- Page 1 6th Edition Eclipse Double & Single Gate Controller ® ® with Eclipse Operating System (EOS) MC : Controller for Double and Single Gates Setup and Technical Information Includes latest Intelligent Technology www.elsema.com...
- Page 2 Elsema Pty Ltd shall not be liable for any injury, damage, cost, expense or any claim whatsoever to any person or property which may result from improper use or installation of this product.
-
Page 3: Table Of Contents
- Keyring Remotes & Photoelectric Beams .31 - Remote Control Open Only .......22 - Strobe Lights ..........31 - Holiday Mode ...........22 - Energy Saving Mode ........22 - Automatic Stop / Open on Closing ...23 - Receiver Channel 2 Options .....23 www.elsema.com... -
Page 4: Features
Elsema’s easy options to add remote controls or any type of photoelectric beams makes for a very user friendly approach, while avoiding the lockdown approach to accessories. -
Page 5: Part Number
Solar kit for double or single gates, includes intelligent Solar kit for double or single gates, includes intelligent Solar24 Solar12 solar charger & 24 Volt 12.0Ah backup battery solar charger & 12 Volt 12.0Ah backup battery SP20* 20 Watt solar panel SP40* 40 Watt solar panel www.elsema.com... -
Page 6: Menu Structure
Menu Structure Press Master Control for 2 seconds to enter the menu structure MAIN Auto Close Auto Close Time AC Time with PE Trig SCREEN Pedestrian Access PA Travel Time PA AC Time Input Functions PE Polarity Limit Sw Polarity PE Beam Stops Motor PE Safety Beam Function on Close Cycle... - Page 7 Reset Max Current Records EXIT 16.7 16.6 16.3 16.4 16.5 Fuse Type : 10 or 15 Amps Travel Timer for Slip Motors Solar Gate Mode Reset Factory Default Test Inputs 16.10 16.9 16.8 EXIT Slow Speed Ramp Down Day / Night Sensitivity www.elsema.com...
-
Page 8: Connection Diagram
DNS Connection : On the top right corner of the control card is a connection for Day and Night Sensor(DNS). This sensor is available from Elsema and is used to detect day and night. This feature can be used to auto close the gate at night, turn on the courtesy light or lights on your gates during the night and many more features which require a day and night detection. -
Page 9: Setup Instructions
The diagram below shows the supply, motors, battery backup and inputs available and the factory default setting for each input. AC Supply : 24/12 Volts AC Model : MC Open Close Stop Designed by ELSEMA Relay IN AUSTRALIA 12 or 24 Volts AC Supply Motor 1... -
Page 10: Limit Switches
Limit Limit Limit Limit in series with motor * 6 Amps, 50V or better diode Elsema : Diode FR604 Diode* Diode* Diode* Diode* By default the limit switch inputs on the control card are normally closed (NC). This can be changed to normally open (NO) during the setup steps. -
Page 11: Setup I-Learning Steps
5. Buzzer will indicate learning was successful. If there was no buzzer check all electrical wiring including the power supply then go back to step 1. 6. If you hear the buzzer the gate or door is ready for use. www.elsema.com... -
Page 12: Menu 1 - Auto Close
The control card has a normal auto close and several special auto close features each one having its own countdown timers. Elsema Pty Ltd recommends a photoelectric beam should be connected to the control card when any of the auto closes options are used. -
Page 13: Auto Close After Power Restored
There are several types of Pedestrian access modes. Pedestrian access opens the gate/door for a short time to allow someone to walk through the gate/door but does not allow a vehicle access. Elsema Pty Ltd recommends a photoelectric beam should be connected to the control card when any of the auto closes options are used. -
Page 14: Menu 3 - Input Functions
Exit * 3.4: This option is only available when used for single gate mode Motor 2 Open Limit terminal can be used to wire Elsema’s safety bump strip on a single gate application. Double Gate & Door Controller with Eclipse Operating System (EOS) ®... -
Page 15: Menu 4 - Photoelectric Beam
The factory default for the PE beam input is “normally closed” but this can be changed to normally open. To change it go back to Menu 3. Elsema Pty Ltd recommends a photoelectric beam should be connected to the control card when any of the auto closes options are used. -
Page 16: Menu 5 - Relay Output Functions
Menu 5 – Relay Output Functions The control card has two relay outputs, Output 1 and Output 2. The user can change the function of these outputs to lock / brake, courtesy light, service call, strobe (Warning) light indicator or locking actuator. Output 1 is a voltage free relay output with common, normally open and normally closed contacts. -
Page 17: Lock/Brake Output
