The earthing conductor in a supply cord, or in an interconnecting cable shall have an equivalent or larger cross-sectional area that the current-carrying conductors in the supply cord or cable.
-
Page 6: Installation
MCW-D 50 Control Unit The MCW-D 50 control unit is the heart of the system. It controls the delegate and chairman microphone units. With the standard version of the MCW-D 50 control unit a maximum of 3 speakers (e.g. 2 delegates and 1 chairman) can speak simultaneously. -
Page 7: Setting Up
3.2.1 Where to place the Control Unit • If you do not use remote antennae*, place the MCW-D 50 control unit in the room where the meeting takes place. If you use remote antennae*, place them in the conference room. -
Page 8: How To Connect The Antennae
Important: • There must be an unobstructed path between the microphone units and the antennae, i.e. between the MCW-D 50 control unit and the microphone units there must not be any obstacles. The range is around 30 - 50 m. For optimum range the surface of the table is important, wood or plastic tables are ideal, but metal tables can cause interferences and reduce the range. -
Page 9: How To Switch The Control Unit On/Off
(standard: 3 channels). Important: • If the MCW-D 50 control unit is equipped with more than one module, but there are not more than 3 LEDs illuminated, please check if individual modules have been deactivated with the MCW-D 50 Conference Software. -
Page 10: Connection Of Media Control System And Pc
3.2.9 Connection of Media Control System and PC • If you want to connect a media control system and a PC to the MCW-D 50 control unit, connect the PC to the LAN network connection and the media control system to the RS 232 connection •... -
Page 11: Remote Supply Of The Antenna Amplifier Via The Control Unit
20 centimetres from all persons. Remote Supply of the Antenna Amplifier via the Control Unit** The antenna amplifiers can be supplied remotely via the MCW-D 50 control unit. On the rear of the MCW-D 50 control unit there is a status LED This LED will illuminate green, when the remote supply voltage is 5 V at all antenna sockets. -
Page 12: Delegate And Chairman Microphone Units
Delegate and Chairman Microphone Units • At the factory each microphone unit is programmed with a different serial number so that the MCW-D 50 control unit can control them. The serial number is printed on the bottom of each microphone unit. - Page 13 MCW-D 50 – Microphone Units Top view MCW-D 523 chairman microphone unit Gooseneck microphone with illuminated ring Loudspeaker LED to indicate the function (green/red) Microphone button Clear button to clear the delegate microphone units Function button for optional functions (refer also to chapter 5.2)
-
Page 14: Switching On/Off
MCW-D 50 control unit. • Furthermore, the microphone units are switched off automatically, when they do not receive a signal from the MCW-D 50 control unit for more than 3 minutes. MCW-D 50 control unit Important: •... -
Page 15: Powering / Operating Time
The remaining time of operation is around 60 minutes. • The supplied MCW-D 50 Conference Software indicates the decreasing battery voltage on a PC or external media control system connected to the MCW-D 50 control unit. Rear view MCW-D 531 / MCW-D 533... -
Page 16: Operating Modes
MCW-D 50 – Setting up Operating Modes • The different operating modes such as Normal, Push-To-Talk or Voice Activation are adjusted with the MCW-D 50 Conference Software. The standard operating mode is Normal. Please refer also to the appropriate MCW-D 50 Conference Software manual. -
Page 17: How To Record The Meeting
Safety Code By using the MCW-D 50 Conference software an alphanumerical code can be entered for the MCW-D microphone units and the MCW-D 50 control unit within one system. This will increase the safety against unauthorised listening. Microphone units which do not... -
Page 18: Function Button Of The Mcw-D 523 Microphone Unit
If the chairman presses the priority button, the audio signal at the Aux Input of the MCW-D 50 control unit will be muted and all delegate units will be cleared. The LED of the chairman unit will start flashing red (slowly). -
Page 19: Request-To-Talk Mode
MCW-D 50 – Setting up Request-to-Talk Mode MCW-D 521 delegate microphone unit • This operating mode is only possible in conjunction with a PC using the MCW-D 50 Conference software or media control system (AMX ® , Crestron ® Cue etc.). -
Page 20: Charging Process
MCW-D 50 – Setting up 6.2 Charging Process 1. Connect the charger to AC power and switch it on. The switch will illuminate. 2. Put the switched-off microphone units into the charging compartments. If microphone units are switched on, they are switched off automatically. -
Page 21: Battery Charging With External Ca 2457 Power Supply Unit
• If the microphone unit is switched on during the charging process, the will illuminate green. Trouble Shooting If problems occur that you do not find listed below, reset the MCW-D system to the standard configuration with the MCW-D 50 Conference software. Please refer to the appropriate manual. Problem... -
Page 22: Simultaneous Operation Of The Mcw-D Discussion System And Other 2.4 Ghz Devices
• Check the volume adjustment with the • Increase the volume with the not work MCW-D 50 Conference Software MCW-D 50 Conference Software or the Volume control of the MCW-D 50 control unit Microphone unit cannot be switched off • “Disable Manual Power Off”... -
Page 23: Mcw-D And Wlan Or Wifi
WLAN channels 1, 6 and 11 can be used simultaneously. For this reason the WLAN channels 1, 6 and 11 were selected for the RF channels Low, Mid and High used for the MCW-D 50 discussion system. Due to this frequency compatibility the MCW-D 50 system is operated WLAN-friendly. -
Page 24: Example For Mcw-D 50, Media Control System And Wlan
Empty compartment for MCW-D 50 control unit ....... . Order # 479.780... -
Page 25: Technical Specifications
MCW-D 50 – Accessories CA 2457 Charger/DC power supply unit for MCW-D 5** microphone units ....Order # 479.721 MCW-D 50 Controller Licence for full version of controller to control the system via PC . - Page 26 MCW-D 50 – Technical Specifications Operating time depending on the type of the microphone unit ....... approx. 30 hours in discussion mode;...
- Page 27 Supply voltage ....... . .
- Page 28 MCW-D 50 – Notes...
- Page 29 Type of Equipment: Wireless Conference System MCW Digital Model Numbers: MCW-D 50, MCW-D 521, MCW-D 523 I, the undersigned, as an employee of beyerdynamic, hereby declare that the equipment specified conforms to the above Directive and Standards. Manufacturer’s Signature: Date: April 2005...
- Page 30 Theresienstrasse 8, 74072 Heilbronn, Germany Type of Equipment: Wireless Conference System Model Numbers: CC 12, CD 12 I, the undersigned, as an employee of beyerdynamic, hereby declare that the equipment specified conforms to the above Directive and Standards. Manufacturer’s Signature: Date: January 2008...
