Menu 14 – Tools
Menu No.
14.1
14.2
14.3
14.4
14.5
14.6 Solar Gate Mode : Optimises the Control Card for Solar Applications
14.7
Optimises the Control Card for the correct Blade Fuse used
14.8
14.9
14.10

14.1 Battery Type

The MCS can be used with 2 types of backup batteries, Lead Acid & Lithium-ion.
Lead Acid. Never connect a lithium battery when lead acid mode is selected. Always
select the correct battery type.

14.2 Set the Supply Voltage

This allows you to manually set the control card to 12 or 24 Volt supply. The control card will
automatically set the correct supply voltage during setup. To use the control card in a solar application
you must set the correct voltage in the Tools. This will disable the automatic voltage sensing which
could causes problems in solar applications.
14.3 Resets Controller
Reset all settings to factory default. Also removes password.
14.4 Test Inputs
This allows you to test all the external devices connected to the controllers inputs. UPPERCASE means
input is activated and lowercase means input is deactivated.

14.5 Travel Timer for Slip Clutch Motors

This allows you to use the controller with travel time. Used for Slip clutch or Hydraulic Motors

14.8 Slow Speed Ramp Down Time

This allows you to change the time it takes the gate/door to change its speed from fast to slow.
www.elsema.com
Tools
Battery Type : Lithium-ion or Lead Acid battery
Set the Supply Voltage : 12 or 24 Volts
Resets Controller to Factory Settings
Test Inputs
Travel Timer for Slip Clutch Motors
Fuse Type : 10 or 15 Amps
Slow Speed Ramp Down Time
Magnetic Limit Switch
Exit
Only use Lithium-ion batteries supplied by Elsema.
Default setting is
