Menu 6.4 – Service Call Output Mode
This sets the number of complete cycles (Open and Close) required before the built-in buzzer is
activated. Also the control card outputs can be configured to be activated if the number of cycles is
completed. Connecting Elsema's G-2000 receiver to the output allows owners to get a phone call or
SMS message when the service is due.
When "Service Call Due" message shows up on the LCD a service call is required. After service has
been done, follow the messages on the LCD.
Menu No. Secvice Call Mode
6.4.1
6.4.2
www.elsema.com
Service Counter
Exit
Factory
Default
Off Min: 2000 to Max: 50,000
Adjustable
