Menu 10 – Anti-Jam, Electronic Braking and
Gate Movement after Obstruction
Menu No.
10.1
10.2
10.3
Opening Direction : Gate Movement after
10.4
Closing Direction : Gate Movement after
10.5
10.6
10.1 and 10.2 Motor Open and Close Anti-Jam
When the gate/door are in the fully open or fully closed position this feature applies a reverse voltage for
aavery short time. It will prevent the motor from jamming up the gate/door so it is easy to disengage the
motors for manual operation.
10.3 Electronic Braking
This will stop the motors with an electronic brake. Brake applies to obstruction and Stop inputs.
10.4 Opening Direction : Gate Movement after Obstruction
After an obstruction has occurred in the opening direction, the gate will either stop, reverse for 2
seconds or reverse fully.
10.5 Closing Direction : Gate Movement after Obstruction
After an obstruction has occurred in the close direction, the gate will either stop, reverse for 2 seconds
or reverse fully.
www.elsema.com
Anti-Jam or
Electronic Braking
Open Anti-Jam
Close Anti-Jam
Electronic Braking
Obstruction
Obstruction
Exit
Factory Adjustable
Default
OFF 0 to 2.0 seconds
OFF 0 to 2.0 seconds
OFF
Stop / Reverse for 2 sec /
Stop
Reverse Fully
Reverse for 2 Stop / Reverse for 2 sec /
seconds Reverse Fully
Off/On