Either output 1 or output 2 can be changed to service call indicator. This will trigger the output when the software service counter is reached. Used to alert installers or owners when the gate/door is to be serviced. Use Elsema’s GSM-1000 receiver allows installers or owners to get a SMS message when the service is due. -
Page 18: Strobe Or Warning Light
Master Control Unfiltered DC Output Ouput voltage depends on supply voltage + if DC 12VAC/DC Output 2 C 24VAC/DC or 240VAC supply Output 2 NC Depends on the light - if DC Output 2 NO Strobe (Warning) Light when Opening or Closing The relay output is activated whenever the gates/doors are operating. -
Page 19: Menu 6.1 - Lock/Brake Output Modes
This sets the time the output is activated. Factory the motor starts in the close direction. Factory default is off. Setting it to Hold means the output default is Off. is activated for the total travel time in the close direction. www.elsema.com... -
Page 20: Menu 6.2 - Courtesy Light Output Mode
Menu 6.2 – Courtesy Light Output Mode The relay output in the courtesy mode can be adjusted from 2 seconds to 18 hours. This sets the time the courtesy light is activated. Factory default is 1 minute. Menu No. Courtesy Light Mode Factory Adjustable Default... -
Page 21: Menu 6.4 - Service Call Output Mode
Also the control card outputs can be configured to be activated if the number of cycles is completed. Connecting Elsema’s GSM-1000 alert receiver to the output allows owners to get a phone call or SMS message when the service is due. -
Page 22: Menu 7 - Special Features
Menu 7 – Special Features The control card has many special features that can all be customised to your specific application. Menu No. Special Features Factory Adjustable Default Remote Control Open Only Off/On Holiday Mode Off/On Energy Saving Mode Off/On Automatic Stop/Open on Closing Off/On Receiver Channel 2 Options... -
Page 23: Automatic Stop / Open On Closing
8.3 Close Leaf Delay on Mid Stop By default motor 1 will always have delay when closing even if the gate is not fully open. When disabled both motor 1 and motor 2 will start closing at the same time only when not fully open. www.elsema.com... -
Page 24: Menu 9 - Motor 1 Obstruction Detect Margins
Menu 9 – Motor 1 Obstruction Detect Margins This sets the current sensitivity margin above the normal run current to trip the gates/doors if an obstruction is detected. Different obstruction margins can be set for the open and close direction. Also the response time is adjustable. -
Page 25: Menu 10 - Motor 2 Obstruction Detect Margins
For high margin settings the supply transformer should be large enough to supply the high margin current. If the gates/doors hits an object on closing it will automatically stop and then re-open. If the gates/doors hit an object on opening it will automatically stop. www.elsema.com... -
Page 26: Menu 11 - Motor Speed, Slow Speed
Menu 11 – Motor Speed, Slow Speed Area and Reverse Time Menu No. Motor Speed, Slow Speed Factory Adjustable Area and Reverse Time Default 11.1 Open Speed 50% to 125% 11.2 Close Speed 50% to 125% 11.3 Open and Close Slow Speed 35% to 65% 11.4 Open Slow Speed Area... -
Page 27: Menu 12 - Anti-Jam, Electronic Braking And
After an obstruction has occurred the gate will either stop, reverse for 2 seconds or reverse fully. 12.7 Closing Direction : Gate Movement after Obstruction After an obstruction has occurred the gate will either stop, reverse for 2 seconds or reverse fully. www.elsema.com... -
Page 28: Menu 13 - I-Learning
This will allow the user to enter a password to prevent unauthorised users from entering the control card settings. User must remember the password. The only way to reset a lost password is to send the control card back to Elsema. To delete a password select Menu 14.2 and press Master Control. -
Page 29: Menu 16 - Tools
This allows you to use the controller with travel timers. Motor 1 and 2 can have separate travel timers up to 120 seconds. Used for Hydraulic Motors. 16.9 Slow Speed Ramp Down Time This allows you to change the time it takes the gate/door to change its speed from fast to slow. www.elsema.com... -
Page 30: Accessories
Menu (16.2). This will disable the automatic voltage sensing which could causes problems in solar applications. Backup Batteries Elsema has backup batteries perfectly matched to Backup Batteries the control card. Three sizes are available: Lab12-12, 12 Volt 12 AH Rechargeable, ideal for solar and industrial gates and doors. -
Page 31: Keyring Remotes & Photoelectric Beams .31 - Strobe Lights
IP-66 ratings. PentaFOB Remotes ® Flashing Lights Elsema has several flashing lights to act as a warning when the gate or doors is in operation. Flashing Lights Penta Repeater can increase the operating range of the keyring remotes to up to 500 metres. - Page 32 ELSEMA PTY LTD 31 Tarlington Place Smithfield NSW 2164 Australia 02 9609 4668 02 9725 2663 www.elsema.com...
