Beyerdynamic Quinta MU 23 Operating Instructions Manual

Digital wireless conference system
Hide thumbs Also See for Quinta MU 23:
Table of Contents

Advertisement

Quick Links

Enlarged version
OPERATING INSTRUCTIONS
Quinta
Digital Wireless Conference System

Advertisement

Table of Contents
loading

Related Manuals for Beyerdynamic Quinta MU 23

Summary of Contents for Beyerdynamic Quinta MU 23

  • Page 1 OPERATING INSTRUCTIONS Quinta Digital Wireless Conference System...

  • Page 2: Table Of Contents

    Quinta – Contents Safety Instructions ..............Page Quinta CU Control Unit / Quinta Charger .

  • Page 3: Safety Instructions

    Exemption from liability • beyerdynamic GmbH & Co. KG will not be liable if any damage, injury or accident occurs due to negligent, incorrect or inappropriate operation of the product. Location •...

  • Page 4: Quinta Mu Microphone Unit

    If you connect defective or unsuitable accessories, the equipment could be damaged. Only use connection cables available from or recommended by beyerdynamic. If you use cables you have made up yourself, all claim to warranty is null and void. Switching off •...

  • Page 5: Quinta Cu Control Unit

    Quinta – Control Unit Quinta CU Control Unit The Quinta CU control unit is the heart of the system. It controls the delegate and chairman microphone units. With one control unit a maxi- mum of 4 speakers (e.g. 3 delegates and 1 chairman) can speak simultaneously. The radio transmission is in the triple band (2.4 / 5.2 / 5.8 GHz frequency band).

  • Page 6: Where To Place The Control Unit

    Quinta – Control Unit Where to Place the Control Unit • If you do not use remote antennae, place the Quinta CU control unit in the room where the meeting takes place. If you use remote antennae, place the antennae in the conference room. •...

  • Page 7: Audio Connection

    Quinta – Control Unit Audio Connection • If required, connect the Audio Mix , XLR or Cinch master output of the Quinta CU control unit to the input of a mixing console or amplifier. • If you want to feed the audio signals into a network, connect the AVB connection * to the network by using a CAT5 cable.

  • Page 8: How To Switch The Control Unit On/Off

    Quinta – Control Unit How to Switch the Control Unit On/Off • Turn on the Quinta CU control unit with the On/Off switch The Power on LED will illuminate. • The channel LED 1 to 4 will illuminate white to indicate the availability.

  • Page 9: Main Menu

    Quinta – Control Unit Main Menu Press the volume control approx. 3 seconds until the Quinta CU control unit displays “Main Menu”. By turning and pressing you can display and set different parameters in the main menu. 2.9.1 Master Volume •...

  • Page 10: Room Combining

    Quinta – Control Unit 2.9.2 Room Combining The “Room Combining” function is used when you want to operate or combine several Quinta systems in different rooms (A, B, C, D). All microphone units and control units have been set to “A” at the factory.
  • Page 11 Quinta – Control Unit • In order to confirm with “OK” turn the volume control clock- wise until “(OK)” is displayed. Press the volume control to confirm and leave the menu. • The default screen still displays “A”. • As the control unit is still set to “A” (factory setting), the micro- phone units will lose the radio link to the control unit.
  • Page 12 Quinta – Control Unit • Important: – The microphone units in the respective rooms must have a radio link to the control unit. – The configuration for room A, B, C or D is stored in the appropriate microphone units. –...

  • Page 13: Ethernet Info

    Quinta – Control Unit • In order to confirm with “OK” turn the volume control clock- wise until “(OK)” is displayed. Press the volume control confirm and leave the menu. • The default screen is displayed. • When you now enter the “Room Combining” menu item, the line “Current selection: A, B, C”...

  • Page 14: Avb Info

    Quinta – Control Unit 2.9.4 AVB Info • Press the volume control approx. 3 seconds until the Quinta CU control unit displays “Main Menu”. • Turn the volume control to the right or left until “AVB Info” is displayed. • Press the volume control to enter the submenu.

  • Page 15: Quinta Mu Microphone Units

    Quinta MU Microphone Units For the Quinta conference system there are different microphone units available: • Quinta MU 23 chairman microphone unit with three buttons (microphone, clear, function) • Quinta MU 22 double delegate microphone unit with two microphone buttons •...
  • Page 16 Quinta MU 31 Delegate Microphone Unit Quinta MU 21 Delegate Microphone Unit Bottom of Microphone Unit Quinta MU 33/31 Lateral View Bottom of Microphone Unit Quinta MU 23/22/21 Opening for unlocking the gooseneck microphone Connection for gooseneck microphone Loudspeaker “Clear” button to clear all delegate microphone units...

  • Page 17: How To Connect The Gooseneck Microphone

    Remove the gooseneck microphone by taking it by the shaft and pulling. Switching On / Off Quinta MU 23 Quinta MU 22 Quinta MU 21 How to switch on and allocate the microphone units •...

