MC240 for Double and Single Gate
Setup and Technical Information
Includes latest Intelligent Technology
4th Edition
Eclipse
®
MC240

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eclipse MC240 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Elsema Eclipse MC240

  • Page 1 4th Edition Eclipse Double & Single Gate Controller ® with Eclipse Operating System MC240 ® (EOS) MC240 for Double and Single Gate Setup and Technical Information Includes latest Intelligent Technology www.elsema.com...
  • Page 2 Elsema Pty Ltd shall not be liable for any injury, damage, cost, expense or any claim whatsoever to any person or property which may result from improper use or installation of this product.
  • Page 3: Table Of Contents

    Anti-Jam and Braking .................. 27 Menu 13 – i-Learning i-Learning ..................... 27 Menu 14 – Password ...................... 27 Menu 15 – Operational Records..................28 Menu 16 – Tools ......................28 Accessories ........................30 PentaFOB Programming Instructions ................31 ® www.elsema.com...
  • Page 4: Features

    Elsema’s easy options to add remote controls or any type of Photoelectric Beams makes for a very user friendly approach, while avoiding the lockdown approach to accessories.
  • Page 5: Part Number

    MC240 MC240E www.elsema.com...
  • Page 6: Menu Structure

    Menu Structure Press Master Control for 2 seconds to enter the menu structure MAIN Auto Close Auto Close Time AC Time with PE Trig SCREEN Pedestrian Access PA Travel Time PA AC Time Input Functions PE Polarity Limit Sw Polarity PE Safety Beam &...
  • Page 7 Disable Soft Start EXIT 12.3 12.4 12.5 M2 Open Anti-Jam M2 Close Anti-Jam EXIT 14.3 EXIT 15.3 EXIT 16.6 16.3 16.4 16.5 16.7 Day / Night Sensitivity Open Hydraulic Locking Close Hydraulic Locking Test Inputs Travel Timer 16.8 EXIT www.elsema.com...
  • Page 8: Connection Diagram

    DNS Connection : On the top left corner of the control card is a connection for Day and Night Sensor (DNS). This sensor is available from Elsema and is used to detect day and night. This feature can be used to Auto Close the gate at night, turn on the courtesy light or lights on your gates during the night and many more features which require a day and night detection.
  • Page 9 Voltage free contacts for Lock, Light, Courtesy light, Service call or Gate not Closed Output 2 Voltage free contacts for Lock, Light, Courtesy light, Service call or Gate not Closed When used with Elsema’s DNS sensor, features such as auto-close, light or lock can only be Day and Night Sensor enabled at night.
  • Page 10: Supply And Motor Inputs

    Recommended wire strip length should be 12mm for all connections to the plug in terminal blocks. The diagram below shows the supply, motors, and inputs available and the factory default setting for each input. Relay Relay Relay ELSEMA Open Close Stop FUSE 240V AC Supply Motor 1...
  • Page 11 FUSE Common AC Supply AC Supply Earth 240V AC Active Supply AC Supply AC Supply Neutral Normally Closed User can change 24 VAC AC Supply 24 VAC AC Supply Forward Reverse Forward Reverse Motor 2 Contactor Motor 1 Contactor www.elsema.com...
  • Page 12 Limit Switches If you are using limit switches make sure they are connected properly. The control card can operate with either the limit switches connected directly to the cards terminal blocks, in series with the motor or travel time for Hydraulic or Clutch slip motors. Relay Relay Controller with...
  • Page 13: Setup I-Learning Steps

    5. Buzzer will indicate learning was successful. If there was no buzzer check all electrical wiring including the power supply then go back to step 1. 6. If you hear the buzzer after the i-Learn, the gate or door is ready for use. www.elsema.com...
  • Page 14: Menu 1 - Auto Close

    The control card has a normal Auto Close and several special Auto Close features each one having its own countdown timers. Elsema Pty Ltd recommends a Photoelectric Beam to be connected to the control card when any of the Auto Close options are used.
  • Page 15: Menu 2 - Pedestrian Access Features

    Pedestrian Access Auto Close Time with PE trigger 1- 60 seconds Pedestrian Access with Hold Gate Off/On Exit Elsema Pty Ltd recommends a Photoelectric Beam to be connected to the control card when any of the Auto Close options are used. www.elsema.com...
  • Page 16: Menu 3 - Input Functions

    2.1 Pedestrian Access Travel Time This sets the time the gate opens when a Pedestrian Access input is activated. 2.2 Pedestrian Access Auto Close Time This sets the countdown timer for automatically closing the gate when a Pedestrian Access input is activated.
  • Page 17: Menu 4 - Photoelectric Beam

