OVERVIEW FUNCTIONS SETUP LEVEL

1 TOTAL
11 UNIT
12 DECIMALS
13 SPAN
14 DECIMALS SPAN
2 FLOWRATE
21 UNIT
22 TIME
23 DECIMALS
SPAN
24
25 DECIMALS SPAN
3 ALARM
31 FLOWZERO
32 ALARM LL
33 ALARM LO
34 ALARM HI
35 ALARM HH
36 DELAY ALARM LL
37 DELAY ALARM LO
38 DELAY ALARM HI
39 DELAY ALARM HH
4 DISPLAY
41 FUNCTION
42 ALARM SET
4.3 LIGHT
4.4 BL ALARM
5 POWER MANAGEMENT
51 LCD NEW
52 BATTERY MODE
6 FLOWMETER
61 FORMULA
62 FILTER
63 CUT-OFF
64 CALIB-LO
65 CALIB-HI
7 ANALOG
71 OUTPUT
72 RATE-MIN
73 RATE-MAX
74 CUT-OFF
75 TUNE-MIN
76 TUNE-MAX
77 FILTER
8 PULSE
81 RELAY 1
82 RELAY 2
83 RELAY 3
84 RELAY 4
85 WIDTH
86 DECIMALS
87 AMOUNT
9 COMMUNICATION
91 SPEED
92 ADDRESS
93 MODE
94 DATABITS
95 PARITY
A OTHERS
A1 MODEL
A2 SOFTWARE VERSION
A3 SERIAL NR
A4 PASSWORD
A5 TAG-NR
L; m3; kg; lb; GAL; USGAL; bbl; no unit
0000000; 111111.1; 22222.22; 3333.333
0.000001 - 999999 unit/second
0 - 6
L; m3; mg; g; kg; ton; GAL; bbl; lb; cf; rev; - - - - (no unit); scf; Nm3; Nl; P; mL
/sec; /min; /hr; /day
0000000; 111111.1; 22222.22; 3333.333
0.000001 - 999999 unit/second
0 - 6
default; no relay; ignore
0000.000 - 9999999
0000.000 - 9999999
0000.000 - 9999999
0000.000 - 9999999
0.0 - 999.9 seconds
0.0 - 999.9 seconds
0.0 - 999.9 seconds
0.0 - 999.9 seconds
total; rate
operator; setup; hidden
0% (off); 20%; 40%; 60%; 80%; 100% (full brightness)
off; on; flash
fast; 1 sec; 3 sec; 15 sec; 30 sec; off
operational; shelf
interpolation, square root
0.1- 99
0.0 - 99.9%
default; calibrate; calibrate set
default; calibrate; calibrate set
Disable; enable
0000.000 - 9999999
0000.000 - 9999999
0.0 - 9.9%
0 - 9999
0 - 9999
0.1 - 99
off; lo-lo; lo; hi; hi-hi; all; pulse
off; lo-lo; lo; hi; hi-hi; all; pulse
off; lo-lo; lo; hi; hi-hi; all; pulse
off; lo-lo; lo; hi; hi-hi; all; pulse
0.000 – 9.999 sec
0000000; 111111.1; 22222.22; 3333.333
0.001 – 9999999
1200; 2400; 4800; 9600; 9600HP; 19200; 38400
1 - 247
bus-asc; bus-rtu; off
8 bits; 7 bits
none; even; odd
F113-A
03.03.xx
xxxxxxx
0000 - 9999
0000000 - 9999999
FW_F113-A_v0601_01_EN