  • Page 18: Powering / Operating Time

    Quinta Conference software. If RF problems occur the microphone button will flash red. Should the system still fail to operate, please contact your beyerdynamic representative. Function Test You can test if the microphone units are operating: •...

  • Page 19: Operating Modes

    The different operating modes such as “Normal”, “Push-To-Talk” or “Voice Activation” are adjusted with the Quinta Conference software for all microphone units. The standard operating mode is “Normal”. Please refer also to the appropriate “Quinta Conference Software” or “Quinta Web Server”manual. 3.6.1 Normal Operating Mode Quinta MU 23 Quinta MU 22 Quinta MU 21 •...

  • Page 20: Maintenance Of The Microphone Units

    Programmable Function Button of the Chairman Microphone Unit Depending on the configuration the following functions are possible Quinta MU 23 with the function button : mute, clear or priority. The function button can be configured via the control unit with the Quinta Conference software.
  • Page 21 Quinta – Microphone Units 5. How to Mute Audio IN ports and clear all active delegate units Quinta MU 23 By pressing the function button a second time, mute is released. By pressing the function button a third time, the audio input is muted again and all active delegate units will be cleared etc.

  • Page 22: Request-To-Talk Mode

    Quinta – Microphone Units Request-to-Talk Mode Quinta MU 22 Double Delegate Microphone Unit • This operating mode is only possible in conjunction with a PC using the Quinta Conference software or a media control system (AMX ® , Crestron ® , Cue etc.).

  • Page 23: Quinta Cd 2 Charger In The Quinta Cc 2 | Cc 2 / 600 Case

    • With the Quinta CD 2 charger integrated in the Quinta CC 2 or CC 2 / 600 case you can charge a maximum of 10 Quinta MU 23/22/21 microphone units with the Classis GM 313 Q, 314 Q, 315 Q or Classis GM 316 Q microphone. With the Quinta CD 3 charger integrated in the Quinta CC 3 case you can charge a maximum of 12 Quinta MU 33/31 microphone units.

  • Page 24: Battery Charging With External Mains Power Adapter

    Quinta – Trouble Shooting Battery Charging with External Mains Power Adapter Quinta MU 23/22/21 Rear View • The Quinta MU microphone units can also be charged with the external CA 2458 mains power adapter, which is connected to the DC socket •...
  • Page 25 Quinta – Trouble Shooting Problem Possible Cause Solution Microphone cannot be activated • All channels are occupied • Switch off an activated microphone • Check the number of open microphones • If possible increase the NOM with the (NOM) with the Quinta Conference Soft- Quinta Conference Software or the Quinta ware or Quinta Web Server Web Server...

  • Page 26: Simultaneous Operation Of The Quinta Conference System And Other 2.4 Ghz Devices

    Quinta – Trouble Shooting Simultaneous Operation of the Quinta Conference System and other 2.4 GHz Devices (e.g. WLAN, Bluetooth) 7.1.1 Physical Laws Due to many physical laws it is not possible to guarantee a simultaneous interference-free operation of different devices using the same frequency band.

  • Page 27: Quinta And Bluetooth

    Quinta – Trouble Shooting You can easily recognise that the individual WLAN channels overlap considerably due to their bandwidth. All neighbouring channels (e.g. channel 1 & 2 or channel 7 & 8) cannot be used simultaneously, because they would disturb each other. Furthermore, channel 12 and 13 are not approved for the use in the USA.

  • Page 28: Components

    Charger for 10 Quinta MU 23/22/21 microphone units........

  • Page 29: Technical Specifications

    Bit 15 – 0 / X Quinta MU 23/22/21 Microphone Units Transmitter power........max. 20 dBm per channel and region (average, duty cycle ≤ 30%)* Battery voltage .
  • Page 30 Quinta – Technical Specifications Quinta CU Control Unit Frequency response ....... . 70 Hz – 22 kHz (-3 dB) Operation mode .

  • Page 31: Ec-Declaration Of Conformity

    Theresienstraße 8, 74072 Heilbronn, Germany Type of Equipment: Wireless Conference System Quinta Model Numbers: Quinta CU I, the undersigned, as an employee of beyerdynamic, hereby declare that the equipment specified conforms to the above Directive and Standards. Manufacturer’s Signature: Date: June, 2012 Full Name:...
  • Page 32 Model Numbers: Quinta MU 21, Quinta MU 22, Quinta MU 23 Quinta MU 31, Quinta MU 33 I, the undersigned, as an employee of beyerdynamic, hereby declare that the equipment specified conforms to the above Directive and Standards. Manufacturer’s Signature:...

  • Page 33: Fcc Regulation

    Part 15.21 Statement NOTICE: Changes or modifications made to this equipment not expressly approved by beyerdynamic GmbH & Co. KG may void the FCC authorization to operate this equipment. Part 15.105 Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 34 GmbH & Co. KG Theresienstr. 8 | 74072 Heilbronn – Germany Tel. +49 (0) 7131 / 617 - 0 | Fax +49 (0) 7131 / 617 - 204 info@beyerdynamic.de | www.beyerdynamic.com For further distributors worldwide, please go to www.beyerdynamic.com...
