4.3.
DIMENSIONS- ENCLOSURE
Aluminum enclosures:
130 mm (5.12")
HA
PG9
25mm
HL
1/2"NPT
HM
M16 x 1,5
HN
25mm
HO
M20 x 1,5
HB
31 mm
(1.22")
75 mm (2.95")
30mm 30mm
PG9
M20 x 1,5
25mm
1/2"NPT
30mm 30mm
M16 x 1,5
M20 x 1,5
M20 x 1,5
25mm
M20 x 1,5
29.1 mm (1.15")
Fig. 6: Dimensions aluminum enclosures.
FW_F113-A_v0601_01_EN
112 mm (4.40")
12mm 12mm
24mm
24mm
6 x M12
36mm
36mm
1/2"NPT
0.12"
0.12"
3x 1/2"NPT
23
15 15
23
mm
4x M20 x 1,5
115 mm (4.53")
Page 19
HP
HT
HU
HV
HZ
