Menu 11 – i-Learning
This feature allows you to do the intelligent travel learning of the gates/doors. Follow the messages on
the LCD to complete the learning
Menu 12 – Password
This will allow the user to enter a password to prevent unauthorised users from entering the control card
settings. User must remember the password. The only way to reset a lost password is to send the control
card back to Elsema.
To delete a password select Menu 12.2 and press Master Control.
Menu 13 – Operational Records
This is for information only.
Menu No.
13.1
13.2
13.3
13.4

13.1 Event History

The event history will store 100 events. The following events are recorded into the memory: Power
On, Low Battery, All Input Activations, Successful Opening, Successful Closing, Obstruction Detected,
Unsuccessful i-Learning Attempt and Factory Reset.
13.2 Displays Gates/Doors Operations and Current Levels
This displays the number of open cycles, close cycles, pedestrian cycles, open obstructions, close
obstructions and motor current levels. All maximum current values can be reset by the user from Menu
13.3
26
Operational Records
Event History, up to 100 events are recorded in the memory
Displays Gates/Doors Operations and Currents Levels
Reset Maximum Current Records
Exit
Gate & Door Controller with Eclipse Operating System (EOS)
®
