Menu 9 – Motor Speed, Slow Speed Area
Menu No. Motor Speed, Slow Speed

Area and Reverse Time

9.1
9.2
9.3 Open and Close Slow Speed
9.4 Open Slow Speed Area
9.5 Close Slow Speed Area
9.6
9.7
After changing speed and slow speed, i-Learn has to be done again.
9.1 & 9.2 Open and Close Speed
This sets the speed at which the gate/door will travel. If the gate/door is travelling too fast reduce this
value.

9.3 Slow Speed

This sets the speed at which the gate/door will travel in the slow speed region. If the gate/door is
travelling too slow increase this value.
9.4 & 9.5 Slow Speed Area
This sets the slow speed travel area. If you want more travel time for the slow speed area increase this
value.

9.6 Obstruction Stop Reverse Delay Time

This sets the stop and reverse delay time when the gate/door hits an obstruction.
24
and Reverse Time
Open Speed
Close Speed
Stop Reverse Delay
Exit
Factory Adjustable
Default
80% 50% to 125%
70% 50% to 125%
50% 35% to 65%
4
5
0.4 seconds 0.2 to 2.5 seconds
Gate & Door Controller
1 to 12
1 to 12
with Eclipse Operating System (EOS)
®