    The factory default for the PE beam input is “normally closed” but this can be changed to normally open in Menu 3.1. Elsema Pty Ltd recommends a Photoelectric Beam to be connected to the control card when any of the Auto Close options are used.
  • Page 18: Menu 5 - Relay Output Functions

    Menu 5 – Relay Output Functions The control card has two relay outputs, Output 1 and Output 2. The user can change the function of these outputs to lock/brake, courtesy light, service call, strobe (Warning) light indicator or locking actuator. Output 1 is a voltage free relay output with common, normally open and normally closed contacts.
  • Page 19 Either output 1 or output 2 can be changed to service call indicator. This will trigger the output when the software service counter is reached. Used to alert installers or owners when the gate is to be serviced. Using Elsema’s GSM receiver allows installers or owners to get a SMS message and a call when the service is due.
  • Page 20: Menu 6 - Relay Output Modes Relay Output Modes

    Menu 6 – Relay Output Modes Menu 6.1 – Lock / Brake Output Modes The relay output in the lock / brake mode can be configured in different ways. Factory Menu No. Lock / Brake Modes Adjustable Default 1 – 30 seconds 6.1.1 Open Lock / Brake Activation 2 seconds...
  • Page 21 This sets the time the strobe light is activated before the gate operates in the open direction. Factory default is Off. 6.3.2 Pre-Close Strobe Light Activation This sets the time the strobe light is activated before the gate operates in the close direction. Factory default is Off. www.elsema.com...
  • Page 22 Also the control card outputs can be configured to be activated if the number of cycles is completed. Connecting Elsema’s GSM receiver to the output allows owners to get a phone call & SMS message when the service is due.
  • Page 23: Menu 7 - Special Features

    7.4 Automatic “Stop & Open” on Closing By default if the gate is closing and a push button or remote control is activated it will automatically stop and open the gate. When this feature is disabled then the gate will just stop in that position. www.elsema.com...
  • Page 24: Menu 8 - Leaf Delay

    7.5 Receiver Channel 2 Options The built-in receivers 2nd channel can be programmed to control a courtesy light, close the gate or can be used as Pedestrian Access. 7.6 & 7.7 Press and Hold for Open and Close Inputs If this feature is ON the user must continuously press the open or close input for it to be activated. 7.8 &...
  • Page 25: Menu 9 - Motor 1 Force And Overrun Time

    Menu No. Factory Default Adjustable and Response Time 10.1 Motor 2 Open Force 100% 40 - 100% 10.2 Motor 2 Close Force 100% 40 - 100% 10.3 Motor 2 Overrun Time 10 seconds Off - 30 seconds 10.4 Exit www.elsema.com...
  • Page 26: Menu 11 - Slow Speed Area And Reverse Time Slow Speed Area And Reverse Time

    Menu 11 – Slow Speed Area and Reverse Time Motor Speed, Slow Speed Factory Menu No. Adjustable Area and Reverse Time Default Very Slow ------------------------------------ Slow ------------------------------------ Medium 11.1 Open Slow Speed Medium ------------------------------------ Fast ------------------------------------ Very Fast ------------------------------------ Slow Speed Disabled Very Slow ------------------------------------ Slow...
  • Page 27: Menu 12 - Anti-Jam And Braking Anti-Jam And Braking

    This will allow the user to enter a password to prevent unauthorised users from entering the control card settings. User must remember the password. The only way to reset a lost password is to send the control card back to Elsema. To delete a password select Menu 14.2 and press Master Control.
  • Page 28: Menu 15 - Operational Records

    Menu 15 – Operational Records This is for information only. Menu No. Operational Records 15.1 Event History, up to 100 events are recorded in the memory 15.2 Displays Gate Operations 15.3 Exit 15.1 Event History The event history will store last 100 events. The following events are recorded into the memory: Power On, All input activations, Successful opening, Successful closing, Auto Close, i-Learning and Factory Reset.
  • Page 29: Menu 16 - Tools

    This option is only available when Day and Night Sensor (DNS) is connected. It allows you to adjust the senstivity of the sensor. This sensor can than be used to switch “On” courtesy light only at night or enable Auto Close only at night. www.elsema.com...
  • Page 30: Accessories

    ® Flashing Lights Penta Repeater can increase the operating range Elsema has several flashing lights to act as a of the keyring remotes to up to 500 metres. warning when the gate or doors is in operation. Flashing Lights...
  • Page 31: Pentafob ® Programming Instructions

    Backup Chips ® This chip is used to backup or restore the contents of a receiver. When there are 100’s of remotes programmed to a receiver the installer normally backups the receiver memory in case the receiver is damaged. www.elsema.com...
