System Setup
Additional power supply units for branches
MCS-D 200 control unit (1 integrated power supply = 2 A) . . . . . . . . . . . . . . for approx. 15 devices
MCS-D 200 control unit option A (2 intergrated power supplies = 4 A). . . . . for approx. 30 devices
To expand the system:
CA 4115 power supply unit (1 integrated power supply = 2 A) . . . . . . . . . . . for approx. 15 devices
CA 4130 power supply unit (2 integrated power supplies = 4 A) . . . . . . . . . . for approx. 30 devices
CA 4145 power supply unit (3 integrated power supplies = 6 A) . . . . . . . . . . for approx. 45 devices
Connect the control unit and the power supply unit with each other via the NetRateBus sockets.
Connect all devices consuming power microphone stations, interpreter stations, digital / analogue interfaces and adapters) to
the EXTENSION PORTS.
MCS-D 200
CA 4115/30/45 power suppy unit
OK
CA 4115/30/45
E
