7.5 Receiver Channel 2 Options

The receivers 2nd channel can be programmed to control a courtesy light or used for pedestrian access.
7.6 & 7.7 Press and Hold for Open and Close Inputs
If this feature is ON the user must continuously press the open or close input for it to be activated.
7.8 Window or Louvre Mode
This mode optimises the control card for operating electronic windows or louvres.
Menu 8 – Obstruction Detect Margins
This sets the current sensitivity margin above the normal run current to trip the gate/door if an
obstruction is detected. Different obstruction margins can be set for the open and close direction. Also
the response time is adjustable.
The minimum margin will allow least pressure applied to trip the gate/door if it hits an object. The
maximum margin will allow for a large amount of pressure applied to trip the gate/door if it hits an
object.
Menu No. Obstruction Detect Margins and
8.1 Open Obstruction Margin
8.2 Close Obstruction Margin
Open and Close Slow Speed
8.3
8.4 Obstruction Detect Response Time
8.5

Margin Example

Motor is running at 2 Amps and the margin is set to 1.5 Amps, an obstruction detect will occur at
3.5 Amps (Normal Running Current + Margin).
For high margin settings, the supply transformer should be large enough to supply the high margin
current.
If the gate/door hits an object on closing it will automatically stop and then re-open. If the gate/door hits
an object on opening it will automatically stop.
www.elsema.com
Response Time
Obstruction Margin
Exit
Factory Default Adjustable
1 Amp 0.5 - 6.0 Amps
1 Amp 0.5 - 6.0 Amps
1 Amp 0.5 - 6.0 Amps
Fast, Medium
Medium
and Slow
23
