Stop
Service Call Output
Either output 1 or output 2 can be changed to service call indicator. This will trigger the output when
the software service counter is reached. Used to alert installers or owners when the gate/door is to be
serviced. Using Elsema's G-2000 receiver allows installers or owners to get a SMS message when the
service is due.
Strobe (Warning) Light when Opening or Closing
The relay output is activated whenever the gate/door is operating. The factory default is Off. Either output
1 or output 2 can be changed to strobe (Warning) light. See diagram above.
18
Master
Control
Gate & Door Controller
REL12-1 available
separately
Output NC
Output C
Output NO
REL12-1
with Eclipse
Operating System (EOS)
®
